| Ref | Part Number | Description |
|---|
| 1 |
321-10 |
SCREW-HH Price: $1.29 |
| 1 |
532169831 |
CHASSIS STAMPING Price: $80.52 |
| 2 |
532165606 |
DRAWBAR Price: $59.99 |
| 2 |
69-1780 |
CONTROL VALVE ASM Price: $2,259.71 |
| 3 |
233-42 |
KNOB Price: $12.88 |
| 3 |
817000612 |
SCREW, 3/8-16X3/4 This part replaces 817060612. Price: $3.99 |
| 4 |
3272-1 |
PIN-COTTER Price: $0.25 |
| 5 |
532155272 |
BUMPER.RUBBER.HOOD Price: $3.99 |
| 5 |
69-7010 |
LEVER-VALVE, LH Price: $101.21 |
| 6 |
532155923 |
SADDLE FLAT Price: $11.99 |
| 6 |
69-9140 |
LINK-LEVER, VALVE Price: $15.42 |
| 7 |
32149-2 |
NUT-KEPS Price: $2.39 |
| 8 |
3234-14 |
SCREW-HHF Price: $0.61 |
| 8 |
532126471 |
CLIP,INSULATOR Price: $3.99 |
| 9 |
532171796 |
DASH Price: $35.86 |
| 9 |
69-9150 |
SHAFT-LEVER, VALVE Price: $17.78 |
| 10 |
3272-6 |
PIN-COTTER Price: $0.25 |
| 10 |
596728201 |
Bolts This part replaces 872140608. Price: $3.99 |
| 11 |
532174996 |
PANEL.DASH.LH.LTX This part replaces 532155927. Price: $9.99 |
| 11 |
69-7810-03 |
VALVE BRACKET ASM This part replaces 69-7810. Price: $118.11 |
| 12 |
237-79 |
O-RING Price: $5.46 |
| 13 |
340-3 |
FITTING-STRAIGHT Price: $10.42 |
| 13 |
532169118 |
PANEL DASH Price: $10.06 |
| 14 |
237-22 |
O-RING Price: $2.43 |
| 14 |
596564001 |
Bolts This part replaces 817490608. Price: $2.99 |
| 15 |
340-86 |
FITTING-TEE Price: $35.23 |
| 15 |
874180512 |
Screw, Machine, Truss Head 5/16-18 UNC x 3/4 Price: $3.99 |
| 16 |
596040501 |
Hardware This part replaces 873510500. Price: $2.99 |
| 16 |
99-3577 |
HOSE ASM This part replaces 69-5860. Price: $73.12 |
| 17 |
532156051 |
HOOD - LT/YT This part replaces 532165378. Price: $549.99 |
| 17 |
69-5720 |
TUBE-HYD Price: $83.04 |
| 18 |
532126938 |
BUMPER HOOD T Price: $3.99 |
| 18 |
69-5700 |
TUBE-HYD Price: $69.94 |
| 19 |
69-5740 |
TUBE-HYD Price: $83.66 |
| 20 |
532180679 |
PLATE MTG.BATTERY/FUEL TANK This part replaces 532156437. Price: $9.99 |
| 20 |
69-5680 |
TUBE-HYD Price: $58.00 |
| 21 |
69-5890 |
TUBE-HYD Price: $58.00 |
| 22 |
69-5870 |
TUBE-HYD Price: $50.09 |
| 23 |
340-2 |
FITTING-STRAIGHT Price: $11.43 |
| 24 |
237-42 |
O-RING Price: $2.78 |
| 24 |
596564401 |
Bolts This part replaces 874780616. Price: $3.99 |
| 25 |
3254-6 |
WASHER-LOCK, INTERNAL Price: $0.31 |
| 25 |
596134901 |
GSPH This part replaces 819131312. Price: $2.99 |
| 26 |
596322601 |
Nuts This part replaces 873800600. Price: $2.99 |
| 28 |
532156880 |
GRILLE.LT.P/L HUSQVARNA.SERVIC This part replaces 532165379. Price: $256.99 |
| 29 |
532149777 |
LENS LT/PL HUSQVARNA This part replaces 532165380. Price: $24.99 |
| 30 |
532168428 |
GUARD Price: $599.99 |
| 31 |
532165156 |
BRACKET SUPPORT FENDER Price: $5.99 |
| 33 |
532147203 |
FOOT REST LH Price: $9.15 |
| 34 |
532145243 |
FOOTREST LT/YT/GT RH This part replaces 532147202. Price: $9.15 |
| 35 |
596136001 |
Bolts This part replaces 872110606. Price: $3.99 |
| 37 |
596030701 |
Screws This part replaces 817490508. Price: $2.99 |
| 38 |
532175710 |
BRACKET.ASM.PIVOT.MOWER.REAR This part replaces 532169834. Price: $9.99 |
| 52 |
596135301 |
Washers This part replaces 819091416. Price: $2.99 |
| 53 |
532150067 |
BRACKET PNT PICK OFF LT/PL Price: $1.64 |
| 57 |
596230901 |
Screws This part replaces 874780412. Price: $2.99 |
| 58 |
532150127 |
AIR DUCT P/L/LT Price: $13.99 |
| 68 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 71 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873680400. Price: $3.99 |
| 102 |
532002751 |
CLIP T This part replaces 532124996. Price: $2.42 |
| 129 |
596582301 |
Washers This part replaces 819091016. Price: $2.99 |
| 134 |
532160219 |
ROD SUPPORT HOOD LT/PL HUS. Price: $7.99 |
| 145 |
532409167 |
ROD.PIVOT.HOOD This part replaces 532156524. Price: $9.99 |
| 162 |
532165672 |
BRACKET Price: $59.99 |
| 163 |
532165673 |
BRACKET Price: $43.99 |
| 164 |
532165605 |
SUPPORT Price: $59.99 |
| 165 |
583687501 |
COVER.BATTERY.CRD.BLACK.LT This part replaces 532167979. Price: $11.99 |
| 166 |
532189747 |
SCREW.HI-LO#13-16X5/8 This part replaces 532164863. Price: $14.99 |
| 167 |
532165779 |
SUPPORT.ASM.BACKPLATE Price: $54.99 |
| 168 |
872050412 |
BOLT.ROUND.HEAD.SQUARE.NECK Price: $4.99 |
| 169 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 532123976. Price: $3.99 |
| 170 |
532165607 |
COVER BACKPLATE Price: $149.99 |
| 171 |
596337801 |
Bolts This part replaces 872140620. Price: $4.99 |
| 172 |
596134901 |
GSPH This part replaces 819132016. Price: $2.99 |
| 173 |
873510600 |
NUT Price: $4.99 |
| 174 |
532165939 |
BRACKET Price: $28.16 |
| 175 |
532166212 |
GUARD Price: $24.24 |
| 176 |
532192786 |
BAGGER.HINGE.PIN This part replaces 532128600. Price: $14.99 |
| 177 |
532132796 |
SPRING COVER LH Price: $5.99 |
| 178 |
596917601 |
Pins This part replaces 876020312. Price: $1.99 |
| 179 |
532165942 |
ROD PIVOT Price: $7.99 |
| 180 |
596580801 |
Bolts This part replaces 874760516. Price: $2.99 |
| 181 |
596040501 |
Hardware This part replaces 873680500. Price: $2.99 |
| 182 |
532138200 |
WASHER Price: $3.99 |
| 183 |
596565301 |
WASHER PLAIN WASHER 3/8 X 0.08 This part replaces 819131316. Price: $2.99 |
| 184 |
532166139 |
BRACKET Price: $25.99 |
| 185 |
532165940 |
TUBE LEVER Price: $4.99 |
| 186 |
597000601 |
LATCH.ASM.MULCH/BAGGER This part replaces 532160793. Price: $5.99 |
| 187 |
596987401 |
Nuts This part replaces 532125004. Price: $2.99 |
| 188 |
819061216 |
WASHER Price: $3.99 |
| 189 |
810071000 |
LOCKWASHER #10 Price: $3.99 |
| 190 |
596039001 |
Screws This part replaces 871161010. Price: $2.99 |
| 192 |
874930624 |
Bolt, Hex Head 3/8-16 UNC x 1-1/2 This part replaces 817490624. Price: $6.99 |
| 193 |
817070412 |
Screw Truss 1/4-20 x 3/4 Tap/R Price: $2.34 |
| 194 |
817000612 |
SCREW, 3/8-16X3/4 This part replaces 817060612. Price: $3.99 |
| 198 |
532168937 |
NUT Price: $2.99 |
