| Ref | Part Number | Description |
|---|
| 1 |
137-6126 |
LONG REAR ROLLER ASM (3IN DIA)(32IN) This part replaces 112-8961. Price: $536.38 |
| 2 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 2 |
506915301 |
SEAT SPRING Price: $17.99 |
| 3 |
119-0626 |
SHIM-ROLLER Price: $3.23 |
| 3 |
734117441 |
WASHER Price: $3.99 |
| 4 |
725249371 |
Screw M10x25 Price: $1.82 |
| 5 |
106-3924 |
BRACKET-ROLLER, REAR Price: $23.58 |
| 5 |
587605301 |
SEAT ASSY KIT LOW HVA This part replaces 544433301. Price: $179.99 |
| 6 |
3230-26 |
SCREW-CARR Price: $3.99 |
| 6 |
585065201 |
KNOB This part replaces 506565501. Price: $17.99 |
| 7 |
117-0990 |
PLASTIC WIEHLE ROLLER ASM Price: $553.30 |
| 7 |
506565301 |
WASHER Price: $4.99 |
| 8 |
734116441 |
SPACER Price: $3.99 |
| 9 |
32128-20 |
NUT-HF Price: $0.99 |
| 9 |
506556301 |
BOLT Price: $3.99 |
| 10 |
322-16 |
SCREW-HH Price: $3.39 |
| 10 |
506509901 |
Shaft Price: $6.08 |
| 11 |
3231-4 |
SCREW-CARR Price: $3.59 |
| 11 |
735311200 |
RETAINING RING SGA 10 Price: $2.99 |
| 12 |
120-0404 |
BRACKET-HIGH HOC (LH) Price: $71.73 |
| 12 |
120-0405 |
BRACKET-HIGH HOC (RH) Price: $71.73 |
| 12 |
506668801 |
PIN Price: $3.99 |
| 13 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 14 |
48-9220 |
WASHER-PLAIN Price: $0.87 |
| 15 |
140-5522 |
SCREW-HHF 5/8, PATCH This part replaces 133-7571. Price: $2.46 |
| 16 |
94-6936 |
WASHER-HARDENED Price: $0.58 |
| 17 |
133-7570 |
NUT-FLANGE, NI Price: $0.45 |
