| Ref | Part Number | Description |
|---|
| 1 |
106-6898 |
JOINT-BALL This part replaces 92-5837. Price: $210.81 |
| 2 |
3220-11 |
NUT-JAM Price: $0.81 |
| 3 |
32144-11 |
SCREW-THD ROLL, HWH Price: $6.99 |
| 4 |
74-6450 |
BRACKET-BULKHEAD, STEERING Price: $44.73 |
| 5 |
340-70 |
NUT-LOCK Price: $2.10 |
| 6 |
139-0988 |
HOSE ASM This part replaces 86-3130. Price: $74.13 |
| 7 |
86-3120 |
HOSE ASM Price: $61.22 |
| 8 |
165619 |
Rod, Shift Price: Call Us |
| 8 |
93-7247 |
WASHER-THRUST Price: $3.46 |
| 9 |
93-7240-03 |
DISCONTINUED Price: Call Us |
| 10 |
325-20 |
SCREW-HH Price: $6.29 |
| 10 |
76020416 |
Pin, Cotter 1/8 x 1 Price: Call Us |
| 11 |
3296-45 |
NUT-HEX Price: $3.79 |
| 12 |
3256-29 |
WASHER-FLAT Price: $2.59 |
| 13 |
94-8000 |
NUT-HEX Price: $2.65 |
| 14 |
10040400 |
Washer Lock 1/4 Price: Call Us |
| 14 |
325-35 |
SCREW-HH Price: $2.37 |
| 15 |
3234-12 |
SCREW-HHF Price: $0.61 |
| 15 |
74490544 |
Bolt Hex Flghd 5/16-18 Gr. 5 Price: Call Us |
| 16 |
69-8890 |
CAP-SPINDLE Price: $13.32 |
| 16 |
73800500 |
Nut, Lock Hex w/Ins 5/16-18 UNC Price: Call Us |
| 17 |
32151-10 |
RING-RETAINING Price: $0.81 |
| 18 |
62-2170 |
WASHER-THRUST Price: $4.48 |
| 19 |
73800600 |
Nut, Lock Hex w/Wsh 3/8-16 UNC Price: Call Us |
| 19 |
94-5607 |
AXLE ASM Price: $1,648.44 |
| 20 |
92-9725-03 |
LH SPINDLE ASM Price: $553.13 |
| 21 |
140845 |
Knob Price: Call Us |
| 21 |
92-9724-03 |
RH SPINDLE ASM Price: $644.87 |
| 22 |
169498 |
Rod, Brake Price: Call Us |
| 23 |
32128-49 |
NUT-HHF Price: $1.04 |
| 24 |
3220-7 |
NUT-JAM Price: $4.09 |
| 24 |
73350600 |
Nut Price: Call Us |
| 25 |
106888X |
Spring, Rod, Brake Price: Call Us |
| 25 |
93-0307 |
NUT-LOCK, RETAINER Price: $3.36 |
| 26 |
19131316 |
Washer 13/32 x 13/16 x 16 Ga. Price: Call Us |
| 26 |
3272-13 |
PIN-COTTER Price: $0.25 |
| 27 |
139-2564 |
NUT-LUG This part replaces 242-50. Price: $0.99 |
| 27 |
76020412 |
Pin, Cotter 1/8 x 3/4 Price: Call Us |
| 28 |
175765 |
Rod, Parking Brake Price: Call Us |
| 28 |
80-8660 |
SPACER-COUPLER Price: $49.67 |
| 29 |
32144-41 |
SCREW-TAPTITE Price: $4.79 |
| 29 |
71673 |
Cap, Parking Brake Price: Call Us |
| 30 |
114-3908 |
HUB ASM This part replaces 92-9651. Price: $129.48 |
| 30 |
169592 |
Bracket, Transmission Price: Call Us |
| 31 |
93-0309 |
WASHER-TAB Price: $3.52 |
| 32 |
3272-12 |
PIN-COTTER Price: $0.25 |
| 32 |
74760512 |
Bolt Hex 5/16-18 UNC x 3/4 Price: Call Us |
| 33 |
92-5833 |
SPACER-JOINT, BALL Price: $20.71 |
| 34 |
105-7815 |
TIE ROD ASM This part replaces 105-7815-03. Price: $573.88 |
| 34 |
175578 |
Shaft, Foot Pedal Price: Call Us |
| 35 |
120183X |
Bearing, Nylon Price: Call Us |
| 35 |
340-97 |
FITTING-ELBOW, 90 DEG Price: $36.21 |
| 36 |
19211616 |
Washer Price: Call Us |
| 36 |
94-8142 |
HYD CYLINDER ASM Price: $802.19 |
| 37 |
1572H |
Pin, Roll Price: Call Us |
| 37 |
92-5839 |
JOINT-BALL Price: $207.89 |
| 38 |
179114 |
Pulley, Idler, Composite Price: Call Us |
| 38 |
325-12 |
SCREW-HH Price: $2.27 |
| 39 |
74760648 |
Bolt Price: Call Us |
| 40 |
302-2 |
FITTING-GREASE Price: $1.89 |
| 41 |
175556 |
Keeper, Belt, Idler Price: Call Us |
| 41 |
93-7249 |
DISCONTINUED Price: Call Us |
| 42 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 43 |
76-4880 |
CONNECTOR Price: $10.76 |
| 44 |
56-7973 |
CLAMP-TUBE Price: $15.56 |
| 45 |
32104-37 |
SCREW-HWH, THREAD CUT Price: $3.26 |
| 46 |
32136-14 |
NUT-HST Price: $3.38 |
| 47 |
127783 |
Pulley, Idler, V-Belt Price: Call Us |
| 47 |
3256-71 |
WASHER-FLAT Price: $0.81 |
| 48 |
154407 |
Bellcrank Clutch Grnd Drustl Price: Call Us |
| 48 |
76-8350 |
STOP-AXLE Price: $10.92 |
| 49 |
123205X |
Retainer, Belt Price: Call Us |
| 49 |
86-5780 |
RH REAR STEERING TUBE ASM Price: $109.22 |
| 50 |
72110612 |
Bolt 3/8-16 x 1-1/2 Gr. 5 Price: Call Us |
| 50 |
86-5790 |
LH REAR STEERING TUBE ASM Price: $104.10 |
| 51 |
32151-104 |
RING-RETAINING, EXTERNAL Price: $4.85 |
| 51 |
73680600 |
Nut Price: Call Us |
| 52 |
100-3769 |
PROTECTOR-BEARING Price: $41.94 |
| 52 |
73680500 |
Nut Crownlock 5/16-28 Price: Call Us |
| 53 |
100-3809 |
CAP-PROTECTOR, BEARING Price: $6.39 |
| 53 |
105710X |
Link, Clutch Price: Call Us |
| 54 |
254-92 |
CONE-BEARING, OUTER Price: $15.84 |
| 55 |
105709X |
Spring, Return, Clutch Price: Call Us |
| 55 |
69-2980 |
SEAL Price: $33.94 |
| 56 |
17060620 |
Screw 3/8-16 x 1-1/4 Price: Call Us |
| 57 |
140294 |
V-Belt, Drive Price: Call Us |
| 59 |
169691 |
Keeper, Belt, Center Price: Call Us |
| 61 |
17120614 |
Screw, 3/8-16 x .875 Price: Call Us |
| 62 |
8883R |
Cover, Pedal Price: Call Us |
| 63 |
175410 |
Pulley, Engine Price: Call Us |
| 64 |
71170764 |
Bolt Hex 7/16 x 4 Gr. 5 Price: Call Us |
| 65 |
10040700 |
Washer Price: Call Us |
| 66 |
154778 |
Keeper, Belt Engine Hydro Price: Call Us |
| 69 |
142432 |
Screw Hex Wsh Hi-Lo 1/4-1/2 Unc Price: Call Us |
| 70 |
134683 |
Guide, Belt, Mower Drive RH Price: Call Us |
| 71 |
169183 |
Strap, Torque, Lh Price: Call Us |
| 73 |
169182 |
Strap, Torque, Rh Price: Call Us |
| 74 |
137057 |
Spacer, Axle Price: Call Us |
| 75 |
121749X |
Washer 25/32 x 1-1/4 x 16 Ga. Price: Call Us |
| 76 |
12000001 |
Ring, E Price: Call Us |
| 77 |
123583X |
Key, Square Price: Call Us |
| 78 |
121748X |
Washer 25/32 x 1-5/8 x 16 Ga. Price: Call Us |
| 81 |
165596 |
Shaft Asm Cross Price: Call Us |
| 82 |
123782X |
Spring, Torsion Price: Call Us |
| 83 |
19171216 |
Washer 17/32 x 3/4 x 16 Ga. Price: Call Us |
| 84 |
169594 |
Link Transaxle Price: Call Us |
| 89 |
169373X428 |
Console, Shift Price: Call Us |
| 95 |
170201 |
Control Asm Bypass Hydro Price: Call Us |
| 96 |
4497H |
Spring, Retainer 1" Price: Call Us |
| 116 |
72140608 |
Bolt 3/8-16 x 1 Price: Call Us |
| 120 |
73900600 |
Bolt Hex 3/8-16 x 1-1/2 Price: Call Us |
| 150 |
175456 |
Spacer Retainer Price: Call Us |
| 151 |
19133210 |
Washer 13/32 x 2 x 10 Price: Call Us |
| 156 |
166002 |
Washer 5/16 x 1.0 x 1.25 Price: Call Us |
| 158 |
165589 |
Bracket Shift Mount Price: Call Us |
| 159 |
183900 |
Hub Shift Price: Call Us |
| 161 |
72140406 |
Bolt Rdhd Sqnk 1/4-20 x 3/4 Gr. 5 Price: Call Us |
| 162 |
73680400 |
Nut Crownlock 1/4-20 Unc Price: Call Us |
| 163 |
74780416 |
Bolt Hex Fin 1/4-20 x 1 Price: Call Us |
| 164 |
19091010 |
Washer 5/8 x .281 x 10 Ga. Price: Call Us |
| 165 |
165623 |
Bracket Pivot Lever Price: Call Us |
| 166 |
166880 |
Screw 5/16 x 1.0 x .125 Price: Call Us |
| 168 |
165492 |
Bolt Shoulder 5/16-18 x .561 Price: Call Us |
| 169 |
165580 |
Plate Fastening LT Price: Call Us |
| 197 |
169613 |
Nyliner Snap-in 5/8" ID Price: Call Us |
| 198 |
169593 |
Washer Nyl 7/8ID x .105" HYD Price: Call Us |
| 199 |
169612 |
Bolt Shoulder 5/16-18 Unc Price: Call Us |
| 200 |
72140508 |
Bolt Rdhd Sqnk 5/16-18 Unc x 1 Price: Call Us |
| 202 |
72110614 |
Bolt Car SH 3/8-16 x 1-1/2 Gr 5 Price: Call Us |
| 212 |
145212 |
Nut Hex Flange Lock Price: Call Us |
