| Ref | Part Number | Description |
|---|
| 1 |
108-8573 |
DISCONTINUED Price: Call Us |
| 3 |
108-8531-03 |
COVER-BELT, RH Price: $55.20 |
| 4 |
29-5590-03 |
BRACKET-PIVOT Price: $23.25 |
| 5 |
40-6230 |
SPRING Price: $37.99 |
| 6 |
126-2928 |
KIT, ANTI-SCALP ROLLER AXLE This part replaces 99-2842. Price: $18.59 |
| 7 |
1-603299 |
ROLLER-SCALP, ANTI Price: $21.99 |
| 8 |
323-16 |
SCREW-HH Price: $2.89 |
| 9 |
3230-18 |
SCREW-CARR Price: $4.09 |
| 10 |
94-1581-01 |
DEFLECTOR/DECAL ASM-INTL This part replaces 94-1581. Price: $230.54 |
| 11 |
3211-15 |
SCREW-HH Price: $7.99 |
| 12 |
3296-5 |
NUT-HEX Price: $3.09 |
| 13 |
67-2150-03 |
BAFFLE Price: $356.99 |
| 14 |
1-373034 |
WASHER Price: $3.19 |
| 15 |
46-8560 |
SCREW-HHFTF Price: $1.79 |
| 16 |
3230-18 |
SCREW-CARR Price: $4.09 |
| 17 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 18 |
29-4820 |
ROLLER Price: $14.88 |
| 19 |
3290-357 |
NUT-HHF, WHIZ Price: $0.61 |
| 20 |
98-5975 |
WASHER-BELLEVILLE Price: $3.09 |
| 21 |
94-2500 |
TUBE-SPACER, WHEEL Price: $3.39 |
| 22 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 25 |
1-806005 |
PIN-COTTER Price: $2.39 |
| 26 |
100-7338 |
CLEVIS Price: $57.99 |
| 27 |
104-3634 |
PIN-CLEVIS Price: $18.99 |
| 28 |
3220-5 |
NUT-JAM Price: $0.65 |
| 29 |
131-3945 |
ROD-MOUNT, DECK This part replaces 104-8047. Price: $28.01 |
| 30 |
104-3699-01 |
LINK-HOC, ADJUSTING Price: $41.22 |
| 31 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 32 |
3296-16 |
NUT-LOCK, NI Price: $1.39 |
| 33 |
46-6290 |
O-RING Price: $2.59 |
| 34 |
3256-1 |
WASHER-FLAT Price: $0.39 |
| 35 |
133-9289 |
FITTING-WASHOUT This part replaces 95-2747. Price: $3.86 |
| 36 |
3229-1 |
BOLT-CARR Price: $3.39 |
