ARMATURE, SPARK PLUG, CONTROLS, ELECTRICAL SYSTEM, GOVERNOR SPRING
Parts (42)
| Ref | Part Number | Description |
|---|---|---|
| 1 | 3231-10 | SCREW-CARR Price: $1.22 |
| 2 | 32151-72 | RING-RETAINING Price: $1.59 |
| 3 | 63-8410 | WASHER Price: $1.76 |
| 4 | 104-8301 | NUT-HF, NI Price: $1.09 |
| 5 | 130-6043 | DECAL-SERVICE Price: $37.66 |
| 6 | 120-4195 | TANK-FUEL Price: $630.36 |
| 7 | 2412-98 | CLAMP-HOSE Price: $1.39 |
| 8 | 104-5228 | FITTING-ELBOW, 90 DEG Price: $17.50 |
| 9 | 120-8908 | PIPE-STAND Price: $26.42 |
| 10 | 46-6560 | BUSHING Price: $2.94 |
| 11 | 92-2379 | CLAMP-HOSE Price: $0.34 |
| 12 | 3253-15 | WASHER-LOCK Price: $1.49 |
| 13 | 32122-24 | SCREW-PTH Price: $0.27 |
| 14 | 121-1688 | GAUGE-FUEL Price: $197.80 |
| 15 | 121-1707 | GASKET-FUEL, VITON Price: $22.66 |
| 16 | 125-9171 | CAP-FUEL Price: $46.70 |
| 17 | 121-1514-03 | BRACKET-LATCH, RH Price: $31.14 |
| 18 | 120-4190-0P | TANK SUPPORT ASM [PRIMED] This part replaces 120-4190-03. Price: $263.49 |
| 19 | 104-8300 | NUT-HF, NI Price: $0.39 |
| 20 | 120-4193-0P | BRACKET-FUEL TANK This part replaces 120-4193-03. Price: $16.84 |
| 21 | 3230-1 | BOLT-CARR Price: $1.49 |
| 22 | 3256-3 | WASHER-FLAT Price: $0.49 |
| 24 | 99-5414 | STRAP-CLEANER, AIR Price: $48.46 |
| 25 | 104-3563 | INDICATOR Price: $58.60 |
| 26 | 99-5410 | AIR CLEANER ASM Price: $381.32 |
| 27 | 322-6 | SCREW-HH Price: $0.45 |
| 28 | 32144-1 | SCREW-TAPTITE Price: $3.19 |
| 29 | 121-1513-03 | BRACKET-LATCH, LH Price: $31.14 |
| 202 | 598672820 | Links Price: $5.99 |
| 222B | 598672080 | Brackets Price: $32.99 |
| 265 | 576302101 | Clamps Price: $2.99 |
| 271 | 598672798 | Levers Price: $34.99 |
| 286 | 598672842 | Ignition Price: $39.99 |
| 333 | 598672017 | Armature Price: $44.99 |
| 347 | 598673418 | Switches Price: $8.99 |
| 356 | 598673562 | Wires Price: $4.99 |
| 485 | 598672779 | Knobs Price: $2.99 |
| 493 | 598672086 | Brackets Price: $5.99 |
| 578D | 598673555 | Wires Price: $17.99 |
| 621 | 598673426 | Switches Price: $3.99 |
| 1052 | 598673257 | Sensors Price: $49.99 |
| 1054 | 576295601 | Cables Price: $2.99 |
