TRANSMISSION 4
Parts (37)
| Ref | Part Number | Description |
|---|---|---|
| 1 | 127-3075 | FUEL/OIL FILTER ASM Price: $238.05 |
| 1 | 506985803 | SPINDLE Price: $179.99 |
| 2 | 127-3076 | FUEL/OIL FILTER BRACKET ASM Price: $104.97 |
| 2 | 738210504 | Ball Bearing 6005-2rs Price: $28.99 |
| 3 | 125-8752 | FILTER-FUEL/OIL Price: $96.10 |
| 3 | 738211004 | BALL BEARING 6010 2RS1 Price: $39.99 |
| 4 | 125-7216 | BOLT Price: $3.48 |
| 4 | 735314010 | CIRCLIP SGH 47 Price: $4.99 |
| 5 | 127-3091 | LIFTER-ENGINE Price: $4.94 |
| 6 | 127-3105 | STAY-BRACKET, FILTER Price: $138.74 |
| 6 | 506985901 | SHAFT Price: $44.99 |
| 7 | 125-7215 | BOLT Price: $3.48 |
| 7 | 735312600 | RETAINING RING SGA 25 Price: $2.99 |
| 8 | 125-7216 | BOLT Price: $3.48 |
| 8 | 506773401 | WASHER Price: $3.99 |
| 9 | 127-3077 | FUEL PIPE ASM Price: $97.23 |
| 9 | 740681421 | V-RING Price: $3.99 |
| 10 | 535406001 | BRACKET Price: $299.99 |
| 11 | 506986102 | BUSHING Price: $14.99 |
| 12 | 125-7191 | CLAMP-HOSE Price: $15.78 |
| 13 | 127-2981 | BAND Price: Call Us |
| 14 | 138-7845 | RETURN PIPE ASM This part replaces 127-3120. Price: $253.71 |
| 16 | 127-3172 | CLAMP-HOSE Price: $5.74 |
| 17 | 127-3078 | FUEL PIPE ASM Price: $124.55 |
| 20 | 125-7191 | CLAMP-HOSE Price: $15.78 |
| 21 | 127-3119 | FUEL PIPE ASM Price: $258.51 |
| 22 | 127-2950 | CLIP-HOSE Price: $6.01 |
| 25 | 127-3087 | BAND-CLIP Price: $2.45 |
| 26 | 127-3079 | FUEL PIPE ASM Price: $82.85 |
| 27 | 127-2950 | CLIP-HOSE Price: $6.01 |
| 27 | 506987701 | BRACKET Price: $11.99 |
| 28 | 506566501 | CLAMP Price: $2.99 |
| 29 | 725236461 | SCREW Price: $2.99 |
| 30 | 125-6900 | LABEL-CAUTION, FUEL OIL Price: $5.51 |
| 46 | 506889901 | DRAW RING Price: $17.99 |
| 47 | 725250071 | SCREW This part replaces 725250051. Price: $2.99 |
| 48 | 953534901 | WEIGHT/ REAR BUMPER KIT This part replaces 544039602. Price: $179.00 |
