| Ref | Part Number | Description |
|---|
| 1 |
70-06-050 |
BOSS ADAPT 1.1/16-3/4" Price: $6.81 |
| 2 |
15-06-109 |
ADAPTER Price: $19.13 |
| 3 |
587044541 |
HOSE 3/16" VAPOR LINE 41" LENG Price: $5.99 |
| 4 |
111-9107 |
FITTING-STRAIGHT Price: $7.60 |
| 4 |
587044507 |
HOSE 3/16" VAPOR LINE 7" LENGT Price: $2.99 |
| 5 |
587044517 |
HOSE.3/16".VAPOR.LINE.17"LGTH Price: $7.99 |
| 6 |
111-6853-03 |
ADJUSTER-DAMPER Price: $5.59 |
| 6 |
587044841 |
HOSE 1/4" LOW PERMEATION FUEL Price: $9.99 |
| 7 |
09565 |
BOLT M8 X 55 HEX HD ZN & PASS Price: $1.40 |
| 8 |
111-6456-03 |
BRACKET-CONTROL, PUMP Price: $64.10 |
| 8 |
587044824 |
HOSE.1/4".LOW.PERM.FUEL.LN.24" Price: $6.99 |
| 9 |
574206602 |
TEE, FUEL LINE 3/16" Price: $2.99 |
| 10 |
575018103 |
CAP 3.5IN SEALED This part replaces 575018101. Price: $27.99 |
| 11 |
582483301 |
GUARD.MUD.LH Price: $64.99 |
| 12 |
134-6260 |
DAMPER KIT This part replaces 111-9548. Price: $122.55 |
| 12 |
590638801 |
SENSOR.FUEL.LVL.FLOAT.V500 Price: $139.99 |
| 13 |
111-6814 |
LEVER-CONTROL, PUMP Price: $45.10 |
| 13 |
576618101 |
VALVE.FUEL.CHECK Price: $14.99 |
| 14 |
111-3336 |
NUT BAR - PROXIMITY SWITCH Price: $12.26 |
| 14 |
539102679 |
FUEL VALVE Price: $49.99 |
| 15 |
09273 |
WASHER 3/8 SC SPRING Price: $1.39 |
| 15 |
525865402 |
TUBE.ASM.FUEL.TANK.PICK-UP.LH Price: $11.99 |
| 16 |
532003645 |
BUSHING OUTLET T Price: $3.99 |
| 17 |
590209101 |
GROMMET, FUEL SENSOR Price: $4.99 |
| 18 |
09441 |
NUT M8 NYL INSERT T TYPE Price: $1.39 |
| 18 |
584648201 |
GROMMET.CHECK.FUEL Price: $3.99 |
| 19 |
105-0023 |
SWITCH-PROXIMITY Price: $134.88 |
| 19 |
582481502 |
BRACKET.FUEL.TANK.REAR.SUP.431 Price: $34.99 |
| 20 |
111-8424 |
PUMP-TANDEM Price: $750.97 |
| 20 |
582481602 |
BRACKET.FUEL.TANK.REAR.SUP.431 Price: $19.99 |
| 21 |
536147601 |
COVER.CONSOLE.LH.FUEL.TANK This part replaces 582483401. Price: $37.99 |
| 22 |
ZDH1L035U |
HEX.HD.SET SCW.M12*35 Price: $1.38 |
| 23 |
575436501 |
CLAMP, HOSE Price: $2.99 |
| 23 |
ZDH1E020U |
HEX HD SET SCREW M5*20 Price: $1.31 |
| 24 |
03162 |
STEEL BOLT Price: $1.39 |
| 24 |
582482601 |
CLIP.U-TYPE Price: $3.99 |
| 25 |
HY103653 |
SETSCREW Price: $1.36 |
| 26 |
111-3676 |
SPACER PROXIMITY SWITCH Price: $1.72 |
| 26 |
874490548 |
BOLT HEX FLGHD 5/16-18X3 GR. 5 Price: $4.99 |
| 27 |
111-3260-03 |
ADJUSTER - SWITCHES Price: $11.05 |
| 27 |
590257301 |
SCREW.1/4-20X1.5IN.HEX.MACH Price: $2.99 |
| 28 |
593337201 |
SCREW HEXAGON HEAD WITH COLLAR This part replaces 817490516. Price: $2.99 |
| 29 |
582484201 |
SCREW.5/16-18X1.25"THREADED Price: $2.99 |
| 30 |
111-8723 |
PUMP-TRANSMISSION Price: $2,074.36 |
| 30 |
594944401 |
NUT HEXAGON FLANGE 5/16-18 ST This part replaces 539112899. Price: $5.99 |
| 31 |
09599 |
WASHER Price: $1.42 |
| 31 |
596582301 |
Washers This part replaces 532126684. Price: $2.99 |
| 32 |
09644 |
WASHER SPRING Price: $1.40 |
| 32 |
587044803 |
HOSE.1/4".LOW.PERM.FUEL.LN.3" Price: $2.99 |
| 33 |
09475 |
WASHER M8 X 17 X 1.6 ZN & PASS Price: $1.40 |
| 34 |
HY09485 |
WASHER M12 PLAIN Price: $1.40 |
| 35 |
09257 |
WASHER 3/16 X 1/2 X 17G PLATED Price: $1.40 |
| 39 |
70-06-028 |
O RING (70-06-001) Price: $29.30 |
| 41 |
HY03355 |
WASHER 3/8 X 7/8 X 15G PLATED Price: $1.49 |
| 53 |
65-01-559 |
WASHER-SPACE Price: $12.73 |
| 54 |
09267 |
WASHER 5/16 X 7/8 X 15G GALV Price: $1.39 |
| 56 |
950726 |
ADAPTOR-BSP Price: $3.73 |
| 63 |
70-06-066 |
BOSS ADAPT 1.1/16-1/2" Price: $9.32 |
| 64 |
111-9766 |
FITTING-ELBOW, 90 Price: Call Us |
| 65 |
111-9111 |
FITTING-CHECK Price: Call Us |
| 66 |
111-9168 |
SCREW-SH Price: Call Us |
| 525865403 |
TUBE.ASM.FUEL.TANK.PICK-UP.RH |
Price: $11.99 525865403 |
| 536147501 |
COVER.CONSOLE.RH.FUEL.TANK |
This part replaces 582482401. Price: $44.99 536147501 |
| 582482301 |
GUARD.MUD.RH |
Price: $69.99 582482301 |
