SEAT
Parts (13)
| Ref | Part Number | Description |
|---|---|---|
| 1 | 573995003 | SEAT BRACKET Price: $49.99 |
| 2 | 117-5115 | HUB AND BEARING ASM Price: $163.75 |
| 3 | 117-8259 | WASHER-SPINDLE Price: $2.71 |
| 3 | 734117441 | WASHER Price: $3.99 |
| 4 | 117-8260 | NUT Price: $19.27 |
| 4 | 725249371 | Screw M10x25 Price: $1.82 |
| 5 | 587605301 | SEAT ASSY KIT LOW HVA This part replaces 544433301. Price: $179.99 |
| 5 | 93-0307 | NUT-LOCK, RETAINER Price: $3.36 |
| 6 | 585065201 | KNOB This part replaces 506565501. Price: $17.99 |
| 7 | 506565301 | WASHER Price: $4.99 |
| 8 | 734116441 | SPACER Price: $3.99 |
| 9 | 506556301 | BOLT Price: $3.99 |
| 11 | 506597401 | BOLT Price: $5.99 |
