| Ref | Part Number | Description |
|---|
| 1 |
11-6350 |
DISCONTINUED Price: Call Us |
| 2 |
23-2100 |
DISCONTINUED Price: Call Us |
| 2 |
462917 |
Hood Assy., STTII (Kubota Diesel) Price: Call Us |
| 3 |
04009-07 |
Bolt, Shoulder 5/16-18 x 1/2" Price: Call Us |
| 3 |
21-3600 |
FOAM-SUPPORT, TANK Price: $25.75 |
| 4 |
424633 |
Latch, Hood Price: Call Us |
| 4 |
43-9110 |
GAS TANK ASM Price: $439.33 |
| 5 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 5 |
483507 |
Spring, Hood Latch Price: Call Us |
| 6 |
3274-51 |
SCREW-HSH Price: $0.41 |
| 6 |
424634 |
Lock, Hood Latch Price: Call Us |
| 7 |
04040-05 |
Flatwasher, 3/8 (.406 x .812 x .065) Price: Call Us |
| 7 |
37-9550 |
STRAP-TANK, FUEL Price: $46.74 |
| 8 |
04001-21 |
Bolt, Hex Head 3/8-16 x 1-3/4" (Kohler EFI) Price: Call Us |
| 8 |
3272-13 |
PIN-COTTER Price: $0.25 |
| 9 |
04041-07 |
Flatwasher, 3/8" Special (.391 x .938 x .105) Price: Call Us |
| 9 |
10-8110 |
WASHER-THRUST Price: $1.09 |
| 10 |
427561 |
Guard, Muffler Price: Call Us |
| 10 |
43-9060 |
DISCONTINUED Price: Call Us |
| 11 |
04117-01 |
Nut, Flange Head Elastic Stop 5/16-18 Price: Call Us |
| 11 |
32144-34 |
SCREW-HWHTF Price: $4.19 |
| 12 |
04110-01 |
Bolt, Hex Head 3/8-16 x 1" Price: Call Us |
| 12 |
62-7650 |
GASKET This part replaces 18-2380. Price: $4.28 |
| 13 |
353-536 |
DISCONTINUED Price: Call Us |
| 13 |
483811 |
Muffler, Kubota Price: Call Us |
| 14 |
108-3282 |
HOSE-FUEL This part replaces 37-9560. Price: $36.93 |
| 14 |
483471 |
Disc, Anti-Friction Price: Call Us |
| 15 |
2412-36 |
CLAMP-HOSE Price: $1.28 |
| 15 |
43740 |
Spacer, Hood Price: Call Us |
| 16 |
04041-11 |
Flatwasher, 3/8-.406 x 1-1-1/2 x 7 Gauge Price: Call Us |
| 16 |
37-9540 |
DISCONTINUED Price: Call Us |
| 17 |
04021-09 |
HEX NUT, ELASTIC STOP LOCK, 3/8-16 Price: Call Us |
| 17 |
321-6 |
SCREW-HH Price: $0.25 |
| 18 |
04019-03 |
Nut, Serrated Flange 5/16-18 (Right Front Engine Mounting, Briggs and Kohler Only) Price: Call Us |
| 18 |
23-2080 |
DISCONTINUED Price: Call Us |
| 19 |
256-237 |
BUSHING Price: $14.99 |
| 19 |
483387 |
Gasket, Muffler Price: Call Us |
| 20 |
22-7810 |
SPACER Price: $16.90 |
| 20 |
424452 |
Plate, Rear Engine Mount Price: Call Us |
| 21 |
04001-19 |
Bolt, Hex Head, 3/8-16 x 1 Gr. 5 Price: Call Us |
| 21 |
21-3610 |
FOAM-SUPPORT, TANK Price: $20.11 |
| 22 |
04030-03 |
Lockwasher, 5/16 (.317 x .586 x .078) Helical Spring Price: Call Us |
| 22 |
2412-41 |
CLAMP-R Price: $4.82 |
| 23 |
04002-12 |
Bolt, Metric Hex Head M8-1.25 x 20LG Price: Call Us |
| 23 |
110-4100 |
HOSE-FUEL This part replaces 23-2140. Price: $28.86 |
| 24 |
2412-6 |
CLAMP-HOSE Price: $4.57 |
| 24 |
482334 |
Stub Shaft, (Kubota) Price: Call Us |
| 25 |
3230-2 |
BOLT-CARR Price: $0.47 |
| 25 |
426054 |
Bracket, Belt Guide Price: Call Us |
| 26 |
04003-12 |
Bolt, 5/16-18 x .75 RHSN Carriage Price: Call Us |
| 26 |
42-6080 |
SHIM-AXLE Price: $29.45 |
| 27 |
231-101 |
TIRE (23X8.5-12) 4-PLY TURF SAVER Price: $147.85 |
| 27 |
427071 |
Cover, Rear Price: Call Us |
| 28 |
23-7270 |
NUT-LUG Price: $10.37 |
| 28 |
424485 |
Bracket, Control Mount Price: Call Us |
| 29 |
217-105 |
DISCONTINUED X-REF Price: Call Us |
| 29 |
424580 |
Clamp Price: Call Us |
| 30 |
04011-06 |
SCREW, 10-32 X 3/4" SELF TAP Price: Call Us |
| 30 |
5108 |
VALVE This part replaces 232-27. Price: $6.29 |
| 31 |
427137 |
Plate, Engine Mount RH Price: Call Us |
| 31 |
43-7630 |
AXLE WA *RO Price: $4,368.18 |
| 32 |
04019-04 |
NUT, 3/8-16 SERRATED FLANGE HEX HEAD Price: Call Us |
| 32 |
3234-15 |
SCREW-HHF Price: $1.97 |
| 33 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 33 |
483351 |
Mount, Engine Isolation Price: Call Us |
| 34 |
3217-6 |
NUT-HEX Price: $1.19 |
| 34 |
427136 |
Plate, Engine Mount LH Price: Call Us |
| 35 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 35 |
452886 |
Pump Mounting Plate Weldment (Diesel) Price: Call Us |
| 36 |
04025-02 |
Nut, Metric Hex M8-1.25mm Price: Call Us |
| 36 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 37 |
2811-9 |
FITTING-ELBOW-90 Price: $15.86 |
| 37 |
452792 |
Mounting Bracket Weldment RH Price: Call Us |
| 38 |
04030-05 |
Lockwasher, 7/16” Spring Price: Call Us |
| 38 |
289-37 |
NIPPLE-PIPE Price: $21.68 |
| 39 |
04002-10 |
Bolt, Metric Hex Head M10-1.25 x 25LG Price: Call Us |
| 39 |
23-5180 |
DIPSTICK ASM Price: $69.61 |
| 40 |
32104-6 |
SCREW-HH, TAP Price: $3.19 |
| 40 |
484069 |
ISO Mount, Upper Radiator Price: Call Us |
| 41 |
452791 |
Mounting Bracket Weldment LH Price: Call Us |
| 42 |
483360 |
Temperature Sensor, Engine Coolant Price: Call Us |
| 43 |
481811 |
Sender Unit, Oil Pressure Price: Call Us |
| 44 |
04002-01 |
Bolt, Metric Hex Head M8-1.25 x 30LG Price: Call Us |
| 45 |
453112 |
Battery Bracket Weldment (Diesel Only) Price: Call Us |
| 46 |
463320 |
Battery Box w/Decal (Diesel Only) Price: Call Us |
| 47 |
428257 |
Cover, Battery (Diesel Only) Price: Call Us |
| 48 |
485698-01 |
Knob, 1/4" Wing Price: Call Us |
| 49 |
04001-221 |
Bolt, Hex Head 1/4-20 x 8" Price: Call Us |
| 50 |
48661 |
PAD, BATTERY SUPPORT Price: Call Us |
| 51 |
04017-17 |
Cpscrw, 5/16-18 x 1"Serrated Flange Hex Head Price: Call Us |
| 52 |
427140 |
Bracket, Air Cleaner Mount Price: Call Us |
| 53 |
485322 |
Air Filter Assembly (Enginaire p/n 67150) Price: Call Us |
| 54 |
484697 |
Hose, Air Intake Price: Call Us |
| 55 |
48136-25 |
Clamp, 2-3/4" Max. Dia. Price: Call Us |
| 56 |
463423 |
Debris Screen Assembly (With Upper Foam) Price: Call Us |
| 57 |
04002-20 |
Bolt, Metric Hex Hd. M6-1.0 x 30mm Price: Call Us |
| 58 |
04030-02 |
Lockwasher, 1/4†Spring Price: Call Us |
| 59 |
43714 |
Spacer, Radiator Price: Call Us |
| 60 |
04106-01 |
Capscrew, Metric M6-1.0 x 16mm Price: Call Us |
| 61 |
424623 |
Debris Screen Track RH Price: Call Us |
| 62 |
424624 |
Debris Screen Track LH Price: Call Us |
| 63 |
483928 |
ISO Mount, Lower Radiator Price: Call Us |
| 64 |
04111-04 |
Nut, Metric Serr. Flng. M8 x 1.25 Price: Call Us |
| 65 |
04025-01 |
Nut, Metric Hex M6 x 1 Price: Call Us |
| 66 |
04040-04 |
Flatwasher, 5/16-.344 x .688 x .065 (48V / 52V) Price: Call Us |
| 67 |
04002-03 |
Bolt, Metric Hex Head M8-1.25 x 25LG Price: Call Us |
| 79 |
04001-21 |
Bolt, Hex Head 3/8-16 x 1-3/4" (Kohler EFI) Price: Call Us |
| 80 |
04117-02 |
Nut, Flange Elastic Stop Nut, 3/8-16 Price: Call Us |
| 81 |
463417 |
Heatshield Assembly, Air Filter Price: Call Us |
| 82 |
463418 |
Heatshield Assembly, Engine Price: Call Us |
| 481780 |
Insulation, |
Battery Cover Price: Call Us 481780 |
| 485846 |
BUMPER, |
PLUG Price: Call Us 485846 |
