| Ref | Part Number | Description |
|---|
| 1 |
501580402 |
SEAT.ASM.907.TRACK.W/O.BELT This part replaces 539108715. Price: $699.99 |
| 1 |
710-04744 |
Self-Tapping Bolt, Hilo #12-16 X 1.00" Price: $4.47 |
| 2 |
539108717 |
ARMREST KIT, RH Price: $119.99 |
| 3 |
539108718 |
SEAT CUSHION KIT Price: $249.99 |
| 3 |
951-12683 |
Recoil Starter Assembly Price: $80.84 |
| 4 |
539105951 |
SEAT MOUNT W/DECAL This part replaces 539105283. Price: $72.99 |
| 5 |
539104525 |
SEAT ROD Price: $9.99 |
| 6 |
539105039 |
STUD/PLATE MOUNT Price: $4.99 |
| 6 |
712-05015 |
Nut M6 This part replaces 712-04212. Price: $5.78 |
| 7 |
539990761 |
NUT 1/4C CENTER LOCK This part replaces 539990372. Price: $2.99 |
| 8 |
539101341 |
HCS 3/8C X 3 Price: $4.99 |
| 8 |
951-11721 |
Recoil Spring and Pulley Ass'y Price: $43.48 |
| 9 |
595305901 |
Nuts This part replaces 539990546. Price: $2.99 |
| 10 |
596583702 |
Nuts This part replaces 539990717. Price: $2.99 |
| 11 |
539104789 |
DECAL, CROWN H Price: $3.10 |
| 12 |
539108719 |
BACK CUSHION KIT Price: $138.99 |
| 13 |
596230901 |
Screws This part replaces 539990580. Price: $2.99 |
| 14 |
539105224 |
SEAT BRKT W/DECAL Price: $24.99 |
| 15 |
596029501 |
Pins This part replaces 539990365. Price: $2.99 |
| 15 |
710-04976 |
STARTER SHROUD STUD Not Available Price: |
| 16 |
710-04977 |
Stud Front/Unmarked/Wh Zinc Not Available Price: |
| 17 |
582478602 |
NUT FLG, NYLOCK, 1/4-20 GR G C This part replaces 539976978. Price: $1.99 |
| 17 |
710-04978 |
STARTER SHROUD STUD M6 x 79 Not Available Price: |
| 18 |
539108716 |
ARMREST KIT, LH Price: $119.99 |
| 18 |
951-10764 |
FLYWHEEL SHROUD Not Available Price: |
| 18 |
951-12869 |
INNER SHROUD ASSEMBLY Not Available Price: |
| 19 |
750-05320 |
Engine Shroud Spacer Price: $3.56 |
| 20 |
951-11610 |
AIR VANE SHAFT Not Available Price: |
| 21 |
951-11611 |
Air Vane Price: $7.04 |
| 39 |
712-04287A |
FLYWHEEL NUT M14-1.5 This part replaces 712-04287. Price: $5.33 |
