| Ref | Part Number | Description |
|---|
| 1 |
142829 |
Mower Asm 38" welded (AYP part number) Price: Call Us |
| 2 |
72140506 |
Bolt Rdhd Sqnk 5/16-18 unc X 3/4 Price: Call Us |
| 3 |
120-0404 |
BRACKET-HIGH HOC (LH) Price: $71.73 |
| 3 |
138017 |
Bracket assembly, front Price: Call Us |
| 4 |
120-0405 |
BRACKET-HIGH HOC (RH) Price: $71.73 |
| 4 |
138440 |
Bracket assembly, decl Price: Call Us |
| 5 |
119-0626 |
SHIM-ROLLER Price: $3.23 |
| 5 |
4939M |
Retaining spring (AYP part number) Price: Call Us |
| 6 |
106-9758 |
SCREW-CARR Price: $2.99 |
| 6 |
130832 |
Arm, suspension rear (AYP part number) Price: Call Us |
| 7 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 8 |
112-7451 |
SCREW-TAP Price: $2.17 |
| 8 |
850857 |
Bolt 3/8-24 x 1 25 Gr 8 Patched Price: Call Us |
| 9 |
10030600 |
Washer Lock Hvy 3/8 Unplated (AYP part number) Price: Call Us |
| 9 |
48-9220 |
WASHER-PLAIN Price: $0.87 |
| 10 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 10 |
140296 |
Washer Hard Blade Mower Vented Price: Call Us |
| 11 |
134148 |
Blade Mulching 38" Price: Call Us |
| 11 |
322-16 |
SCREW-HH Price: $3.39 |
| 12 |
129895 |
Bearing Ball #6204 (Mandrel) Price: Call Us |
| 13 |
137645 |
Shaft Asm W/lower Bearing (AYP part number) Price: Call Us |
| 14 |
128774 |
Housing Mandrel Vented (machd) Price: Call Us |
| 15 |
110485X |
Bearing Ball Mandrel Price: Call Us |
| 16 |
140329 |
Stripper MWR (AYP part number) Price: Call Us |
| 19 |
132827 |
Bolt Shoulder Price: Call Us |
| 21 |
73680500 |
Nut Crownlock 5/16-18 Unc Price: Call Us |
| 23 |
137607 |
Bracket Deflector Mower Price: Call Us |
| 24 |
105304X |
Cap Sleeve 80 x 112 Blk Mower Price: Call Us |
| 25 |
123713X |
Spring Deflector Price: Call Us |
| 26 |
110452X |
Nut Push Phos & Oil Price: Call Us |
| 27 |
106736X |
Shield Deflector Mower 38" blk (AYP part number) Price: Call Us |
| 28 |
19111016 |
Washer 11/32 X 5/8 X 16 Ga Price: Call Us |
| 29 |
106735X |
Rod Hinge Brt/blk Zinc 9 88 Lg Price: Call Us |
| 30 |
138776 |
Screw Thdrol Hex Head Zinc Mwr (AYP part number) Price: Call Us |
| 31 |
129963 |
Washer Spacer Mower Vented (AYP part number) Price: Call Us |
| 32 |
153532 |
Pulley Mandrel 38" (AYP part number) Price: Call Us |
| 33 |
137266 |
Nut 9/16 top Lock Flng Cntr Price: Call Us |
| 36 |
131494 |
Pulley Idler Flat 3 060 (AYP part number) Price: Call Us |
| 40 |
73680600 |
Nut Crownlock 3/8-16 Unc Price: Call Us |
| 41 |
133551 |
Rod Pivot W/nibs Price: Call Us |
| 43 |
133504 |
Rod Clutch Secondary W/nibs Price: Call Us |
| 45 |
4497H |
Spring Retainer 1" Zinc/cad Price: Call Us |
| 53 |
130840 |
Brake Asm Mower Vented Price: Call Us |
| 54 |
133943 |
Washer Hardened (AYP part number) Price: Call Us |
| 55 |
133840 |
Arm Idler 38" Price: Call Us |
| 56 |
122052X |
Spacer Retainer Pm Mower Price: Call Us |
| 67 |
106932X |
Knob Round Price: Call Us |
| 68 |
144200 |
V-Belt Mower Price: Call Us |
| 69 |
76020312 |
Pin Cotter 3/32 X 3/4 Cad Price: Call Us |
| 71 |
142427 |
Rod Clutch Primary 38/42 Price: Call Us |
| 72 |
131870 |
Spring Return Price: Call Us |
| 73 |
127847 |
Arm Clutch Secondary Price: Call Us |
| 74 |
121748X |
Washer 25/32 X 1-5/8 X 16 Ga Price: Call Us |
| 75 |
12000029 |
Ring Klip #t5304-75 Price: Call Us |
| 76 |
128903 |
Bolt Shoulder 3/8-16 Unc 1 44 Price: Call Us |
| 77 |
127845 |
Keeper Spring 4 000 Price: Call Us |
| 78 |
154809 |
Arm Asm Clutch Primary Price: Call Us |
| 79 |
127498 |
Bushing 747 Od X 794 Lg Brass Price: Call Us |
| 80 |
153701 |
Spring Clutch Mower Price: Call Us |
| 81 |
73350600 |
Nut Hex Jam 3/8-16 Price: Call Us |
| 82 |
142028 |
Trunnion Adj '94 Price: Call Us |
| 86 |
7631J |
Runner Mower LH 10 00 Price: Call Us |
| 87 |
128772 |
Runner RH 38" Price: Call Us |
| 88 |
19111216 |
Washer 11/32 X 3/4 X 16 Ga Price: Call Us |
| 89 |
19131612 |
Washer 13/32 X 1 X 12 Ga Price: Call Us |
| 92 |
73800600 |
Nut Lock Hex W/ins. 3/8-16 UNC Price: Call Us |
| 96 |
74930620 |
Bolt 3/8-16 x 1-1/4 Mulcher Price: Call Us |
| 97 |
73930600 |
Nut Centerlock 3/8-16 UNC Price: Call Us |
| 98 |
19132016 |
Washer 13/32 x 1-1/4 x 16 Ga. (AYP part number) Price: Call Us |
| 99 |
10040600 |
Washer Lock Hvy Hlcl Spr. 3/8 Price: Call Us |
| 100 |
135651 |
Nut Wing Price: Call Us |
| 101 |
132803 |
Cover Asm Mulcher 38" Price: Call Us |
| 107 |
133502 |
Spacer Arm Idler Upper Hdn 42" Price: Call Us |
| 108 |
133503 |
Stiffener Arm Idler Upper 42" Price: Call Us |
| 109 |
74760640 |
Bolt Hex Fin 3/8-16 x 2-1/2 Price: Call Us |
| 110 |
142587 |
Upstop Deck front Price: Call Us |
| 113 |
17490512 |
Screw Thdrol 5/16-18 X 3/4 TYT Price: Call Us |
| 122 |
131289 |
Rod Brake Mandrel LH 4 856 Price: Call Us |
| 123 |
131288 |
Rod Brake Mandrel RH 10 744 Price: Call Us |
| 124 |
72110614 |
Bolt Rdhd 3/8-16 unc x 1-3/4 Gr 5 Price: Call Us |
| 128 |
153390 |
Washer Felt Price: Call Us |
