| Ref | Part Number | Description |
|---|
| 1 |
132-5865 |
CANISTER-CARBON This part replaces 114-0289. Price: $80.55 |
| 1 |
547745901 |
KIT.SVC.DECK.WELD.46.TEX_428 This part replaces 532410863. Price: $449.99 |
| 2 |
3231-2 |
BOLT-CARR Price: $0.81 |
| 3 |
117-8399 |
STRAP-MOUNTING Price: $34.40 |
| 4 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 5 |
110-3254 |
HOSE-FUEL Price: $18.55 |
| 6 |
115-7872 |
HOSE-FUEL Price: $7.93 |
| 6 |
529846401 |
SERVICE.KIT ARM.SUSPENSION.MOW This part replaces 532195186. Price: $14.99 |
| 7 |
3254-2 |
WASHER-LOCK, INTERNAL Price: $0.27 |
| 7 |
596321701 |
Screws This part replaces 532416358. Price: $2.99 |
| 8 |
2412-80 |
CLAMP-HOSE Price: $4.39 |
| 8 |
532193003 |
BOLT.WASHER.ASM.7/16-2 Price: $6.99 |
| 9 |
133-8499 |
VALVE-CHECK, VACUUM This part replaces 115-7868. Price: $14.10 |
| 10 |
115-7871 |
HOSE-FUEL Price: $5.23 |
| 11 |
119-2965 |
STRAP-TANK Price: $32.35 |
| 12 |
323-6 |
SCREW-HH Price: $0.66 |
| 13 |
2412-98 |
CLAMP-HOSE Price: $1.39 |
| 13 |
587819701 |
KIT.MANDREL.NONGREASE.TALL This part replaces 532192872. Price: $49.99 |
| 14 |
120-5908 |
CABLE-BATTERY, NEGATIVE Price: $45.22 |
| 14 |
587819701 |
KIT.MANDREL.NONGREASE.TALL This part replaces 532187281. Price: $49.99 |
| 15 |
112-6808 |
CABLE-BATTERY, POSITIVE Price: $70.12 |
| 15 |
532110485 |
BEARING Price: $11.99 |
| 16 |
106-5190 |
BATTERY Price: $170.85 |
| 17 |
105-4886 |
NUT-TINNERMAN Price: $2.37 |
| 18 |
93-7595 |
BATTERY BOX ASM Price: $83.58 |
| 19 |
109-1395 |
HOSE-FUEL Price: $15.64 |
| 19 |
532196539 |
BOLT.SHOULDER Price: $5.99 |
| 20 |
115-9047 |
FUEL TANK ASM Price: $700.56 |
| 21 |
33114-016 |
SCREW-HH Price: $0.27 |
| 21 |
596040501 |
Hardware This part replaces 873680500. Price: $2.99 |
| 22 |
104-7102 |
PAD-BATTERY Price: $3.53 |
| 23 |
532192557 |
BRKT.DEFLECTOR.38"2005+ Price: $7.99 |
| 24 |
3339-175 |
STRAPPING-WEB This part replaces 94-1445. Price: $18.99 |
| 24 |
532105304 |
CAP-SLEEVE LT Price: $3.99 |
| 25 |
532197026 |
SPRING.TORSION.DEFLECT Price: $8.99 |
| 25 |
93-7968 |
PAD-FOAM Price: $33.52 |
| 26 |
532110452 |
NUT PUSH M Price: $2.99 |
| 27 |
532405357 |
SHIELD.DEFLECTOR.MOWER.46"BLAC Price: $49.99 |
| 29 |
595297001 |
Rods This part replaces 532131491. Price: $4.99 |
| 30 |
584953901 |
BOLT.HEX.WASHR.HED.313-18X1.19 This part replaces 532173984. Price: $3.99 |
| 31 |
532187690 |
WASHER.SPACER.MANDREL Price: $3.99 |
| 32 |
532195945 |
PULLEY.MANDREL.5.438.P This part replaces 532197473. Price: $12.99 |
| 33 |
596134801 |
Nuts This part replaces 532400234. Price: $1.00 |
| 34 |
596136101 |
GSPW Bolts This part replaces 872110612. Price: $2.99 |
| 36 |
532196106 |
PULLEY.IDLER.2006 This part replaces 532197379. Price: $34.99 |
| 37 |
596565301 |
WASHER PLAIN WASHER 3/8 X 0.08 This part replaces 819131316. Price: $2.99 |
| 38 |
589676103 |
KEEPER 42 MANDREL BELT FOR 6.2 This part replaces 532199189. Price: $6.99 |
| 40 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $3.99 |
| 42 |
532198410 |
SPRING.TORSION.BRAKE Price: $4.99 |
| 43 |
532197256 |
SRPING.TORSION.RETAINE Price: $4.99 |
| 47 |
532197250 |
BRKT.CLUTCH.CABLE Price: $4.99 |
| 55 |
531169401 |
SERVICE KIT IDLER.ARM This part replaces 532197249. Price: $5.99 |
| 56 |
532199092 |
SPACER.RETAINER Price: $5.99 |
| 57 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 59 |
531165901 |
SERVICE KIT GUARD This part replaces 532141043. Price: $4.99 |
| 63 |
532199478 |
ARM.BRAKE.ZINC This part replaces 532199477. Price: $14.99 |
| 64 |
532405139 |
LINKAGE.ASM.BRAKE.CLEAR.ZINC This part replaces 532405138. Price: $14.99 |
| 67 |
532403012 |
HANDLE.CLUTCH.CABLE.LT Price: $6.99 |
| 68 |
584453101 |
V-BELT.DRIVE.MWR.MECHANICL.46" This part replaces 532405143. Price: $49.99 |
| 69 |
596136401 |
Bolts This part replaces 872140505. Price: $2.99 |
| 70 |
532406563 |
CLUTCH.ASM.CABLE.HUSQ.TEX Price: $71.99 |
| 113 |
817000510 |
BOLT.5/16HEX.WHS.HD Price: $4.99 |
| 116 |
596434404 |
Bolts This part replaces 532193406. Price: $4.99 |
| 117 |
589527301 |
WHEEL.GAUGE.RALLY This part replaces 532174873. Price: $8.99 |
| 119 |
596134901 |
GSPH This part replaces 819132012. Price: $2.99 |
| 144 |
531169801 |
SERVICE KIT BELT KEEPER This part replaces 532199204. Price: $4.99 |
| 145 |
532177968 |
PULLEY.IDLER.FLAT This part replaces 532193197. Price: $27.99 |
| 147 |
532401872 |
SPRING RETURN Price: $4.99 |
| 152 |
532435110 |
CABLE.CLUTCH.CABLE.W/SPRING This part replaces 532408319. Price: $32.99 |
| 188 |
593824001 |
STUD.W/"D"ANTI-ROTATION This part replaces 532195161. Price: $3.99 |
| 189 |
596135701 |
GSPW Nuts This part replaces 873900500. Price: $2.99 |
| 195 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 197 |
596134901 |
GSPH This part replaces 819131312. Price: $2.99 |
| 198 |
531170601 |
SERVICE KIT BAFFLE CENT This part replaces 532403149. Price: $9.99 |
| 200 |
596135501 |
Washers This part replaces 532413524. Price: $4.99 |
| 240 |
596564404 |
Bolts This part replaces 874520636. Price: $2.99 |
| 241 |
532152927 |
SCREW.TT.#10-32X.5.3/8.FLANGE Price: $3.99 |
| 242 |
532415598 |
PORT.WASHOUT Price: $6.99 |
| 587819701 |
KIT.MANDREL.NONGREASE.TALL |
This part replaces 532192870. Price: $49.99 587819701 |
