TRIMMER ASSEMBLY
Parts (26)
| Ref | Part Number | Description |
|---|---|---|
| 1 | 125-3527-03 | SCRAPER-NARROW Price: $57.49 |
| 1 | 534234501 | Power Cord Price: $3.33 |
| 2 | 115-7364 | BLOCK-CLAMP, SCRAPER Price: $17.51 |
| 2 | 534356742 | Handle Set Price: $3.33 |
| 3 | 115-7372 | SCREW-HH Price: $0.47 |
| 3 | 534193001 | Trigger Switch Price: $3.33 |
| 4 | 534162323 | Harness Price: Call Us |
| 5 | 534193700 | Screw Price: $1.99 |
| 6 | 534299725 | Rain Guard Price: Call Us |
| 7 | 534386404 | Tube Price: $3.33 |
| 8 | 534605011 | Retaining Ring Price: $1.99 |
| 9 | 534273572 | Housing Set Price: Call Us |
| 10 | 534619037 | Screw Price: $3.33 |
| 11 | 534455305 | Air Baffle Price: $3.33 |
| 12 | 534517300 | Motor Ass'y. Price: $3.33 |
| 13 | 534264935 | Rotating Head Price: $3.33 |
| 14 | 952710513 | Spool & Line Price: Call Us |
| 15 | 534561000 | Terminal Cap Price: $1.99 |
| 16 | 534193800 | Screw Price: $3.33 |
| 17 | 534525205 | Blade Retainer Ass'y. Price: $2.99 |
| 18 | 534872701 | Endbell Ass'y. (Drive) Price: $3.33 |
| 19 | 534517400 | Armature Ass'y. Price: $3.33 |
| 20 | 534521010 | Field Ass'y. Price: $3.33 |
| 21 | 534601015 | Brush Spring Price: $3.33 |
| 22 | 534600042 | Carbon Brush Price: $1.99 |
| 23 | 534522012 | Bracket/Plate Ass'y. Price: $3.33 |
