| Ref | Part Number | Description |
|---|
| 1 |
547565001 |
SERVICE KIT DECK 38" X428 This part replaces 532411483. Price: $379.99 |
| 1 |
67-3420 |
NO. 3 PIPE ASSEMBLY Price: $83.77 |
| 2 |
67-3430 |
NUT Price: $4.57 |
| 3 |
70-8700 |
FUEL RETURN PIPE Price: $92.21 |
| 4 |
67-3440 |
GASKET Price: $7.12 |
| 5 |
110-3996 |
GAUGE-OIL LEVEL This part replaces 70-8880. Price: $108.61 |
| 6 |
529846401 |
SERVICE.KIT ARM.SUSPENSION.MOW This part replaces 532195186. Price: $14.99 |
| 6 |
93-3489 |
NOZZLE & HOLDER ASSY This part replaces 67-3380. Price: $570.51 |
| 7 |
596321701 |
Screws This part replaces 532416358. Price: $2.99 |
| 7 |
67-3390 |
GASKET Price: $4.67 |
| 8 |
110-3994 |
GUIDE This part replaces 70-8870. Price: $15.67 |
| 8 |
532193003 |
BOLT.WASHER.ASM.7/16-2 Price: $6.99 |
| 9 |
67-2300 |
GASKET Price: $3.40 |
| 10 |
67-2290 |
COVER Price: $18.48 |
| 11 |
581116302 |
BLADE.2 IN 1.38"DECK.BLACK This part replaces 532193957. Price: $14.99 |
| 11 |
67-2340 |
BOLT W/WASHER Price: $2.19 |
| 12 |
56-0020 |
EXPANSION PLUG Price: $14.38 |
| 13 |
587819701 |
KIT.MANDREL.NONGREASE.TALL This part replaces 532192872. Price: $49.99 |
| 13 |
67-2280 |
GASKET Price: $8.62 |
| 14 |
587819701 |
KIT.MANDREL.NONGREASE.TALL This part replaces 532187281. Price: $49.99 |
| 14 |
67-2230 |
OIL SEAL Price: $83.03 |
| 15 |
532110485 |
BEARING Price: $11.99 |
| 15 |
67-2270 |
CASE Price: $79.65 |
| 16 |
67-2330 |
BOLT Price: $2.25 |
| 17 |
43-2570 |
GASKET-PUMP Price: $15.12 |
| 18 |
43-2550 |
FILTER-PUMP Price: $23.30 |
| 19 |
43-2560 |
GASKET-PUMP Price: $23.14 |
| 19 |
532196539 |
BOLT.SHOULDER Price: $5.99 |
| 20 |
43-2580 |
MAGNET-PUMP Price: $12.24 |
| 21 |
53-8150 |
PUMP-FUEL Price: $680.19 |
| 21 |
596040501 |
Hardware This part replaces 873680500. Price: $2.99 |
| 22 |
67-2440 |
DISCONTINUED Price: Call Us |
| 23 |
532192557 |
BRKT.DEFLECTOR.38"2005+ Price: $7.99 |
| 23 |
67-2430 |
BRACKET Price: $156.42 |
| 24 |
532105304 |
CAP-SLEEVE LT Price: $3.99 |
| 24 |
67-2390 |
PLUG Price: $5.06 |
| 25 |
532197026 |
SPRING.TORSION.DEFLECT Price: $8.99 |
| 25 |
67-2350 |
PLUG Price: $2.53 |
| 26 |
532110452 |
NUT PUSH M Price: $2.99 |
| 26 |
67-2360 |
DISCONTINUED Price: Call Us |
| 27 |
532192572 |
SHIELD.DEFLECTOR.MOWER.38" This part replaces 532193968. Price: $32.99 |
| 27 |
67-2380 |
BUSHING Price: $3.80 |
| 28 |
56-1230 |
OIL FILTER SHAFT Price: $14.76 |
| 29 |
595297001 |
Rods This part replaces 532131491. Price: $4.99 |
| 30 |
42-9650 |
NUT-HEX, JAM Price: $0.70 |
| 30 |
584953901 |
BOLT.HEX.WASHR.HED.313-18X1.19 This part replaces 532173984. Price: $3.99 |
| 31 |
532187690 |
WASHER.SPACER.MANDREL Price: $3.99 |
| 31 |
67-4340 |
SCREEN ASSEMBLY Price: $60.41 |
| 32 |
531170001 |
SERVICE KIT PULLEY PULLEY.MAND This part replaces 532199789. Price: $17.99 |
| 32 |
67-2370 |
BUSHING Price: $4.65 |
| 33 |
42-7190 |
DISCONTINUED Price: Call Us |
| 33 |
596134801 |
Nuts This part replaces 532400234. Price: $1.00 |
| 34 |
596136101 |
GSPW Bolts This part replaces 872110612. Price: $2.99 |
| 34 |
67-2260 |
IDLER SHAFT Price: $45.97 |
| 35 |
56-0220 |
DISCONTINUED Price: Call Us |
| 36 |
67-2210 |
PLUG Price: $3.72 |
| 37 |
56-0100 |
PLUG-DRAIN Price: $6.55 |
| 37 |
596565301 |
WASHER PLAIN WASHER 3/8 X 0.08 This part replaces 819131316. Price: $2.99 |
| 39 |
67-3370 |
BOLT W/WASHER Price: $3.08 |
| 40 |
108-3841 |
FILTER-OIL This part replaces 67-4330. Price: $10.81 |
| 40 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $3.99 |
| 41 |
75-5020 |
DISCONTINUED Price: Call Us |
| 42 |
532198410 |
SPRING.TORSION.BRAKE Price: $4.99 |
| 42 |
67-3400 |
NO. 1 PIPE ASSEMBLY Price: $228.43 |
| 43 |
532197256 |
SRPING.TORSION.RETAINE Price: $4.99 |
| 46 |
532137729 |
SCREW.1/4-20X5/8 Price: $3.99 |
| 55 |
531169401 |
SERVICE KIT IDLER.ARM This part replaces 532197249. Price: $5.99 |
| 56 |
532199092 |
SPACER.RETAINER Price: $5.99 |
| 57 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 59 |
531165901 |
SERVICE KIT GUARD This part replaces 532141043. Price: $4.99 |
| 64 |
532199918 |
LINKAGE.BRAKE.ASM.ZINC Price: $11.99 |
| 67 |
532403012 |
HANDLE.CLUTCH.CABLE.LT Price: $6.99 |
| 68 |
532408381 |
V-BELT Price: $37.99 |
| 69 |
596136401 |
Bolts This part replaces 872140505. Price: $2.99 |
| 70 |
532401246 |
CLUTCH.ASM.MANUAL.LT.PRED Price: $32.99 |
| 115 |
596039401 |
BOLT ROUND HEAD SQUARE NECK BO This part replaces 872110505. Price: $2.99 |
| 116 |
596434402 |
Bolts This part replaces 532124842. Price: $3.99 |
| 117 |
589527401 |
WHEEL.GAUGE.RALLY.NARROW This part replaces 532188606. Price: $9.99 |
| 118 |
596322601 |
Nuts This part replaces 873930600. Price: $2.99 |
| 119 |
596134901 |
GSPH This part replaces 819121414. Price: $2.99 |
| 144 |
531148901 |
SERVICE.KIT KEEPER BELT KEEPER This part replaces 532193414. Price: $3.99 |
| 145 |
532177968 |
PULLEY.IDLER.FLAT This part replaces 532193197. Price: $27.99 |
| 147 |
532401872 |
SPRING RETURN Price: $4.99 |
| 152 |
532435111 |
CABLE.CLUTCH.MANUAL. Price: $29.99 |
| 188 |
593824001 |
STUD.W/"D"ANTI-ROTATION This part replaces 532195161. Price: $3.99 |
| 189 |
596135701 |
GSPW Nuts This part replaces 873900500. Price: $2.99 |
| 195 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 199 |
531170401 |
SERVICE KIT BAFFLE BAFFLE.VORT This part replaces 532400095. Price: $14.99 |
| 208 |
817670608 |
SCREW 3/8-16X1/2 Price: $3.99 |
| 209 |
596135501 |
Washers This part replaces 819133210. Price: $4.99 |
