| Ref | Part Number | Description |
|---|
| a |
None |
Choke Shaft |
| aa |
None |
Float Bowl |
| b |
None |
Gasket |
| bb |
951-14676 |
FUEL SOLENOID Price: $35.82 |
| c |
None |
Choke Spring |
| cc |
None |
O-Ring, Solenoid Valve Seat |
| d |
None |
Washer |
| dd |
951-11349A |
FUEL DRAIN PLUG GASKET This part replaces 951-11349. Price: $3.66 |
| e |
None |
Choke Plate |
| ee |
710-04938 |
FUEL DRAIN PLUG Price: $3.66 |
| f |
None |
Idle Jet |
| ff |
None |
O-Ring, Solenoid Valve Seat |
| g |
None |
O-Ring, 4x1.8G |
| h |
None |
Throttle Shaft Sleeve |
| i |
None |
Throttle Shaft |
| j |
None |
Throttle Plate |
| k |
None |
Screw, M3x5 |
| l |
736-04638A |
LOCK WASHER This part replaces 736-04638. Price: $2.88 |
| m |
None |
Gasket, Throttle Shaft |
| n |
None |
Gasket |
| o |
None |
Idle Adjusting Screw |
| p |
None |
Idle Jet Rivet |
| q |
None |
Carburetor Body |
| r |
None |
Fuel Nipple |
| s |
None |
Float Pin |
| t |
None |
Nozzle Tube |
| u |
None |
Needle Valve |
| v |
None |
Main Jet |
| w |
None |
Needle Valve Spring |
| x |
731P09132A |
FLOAT Price: $4.45 |
| y |
951-11970 |
FUEL BOWL GASKET Price: $5.95 |
| z |
None |
Seal |
| 1 |
710-05316 |
BOLT M6 x 22 Price: $3.56 |
| 2 |
951-12266 |
VALVE COVER Price: $23.04 |
| 3 |
951-12267 |
VALVE COVER RINGER GASKET Price: $8.12 |
| 4 |
951-11981A |
ROCKER ARM ASSEMBLY This part replaces 951-11981. Price: $35.16 |
| 5 |
951-12268 |
PUSH ROD GUIDE Price: $6.42 |
| 6 |
951-12269 |
EXHAUST VALVE ADJUSTER Price: $5.48 |
| 7 |
951-14912A |
VALVE CAP This part replaces 951-14912. Price: $3.03 |
| 8 |
951-14911A |
VALVE SPRING SEAT This part replaces 951-14911. Price: $4.64 |
| 9 |
951-12078 |
VALVE SPRING Price: $3.49 |
| 10 |
951-11964A |
INTAKE VALVE SEAL This part replaces 951-11964. Price: $9.96 |
| 11 |
951-15776 |
EXHAUST VALVE Price: $19.60 |
| 12 |
951-15777 |
INTAKE VALVE Price: $17.52 |
| 13 |
710-06065 |
SCREW M10-1.25 x 65 x GR10.9 Price: $5.53 |
| 14 |
710-06064 |
SCREW M10-1.25 x 87 x GR10.9 Price: $5.72 |
| 15 |
951-12253 |
SCREW JOINT OIL FILTER ADAPTER Price: $6.87 |
| 16 |
951-12690 |
ENGINE OIL FILTER Price: $15.89 |
| 17 |
710-04916 |
BOLT M6-1 x 14 GR8.8 Price: $3.86 |
| 18 |
751-15427 |
NUT M8 Price: $3.64 |
| 19 |
951-12271 |
EXHAUST PIPE MUFFLER GASKET Price: $5.48 |
| 20 |
951-14459 |
MUFFLER STUD M8 x 47 Price: $6.02 |
| 21 |
951-10292A |
SPARK PLUG (F6RTC/RN11YC/BPR6ES) This part replaces 951-10292. Price: $6.35 |
| 22 |
None |
Cylinder Head |
| 23 |
951-12264 |
CARBURETOR STUD Price: $5.48 |
| 24 |
951-12263 |
CARBURETOR INSULATER GASKET Price: $3.60 |
| 25 |
951-12262 |
CARBURETOR INSULATOR Price: $9.02 |
| 26 |
951-12261 |
CARBURETOR GASKET Price: $3.60 |
| 27 |
951-05559 |
CARBURETOR ASSEMBLY - HY-8P92 Price: $129.78 |
| 28 |
951-12258A |
MANIFOLD GASKET-ADD AIR HOLE Price: $3.60 |
| 29 |
951-15440 |
INTAKE MANIFOLD Price: $26.84 |
| 30 |
712-05015 |
HEX NUT Price: $5.78 |
| 31 |
710-06290 |
BOLT M5-.8 x 10 Price: $4.31 |
| 32 |
951-15772 |
CARBURETOR SHIELD BRACKET Price: $6.53 |
| 33 |
951-12265 |
COWL SHIELD Price: $24.06 |
| 34 |
951-15444 |
SEAL Price: $5.48 |
| 35 |
937-05122 |
AIR FILTER Price: $22.25 |
| 36 |
712-05227 |
WING NUT Price: $4.11 |
| 37 |
931-05081B |
Air Filter Cover Assembly This part replaces 931-05081A. Price: $22.83 |
| 38 |
951-11700A |
CARBURETOR HOSE CLAMP This part replaces 951-11700. Price: $3.60 |
| 39 |
951-14091 |
PLUG Price: $4.09 |
| 40 |
935-05087 |
FUEL HOSE 6.3X12X290 Price: $9.78 |
| 41 |
723-04071A |
FUEL LINE SUPPORT CLAMP This part replaces 723-04071. Price: $2.77 |
| 42 |
951-15773 |
CYLINDER HEAD GASKET Price: $24.59 |
| 43 |
715-04122 |
DOWEL PIN Price: $3.52 |
| 44 |
951-14226A |
PUSH ROD This part replaces 951-14226. Price: $9.70 |
| 45 |
951-11962A |
TAPPET This part replaces 951-11962. Price: $5.88 |
| 46 |
951-05566 |
PISTON RING SET Price: $24.59 |
| 47 |
951-15774 |
PISTON Price: $38.76 |
| 48 |
911-06415 |
PISTON PIN Price: $8.96 |
| 49 |
951-11953A |
PISTON PIN SNAP RING This part replaces 951-11953. Price: $3.42 |
| 50 |
951-15775 |
CONNECTING ROD ASSEMBLY Price: $35.11 |
| 51 |
712-04276A |
ACORN NUT M6-1 This part replaces 712-04276. Price: $5.38 |
| 52 |
931-10840 |
BLOWER HOUSING SCREEN Price: $22.95 |
| 53 |
710-05303 |
BOLT 5.5 x 25 Price: $3.56 |
| 54 |
951-12205 |
DEBRIS SHIELD Price: $9.07 |
| 55 |
951-14128B |
ENGINE SHROUD Price: $52.45 |
| 56 |
710-05305 |
HOOK BOLT Price: $3.56 |
| 57 |
710-05304 |
STARTER/SHROUD STUD M6 x 100 Price: $3.32 |
| 58 |
712-05169 |
FLYWHEEL NUT M16X1.5 Price: $7.30 |
| 59 |
951-12221 |
FAN MOUNTING PLATE Price: $9.58 |
| 60 |
951-12222B |
COOLING FAN Price: $49.32 |
| 61 |
710-04968 |
BOLT M6 x 16 Price: $5.77 |
| 62 |
951-15778 |
FLYWHEEL Price: $202.84 |
| 63 |
710-04943 |
BOLT-M6-1 x 28 GR8.8 Price: $3.76 |
| 64 |
951-15779 |
CHARGING COIL Price: $86.04 |
| 65 |
951-11622A |
FLEXIBLE CLAMP This part replaces 951-11622. Price: $3.42 |
| 66 |
951-12220 |
IGNITION COIL ASSEMBLY Price: $77.48 |
| 67 |
710-04914 |
BOLT M6-1 x 10 GR8.8 Price: $3.71 |
| 68 |
951-12279 |
COWL COVER SHIELD Price: $12.93 |
| 69 |
951-11375A |
OIL SEAL This part replaces 951-11375. Price: $13.55 |
| 70 |
951-12770A |
BREATHER COVER PLATE Price: $6.79 |
| 71 |
951-12226 |
BREATHER GASKET Price: $4.45 |
| 72 |
951-12685 |
BREATHER VALVE Price: $5.15 |
| 73 |
951-12227 |
MESH SCREEN FILTER Price: $4.95 |
| 74 |
951-12686 |
BREATHER VALVE BASE Price: $5.15 |
| 75 |
710-05306 |
BOLT M8 x 40 Price: $3.56 |
| 76 |
951-15920 |
REGULATOR ASSEMBLY Price: $120.63 |
| 77 |
951-15781 |
STUD - M8-6 x 58 Price: $4.34 |
| 78 |
751P12207A |
STARTER ASSEMBLY This part replaces 951-12207. Price: $197.22 |
| 79 |
715-04120 |
DOWEL PIN Price: $3.56 |
| 80 |
919-05241 |
CRANKCASE Price: $275.04 |
| 81 |
951-12235 |
BREATHER HOSE ASSEMBLY Price: $12.06 |
| 82 |
750-05530 |
COMPONENT BRACKET SPACER Price: $3.32 |
| 83 |
951-15513 |
COMBINATION CONTROL BRACKET ZS Price: $24.76 |
| 84 |
710-05310 |
BOLT M6 x 38 Price: $3.32 |
| 85 |
710-05003A |
BOLT M6-1 x 18 This part replaces 710-05003. Price: $3.11 |
| 86 |
932-05187 |
GOVERNOR SPRING Price: $5.42 |
| 87 |
951-12231 |
THROTTLE LINKAGE SPRING Price: $3.68 |
| 88 |
951-12228 |
CHOKE LINKAGE ROD Price: $3.60 |
| 89 |
951-12230 |
THROTTLE LINKAGE ROD Price: $3.56 |
| 90 |
947-06356 |
GOVERNOR ARM SHAFT Price: $20.61 |
| 91 |
736-04558 |
GOVERNOR WASHER Price: $3.35 |
| 92 |
951-11902A |
OIL SEAL This part replaces 951-11574. Price: $3.36 |
| 93 |
714-04078 |
COTTER PIN Price: $3.66 |
| 94 |
951-12232 |
GOVERNOR ARM Price: $21.03 |
| 95 |
951-12237 |
CRANKCASE COVER GASKET Price: $19.48 |
| 96 |
951-15784 |
CRANKSHAFT ASSEMBLY Price: $201.27 |
| 97 |
751P10307A |
WOODRUFF KEY This part replaces 951-10307. Price: $2.01 |
| 98 |
736-04557 |
CRANKSHAFT THRUST WASHER Price: $3.52 |
| 99 |
715-04121 |
DOWEL PIN Price: $3.56 |
| 100 |
710-05198 |
HHFLG M6-1 x 35 CL8.8 Price: $5.01 |
| 101 |
951-12239 |
DIPSTICK ASSEMBLY Price: $26.61 |
| 102 |
951-12240 |
OIL FILL TUBE ASSEMBLY Price: $16.00 |
| 103 |
951-12363 |
O-RING Price: $3.49 |
| 104 |
951-11644 |
ENGINE PLUG 3/8 NPT Price: $8.96 |
| 105 |
919-05090 |
CRANKCASE COVER Price: $123.86 |
| 106 |
710-04982 |
BOLT M8 x 54 Price: $3.37 |
| 107 |
951-15463 |
BALL BEARING Price: $10.75 |
| 108 |
751-12246 |
BALANCE GEAR SHAFT ASSEMBLY Price: $140.57 |
| 109 |
736-04559 |
BALANCEABLE THRUST Price: $3.56 |
| 110 |
951-15782 |
CAMSHAFT ASSEMBLY Price: $54.33 |
| 111 |
736-04561 |
CAMSHAFT THRUST WASHER Price: $3.52 |
| 112 |
951-14895 |
PRESSURE RELEASE COVER Price: $4.69 |
| 113 |
932-05290 |
PRESSURE RELEASE SPRING Price: $4.40 |
| 114 |
951-15588 |
OIL PUMP STEEL BALL Price: $3.50 |
| 115 |
951-11956 |
GOVERNOR GEAR/SHAFT ASSEMBLY Price: $36.12 |
| 116 |
951-12247 |
O-RING Price: $3.60 |
| 118 |
951-12248 |
OIL PUMP ASSEMBLY Price: $59.85 |
| 119 |
951-12249 |
SUMP FILTER Price: $3.35 |
| 120 |
951-12250 |
FILTER SPRING Price: $3.49 |
| 121 |
951-12251 |
O-RING Price: $3.60 |
| 122 |
951-12252 |
FILTER COVER Price: $5.79 |
| 123 |
736-04560 |
OIL DRAIN PLUG WASHER Price: $3.68 |
| 124 |
710-05313 |
BOLT M8 x 15 Price: $3.56 |
