| Ref | Part Number | Description |
|---|
| 1 |
3231-22 |
SCREW-CARR Price: $0.72 |
| 1 |
532419888 |
V-BELT.IMPELLER Price: $49.99 |
| 2 |
532427304 |
TRACTION BELT Price: $17.99 |
| 2 |
93-5137 |
LEVER-TRACTION Price: $126.70 |
| 3 |
2411-36 |
BEARING-END, ROD Price: $32.13 |
| 3 |
584232402 |
ARM.IDLER BRAKE.CLEAR.ZINC This part replaces 532423723. Price: $12.99 |
| 4 |
3220-3 |
NUT-HJ Price: $0.28 |
| 4 |
594095301 |
Pulleys This part replaces 532180523. Price: $9.99 |
| 5 |
532423990 |
RP.BRACKET.IDLER.PIVOT.BLACK Price: $4.99 |
| 5 |
93-5173-03 |
TUBE-CONTROL This part replaces 93-5173. Price: $56.18 |
| 6 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 6 |
585802801 |
NUT.HEX.FL 5/16-18 TOP LCK BLK This part replaces 532426589. Price: $4.99 |
| 7 |
3290-355 |
PIN-HAIR Price: $2.09 |
| 7 |
596582201 |
Bolts This part replaces 874780524. Price: $2.99 |
| 8 |
532424297 |
BOLT.SHOULDER.1/2X12 Price: $3.99 |
| 8 |
93-5486 |
DISCONTINUED Price: Call Us |
| 9 |
23-2270 |
BUSHING-RUBBER Price: $17.07 |
| 9 |
532751153 |
NUT.LOCK.5/16-18 Price: $2.99 |
| 10 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 Price: $4.99 |
| 10 |
93-5488 |
POST - HUB Price: $51.49 |
| 11 |
532427577 |
ARM.ASM.TRACTION.IDLER This part replaces 532427576. Price: $17.99 |
| 11 |
93-5175-03 |
DISCONTINUED This part replaces 93-5175. Price: Call Us |
| 12 |
121-4600 |
NUT-HEX This part replaces 3296-59. Price: $0.78 |
| 12 |
532180522 |
PULLEY.W/SPACER.2.25 Price: $22.99 |
| 13 |
33024-00 |
NUT-LOCK, NI Price: $0.75 |
| 13 |
532059289 |
STEEL WASHER Price: $3.99 |
| 14 |
33104-050 |
SCREW-HHF Price: $1.70 |
| 14 |
596040501 |
Hardware This part replaces 873800500. Price: $2.99 |
| 15 |
595305701 |
Screws This part replaces 874780520. Price: $3.99 |
| 15 |
93-5347 |
ABRASIVE-PEDAL Price: $12.38 |
| 16 |
532851084 |
SCREW, HEX HD 3/8-24 X 1-3/8 Price: $2.50 |
| 16 |
93-5368 |
ABRASIVE-PEDAL Price: $9.23 |
| 17 |
819132005 |
WASHER.400X1.25X5. Price: $5.99 |
| 17 |
93-5133-01 |
PEDAL-TRACTION This part replaces 93-5133. Price: $132.14 |
| 18 |
3217-6 |
NUT-HEX Price: $1.19 |
| 18 |
532425934 |
PULLEY ENG IMPELLER Price: $29.99 |
| 19 |
33113-016 |
SCREW-HH Price: $0.34 |
| 19 |
532425933 |
PULLEY.ASM.ENG.TRACTION.1.00 Price: $22.99 |
| 20 |
32141-36 |
SCREW-ADJUSTMENT, LEVEL Price: $12.75 |
| 20 |
874610516 |
SCREW Price: $3.99 |
| 21 |
256-10 |
BUSHING-FLANGE Price: $3.68 |
| 21 |
596238801 |
WASHER SPRING LOCK WASHER WITH This part replaces 810040500. Price: $2.99 |
| 22 |
532155452 |
BELT.GUIDE.RH Price: $4.99 |
| 22 |
93-5129-03 |
BRACKET-PEDAL ASM This part replaces 93-5129. Price: $99.35 |
| 23 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 23 |
596238801 |
WASHER SPRING LOCK WASHER WITH This part replaces 811050500. Price: $2.99 |
| 24 |
33003-00 |
NUT-HF Price: $0.25 |
| 24 |
587343701 |
BUSHING.BRAKE.ARM This part replaces 532175331. Price: $5.99 |
| 25 |
819112206 |
WASHER.FLAT.34X1.38X22 Price: $4.99 |
| 26 |
874610520 |
CAPSCREW.HEXHD.5/16X1.25. Price: $7.99 |
