| Ref | Part Number | Description |
|---|
| 1 |
582478602 |
NUT FLG, NYLOCK, 1/4-20 GR G C This part replaces 532063601. Price: $1.99 |
| 3 |
586122501 |
KIT.ROPE.GUIDE.T-KNOB This part replaces 532179585. Price: $7.99 |
| 5 |
532174291 |
HANDLE.LOWER.BLACK Price: $32.99 |
| 6 |
582478602 |
NUT FLG, NYLOCK, 1/4-20 GR G C This part replaces 532063601. Price: $1.99 |
| 7 |
532183724 |
KIT.KNOB.HANDLE.SERVICE This part replaces 532131959. Price: $9.99 |
| 8 |
532158755 |
SCREW.PAN.HEAD This part replaces 532144929. Price: $4.99 |
| 9 |
532182154 |
CONTRL.THROTTLE. This part replaces 532164137. Price: $17.99 |
| 11 |
532133107 |
ENGINE ZONE CONTROL Price: $17.99 |
| 12 |
817021008 |
SCREW This part replaces 532750097. Price: $3.99 |
| 13 |
532850733 |
BRACKET.UPSTOP This part replaces 532125162. Price: $4.99 |
| 14 |
532125078 |
WASHER.ENGINE.BZP This part replaces 532213146. Price: $4.99 |
| 15 |
532083816 |
SCREW.HEX.HEAD.WASHER.10-16 Price: $4.99 |
| 16 |
532183724 |
KIT.KNOB.HANDLE.SERVICE This part replaces 532136376. Price: $9.99 |
| 19 |
532051793 |
HAIRPIN COTTER Price: $5.99 |
| 21 |
532413160 |
SKIRT.REAR.22RD/SD.FO/VE This part replaces 532165858. Price: $11.99 |
| 22 |
532007192 |
WIRE TIE This part replaces 532066426. Price: $7.99 |
| 27 |
532408585 |
SPRING.HINGE This part replaces 532160832. Price: $11.99 |
| 30 |
532160833 |
HINGE ROD Price: $3.99 |
| 33 |
596040501 |
Hardware This part replaces 532063124. Price: $2.99 |
| 34 |
532170373 |
BRACKET.ASM.HDL.22.ECON.HW.LH. This part replaces 532174413. Price: $8.99 |
| 35 |
532170374 |
BRKT.ASM.HDL.22.ECON.HW.RH This part replaces 532174414. Price: $8.99 |
| 36 |
532407494 |
BRACKET.ADJ.5POS.ADS This part replaces 532165704. Price: $3.99 |
| 39 |
532168360 |
SPRING.SELECTOR.5/9POS This part replaces 532168599. Price: $3.99 |
| 40 |
532087877 |
KNOB Price: $3.99 |
| 43 |
819112206 |
WASHER.FLAT.34X1.38X22 This part replaces 819112222. Price: $4.99 |
| 44 |
532160828 |
SHOULDER BOLT Price: $3.99 |
| 45 |
532752063 |
WHEEL.14X2.PR.SP.RAD.GY Price: $69.99 |
| 46 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 532083923. Price: $3.99 |
| 47 |
532750550 |
WHEEL.8X2.PR.LP.RAD.GREY Price: $27.99 |
| 48 |
532428450 |
KIT.O-RING/WASHER This part replaces 532057143. Price: $3.99 |
| 50 |
532077400 |
CAP.HUB.BLACK.WALK Price: $4.99 |
| 51 |
596322201 |
BOLT HEXAGON BOLT 5/16-18 X 7/ This part replaces 874760514. Price: $2.99 |
| 52 |
532150406 |
BOLT 3/8-16X1-1/8 Price: $4.99 |
| 55 |
581579101 |
DECAL.CUTFINGER.CE.02 This part replaces 532107339. Price: $3.99 |
| 61 |
532851514 |
BLADE ADAPTOR Price: $7.99 |
| 62 |
532141114 |
BLADE 22" Price: $24.99 |
| 63 |
532851074 |
WASHER,HARDEN Price: $3.99 |
| 64 |
596238701 |
Washers This part replaces 532850263. Price: $3.99 |
| 65 |
532851084 |
SCREW, HEX HD 3/8-24 X 1-3/8 Price: $2.50 |
| 73 |
532186578 |
ARM.ASM.AXLE.LR/RF.5/9POS.BZP This part replaces 532168604. Price: $7.99 |
| 74 |
532751153 |
NUT.LOCK.5/16-18 Price: $2.99 |
| 75 |
532176562 |
MULCHER PLATE Price: $3.99 |
| 77 |
874760412 |
BOLT.HEX.1/4.X.3/4.DICHROMATE Price: $3.99 |
| 78 |
585161003 |
GRIP.HANDLE.FOAM.438MM This part replaces 532164265. Price: $4.99 |
| 79 |
596134901 |
GSPH This part replaces 532061537. Price: $2.99 |
| 80 |
582478602 |
NUT FLG, NYLOCK, 1/4-20 GR G C This part replaces 532132004. Price: $1.99 |
