| Ref | Part Number | Description |
|---|
| 1 |
108-9083 |
PLATE-SIDE, RH Price: $328.36 |
| 1 |
532123899 |
BATTERY.DRY.30.AMP This part replaces 532163465. Price: $139.99 |
| 2 |
108-9082 |
PLATE-SIDE, LH Price: $328.36 |
| 2 |
874760412 |
BOLT.HEX.1/4.X.3/4.DICHROMATE Price: $3.99 |
| 3 |
104-3396 |
SCREW-HH Price: $0.75 |
| 4 |
99-8662 |
TUBE-SPRING Price: $21.55 |
| 5 |
3218-5 |
NUT-JAM Price: $0.27 |
| 6 |
87-7270 |
WASHER-THRUST Price: $0.89 |
| 7 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 8 |
3290-357 |
NUT-HHF, WHIZ Price: $0.61 |
| 8 |
532193228 |
BOX.BATTERY.MNT.REAR.L Price: $11.99 |
| 9 |
119-4275 |
SPRING-COMPRESSION Price: $60.71 |
| 12 |
110-4069 |
BRACKET Price: $5.57 |
| 13 |
115-2007 |
ROD-SPRING Price: $34.97 |
| 14 |
92-2762 |
PIN-HAIR Price: $1.09 |
| 15 |
119-4162 |
SCREW-CARR This part replaces 3231-25. Price: $1.73 |
| 16 |
532176138 |
SWITCH INTERLOOK PUSH-IN Price: $11.99 |
| 17 |
107-7400 |
PIN-LYNCH Price: $9.56 |
| 18 |
110-4058 |
BRACKET-CHAIN Price: $32.43 |
| 19 |
112-8935 |
FRAME-CENTER Price: $455.11 |
| 20 |
107-2979 |
BOLT-SHOULDER Price: $3.94 |
| 21 |
3234-19 |
SCREW-HHF Price: $1.73 |
| 21 |
532183759 |
HARNESS ASSY LIGHT Price: $29.99 |
| 22 |
532004152 |
LIGHTBULB Price: $2.99 |
| 22 |
67-9410 |
WASHER Price: $2.04 |
| 23 |
108-4279 |
SPACER-FRAME Price: $8.34 |
| 24 |
117-3752 |
TUBE-SUPPORT Price: $68.98 |
| 25 |
112-8937 |
CARRIER FRAME ASM Price: $893.50 |
| 25 |
585555501 |
CABLE.STARTER.8GA.17.5 This part replaces 532412895. Price: $4.99 |
| 26 |
283-71 |
PIN-LYNCH Price: $2.73 |
| 26 |
532175158 |
FUSE 20AMP Price: $3.99 |
| 27 |
873680400 |
NUT.CROWNLOCK.1/4 This part replaces 873510400. Price: $2.99 |
| 28 |
532198885 |
CABLE.BLACK.18"REAR.BA Price: $19.99 |
| 29 |
532192749 |
SWITCH.SEAT.DP W/RAMPS Price: $12.99 |
| 30 |
532193350 |
SWITCH.IGN.DELTA.W.LGH.ROS Price: $9.99 |
| 33 |
532411933 |
KEY.CHAIN.BLISTER.PACK.GEN.USA Price: $6.99 |
| 34 |
532110712 |
SWITCH LT Price: $4.99 |
| 40 |
532401098 |
HARNESS IGN. DASH Price: $74.99 |
| 41 |
539990071 |
HCS 1/4-20. This part replaces 817720408. Price: $1.99 |
| 42 |
532154336 |
COVER.TERMINAL.RED This part replaces 532131563. Price: $4.99 |
| 43 |
582042801 |
SOLENOID.STARTER.BRASS.PLUNGER This part replaces 532192507. Price: $7.99 |
| 55 |
532171877 |
BOLT, 5/16-18 X 1 3/4 This part replaces 817060512. Price: $3.99 |
| 71 |
532441544 |
HARNESS.CHASSIS.TEX.8AWG Price: $59.99 |
| 79 |
532175242 |
BULB HOLDER ASM. Price: $11.99 |
| 87 |
532197802 |
SWITCH.INTRLCK.CLUTCH. Price: $11.99 |
| 90 |
532435395 |
COVER.TERMINAL.BATTERY Price: $2.99 |
| 92 |
532196615 |
HARNESS.PIGTAIL.CONSLE Price: $11.99 |
| 93 |
532192540 |
SCREW.PLASTITE Price: $2.99 |
