| Ref | Part Number | Description |
|---|
| 1 |
115-5304 |
CAP-FUEL This part replaces 93-7170. Price: $26.87 |
| 1 |
532439699 |
SEAT.XH130.MS498.G.HUSQ.NONTEX This part replaces 532190120. Price: $179.99 |
| 2 |
532140551 |
Bracket, Pivot Seat Price: $3.99 |
| 2 |
92-7186 |
TANK-FUEL Price: $333.26 |
| 3 |
240-11 |
BUSHING-FLANGE Price: $5.32 |
| 3 |
532140675 |
Strap Asm Fender Price: $3.99 |
| 4 |
532127018 |
Bolt Shoulder 5/16-18 x .62 Price: $3.99 |
| 4 |
95-0576-03 |
BASE-TANK, FUEL Price: $196.80 |
| 5 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 5 |
532145006 |
Clip, Push In Hinged Price: $2.99 |
| 6 |
3250-36 |
SCREW-PPH Price: $2.41 |
| 6 |
873680600 |
Nut This part replaces 873800600. Price: $1.99 |
| 7 |
2412-36 |
CLAMP-HOSE Price: $1.28 |
| 7 |
539110300 |
SRPING.SEAT This part replaces 532124181. Price: $2.99 |
| 8 |
110-8151 |
HOSE-FUEL, FORMED This part replaces 92-7152. Price: $18.95 |
| 8 |
532171877 |
Bolt 5/16-18 Unc x 3/4 Price: $3.99 |
| 9 |
92-7160 |
CLIP Price: $13.03 |
| 10 |
32103-12 |
NUT-WING Price: $1.15 |
| 10 |
532195530 |
PAN, SEAT This part replaces 532182493. Price: $14.99 |
| 11 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 12 |
532174648 |
Bracket, Mounting Switch Price: $4.99 |
| 12 |
92-5018-03 |
CLAMP-BATTERY Price: $21.92 |
| 13 |
323-6 |
SCREW-HH Price: $0.66 |
| 13 |
532121248 |
Bushing, Snap Price: $3.99 |
| 14 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 14 |
872050412 |
Bolt, Carriage 1/4-20 x 1-1/2 Price: $3.99 |
| 15 |
104-8162 |
BATTERY-DRY Price: $114.99 |
| 15 |
532134300 |
Spacer, Split Price: $3.99 |
| 16 |
100-6435 |
POST-BATTERY This part replaces 56-7720. Price: $15.91 |
| 16 |
532121250 |
Spring, Cprsn Price: $3.99 |
| 17 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 17 |
873680400 |
Nut Crownlock 1/4-20 unc This part replaces 532123976. Price: $2.69 |
| 18 |
322-3 |
SCREW-HH Price: $0.79 |
| 18 |
819171912 |
Washer 17/32 x 1-3/16 x 12 Ga. Price: $3.99 |
| 19 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 19 |
532166369 |
Knob Seat Price: $4.99 |
| 20 |
2412-73 |
CLAMP-R Price: $2.56 |
| 20 |
532124238 |
Cap, Spring Seat Price: $3.99 |
| 21 |
3274-69 |
SCREW-HSBH Price: $0.43 |
| 21 |
532171852 |
Bolt, Shoulder 5/16-18 Price: $3.99 |
| 22 |
109-0294 |
HOSE-FUEL This part replaces 95-0618. Price: $6.29 |
| 22 |
873800500 |
Nut Lock Hex W/Ins. 5/16-18 Unc P This part replaces 873680500. Price: $2.69 |
| 23 |
2412-98 |
CLAMP-HOSE Price: $1.39 |
| 24 |
83-1390 |
VALVE-SHUT-OFF, FUEL Price: $55.01 |
| 25 |
240-9 |
GROMMET Price: $3.25 |
| 26 |
86-7640-01 |
BOX-LITTER Price: $165.59 |
| 27 |
86-7450 |
CABLE-GROUND Price: $23.53 |
| 28 |
63-8410 |
WASHER Price: $1.76 |
| 29 |
93-6668 |
DECAL-BATTERY Price: $18.99 |
