| Ref | Part Number | Description |
|---|
| 7 |
121-2974 |
ROD-BRAKE, RH Price: $29.99 |
| 8 |
121-2975 |
ROD-BRAKE, LH Price: $29.99 |
| 9 |
3296-42 |
NUT-LOCK, NI Price: $0.39 |
| 10 |
119-8952 |
WASHER Price: $0.39 |
| 11 |
117-1169 |
SPRING-COMPRESSION Price: $2.39 |
| 13 |
1-806003 |
PIN-COTTER This part replaces 3290-307. Price: $1.39 |
| 14 |
135-0148 |
PIVOT-BRAKE Price: $84.99 |
| 15 |
32120-47 |
RING-RETAINING, EXTERNAL Price: $1.19 |
| 16 |
136-7469 |
BEARING-SPHERICAL Price: $7.69 |
| 17 |
55-9280 |
SPRING-EXTENSION Price: $6.29 |
| 18 |
3230-23 |
SCREW-CARR Price: $0.89 |
| 19 |
104-8300 |
NUT-HF, NI Price: $0.89 |
| 20 |
135-0147-03 |
ANGLE-MOUNT PIVOT Price: $8.29 |
| 22 |
135-0164 |
ROD-LINK HANDLE Price: $24.99 |
| 23 |
1-303105 |
YOKE-ADJUSTABLE Price: $11.99 |
| 24 |
1-808280 |
PIN-CLEVIS Price: $2.29 |
| 25 |
3272-5 |
PIN-COTTER Price: $1.39 |
| 26 |
135-0165-03 |
LEVER-BRAKE Price: $28.99 |
| 27 |
119-7640 |
WASHER-THRUST Price: $3.19 |
| 28 |
121-4517 |
WASHER-WAVE Price: $3.59 |
| 29 |
126-5989 |
PIVOT-FLANGE Price: $2.29 |
| 30 |
323-7 |
SCREW-HH Price: $2.69 |
| 31 |
63-8590 |
SCREW Price: $1.19 |
| 32 |
135-0190-03 |
HANDLE-BRAKE Price: $13.99 |
| 33 |
132-4749 |
GRIP-LEVER Price: $4.89 |
| 34 |
3219-2 |
NUT-HEX Price: $0.79 |
