| Ref | Part Number | Description |
|---|
| 1 |
04220167 |
WMT, CONTROL ARM This part replaces 04220100. Price: $96.45 |
| 2 |
03563100 |
ROD END, .38 RH Price: $15.45 |
| 3 |
02956000 |
LINK, TRANSMISSION Price: $117.45 |
| 4 |
00363800 |
BSHG, SPCR .390X.625X1.25 PM Price: $14.45 |
| 5 |
03266400 |
SPACER, STEERING Price: $19.45 |
| 6 |
00952300 |
BRKT, STEERING Price: $40.95 |
| 7 |
03262051 |
PLATE, STEERING REINFORCING Price: $7.45 |
| 8 |
04257400 |
GRIP, HANDLEBAR 15" FOAM Price: $14.45 |
| 9 |
06300119 |
WSHR-LK-REG .312X.078 ZCC This part replaces 06308600. Price: $0.95 |
| 10 |
05901802 |
BLT, HEX .31-18X1.00 G8 ZCC This part replaces 05901311. Price: $1.45 |
| 12 |
05901812 |
BLT, HEX .38-16X2.50 G5 ZCC This part replaces 05958400. Price: $2.45 |
| 13 |
05500020 |
BUSHING, POLYLINER-.38 SNAPIN Price: $2.45 |
| 14 |
05901804 |
BLT, HEX .31-18X1.75 G5 ZCC This part replaces 05957400. Price: $2.95 |
| 15 |
05503900 |
BSHG-FLG .750X1.000X.625X1.250 Price: $11.45 |
| 16 |
03207600 |
BEARING FLANGE Price: Call Us |
| 17 |
06500910 |
NUT-JAM .375-16 G2 ZCC This part replaces 06535900. Price: $0.95 |
| 18 |
06700222 |
PIN, HAIR #213 .08X1.19 ZCC This part replaces 06713500. Price: $0.45 |
| 19 |
05901716 |
BLT- HEX .25-20X.75 G5 ZCC This part replaces 05946800. Price: $0.95 |
| 20 |
06500809 |
NUT,NYL-FLG .31-18 GF ZCC This part replaces 06545400. Price: $1.45 |
| 21 |
04219451 |
WMT, STEERING HANDLE RH Price: $64.95 |
| 22 |
02981451 |
BRACKET, LH SPEED CONTROL Price: $71.45 |
| 23 |
05901815 |
BLT, HEX .38-16X3.00F G5 ZCC This part replaces 05958300. Price: $2.95 |
| 24 |
05901612 |
BLT, HEX .38-16X1.75F G5 ZCC This part replaces 05974000. Price: $2.95 |
| 25 |
03652200 |
STUD- BALL Price: $3.45 |
| 26 |
03914200 |
DAMPER, CONTROL Price: $51.95 |
| 27 |
06500904 |
NUT-LK-TOP-FLG .312-18 GF ZCC This part replaces 06543100. Price: $0.95 |
| 28 |
02981351 |
BRACKET, RH SPEED CONTROL Price: $61.45 |
| 29 |
07400124 |
SCR,TAP .312-18X.50 HWH TR ZCC This part replaces 07411500. Price: $1.45 |
| 30 |
06500903 |
NUT-LK-TOP-FLG .250-20 GF ZCC This part replaces 06543500. Price: $0.95 |
| 31 |
07500131 |
CAP PLUG, SQ 3/4-14-20 RIBBED Price: $3.45 |
| 33 |
05501017 |
BSHG-FLG, .625X.75X.450X.875 Price: $7.45 |
| 34 |
05500932 |
BSHG, ECCENTRIC .328X.750X.970 Price: $1.95 |
| 35 |
04192900 |
WMT, UPPER CONTROL ARM Price: Call Us |
| 36 |
07001816 |
BLT, SERHFWH .375-16X1.25 ZCC This part replaces 07050000. Price: $3.95 |
| 37 |
06401013 |
WSHR-FLT .406X.812X.065 ZCC This part replaces 06436200. Price: $0.95 |
| 04219551 |
WMT, |
STEERING HANDLE LH Price: $76.45 04219551 |
