| Ref | Part Number | Description |
|---|
| 1 |
32151-36 |
RING-RETAINING Price: $1.73 |
| 1 |
532184233 |
DECK.SVC.4.GA.WHLS.48".BLK This part replaces 532180358. Price: $349.99 |
| 2 |
99-7667 |
WASHER-FLAT Price: $4.80 |
| 3 |
531165401 |
SERVICE.KIT BRACKET BRKT ASM S This part replaces 532138017. Price: $12.99 |
| 4 |
340-77 |
FITTING-ELBOW, 90 DEG Price: $24.95 |
| 5 |
127-6430 |
LIFT CYLINDER ASM This part replaces 107-1981. Price: $793.53 |
| 5 |
532124670 |
RETAINER-SPRNG RB Price: $5.99 |
| 6 |
531149301 |
SERVICE KIT BAR BAR SWAY DECK. This part replaces 532178024. Price: $9.99 |
| 6 |
93-2700 |
ROLLER-PLASTIC Price: $30.55 |
| 7 |
33029-00 |
NUT-LOCK, NI Price: $2.92 |
| 8 |
302-2 |
FITTING-GREASE Price: $1.89 |
| 8 |
532193003 |
BOLT.WASHER.ASM.7/16-2 This part replaces 532174365. Price: $6.99 |
| 9 |
98-8821 |
LINK-REAR Price: $30.71 |
| 10 |
93-2704-03 |
LINK-LEFT Price: $23.18 |
| 11 |
3229-28 |
SCREW-CARR Price: $0.81 |
| 12 |
100-4872 |
PLATE-SWITCH, NEUTRAL Price: $11.84 |
| 13 |
105-3858 |
BRACKET-SWITCH Price: $28.58 |
| 13 |
532174360 |
SHAFT ASM W/LOWER BEARING Price: $39.99 |
| 14 |
104-1450 |
BOLT-CARR Price: $0.25 |
| 14 |
532174358 |
HOUSING, MANDREL 48" Price: $49.99 |
| 15 |
10-8110 |
WASHER-THRUST Price: $1.09 |
| 15 |
532110485 |
BEARING Price: $11.99 |
| 16 |
323-7 |
SCREW-HH Price: $0.65 |
| 16 |
531167701 |
SERVICE KIT MANDREL STRIPPER This part replaces 532174493. Price: $6.99 |
| 17 |
32149-7 |
NUT-KEPS Price: $0.27 |
| 17 |
596987501 |
Bolts This part replaces 872110610. Price: $3.99 |
| 18 |
106-9288 |
SENSOR-PROXIMITY, FERROUS Price: $126.57 |
| 18 |
596136401 |
Bolts This part replaces 872140505. Price: $2.99 |
| 19 |
3296-49 |
NUT-LOCK, NI Price: $4.93 |
| 19 |
532132827 |
BOLT SHD 5/16-18 Price: $4.99 |
| 20 |
531167501 |
SERVICE KIT BAFFLE BAFFLE This part replaces 532174378. Price: $12.99 |
| 20 |
76-2980 |
WASHER-THRUST Price: $5.08 |
| 21 |
136-3381 |
NO.6 LIFTARM ASM This part replaces 108-4035. Price: $1,212.21 |
| 21 |
596040501 |
Hardware This part replaces 873680500. Price: $2.99 |
| 22 |
108-4022 |
SHAFT-CARRIER, PIVOT Price: $160.59 |
| 23 |
105-3999 |
SPRING-COMPRESSION Price: $54.93 |
| 24 |
3-6781 |
WASHER-THRUST Price: $1.40 |
| 24 |
532105304 |
CAP-SLEEVE LT Price: $3.99 |
| 25 |
3256-28 |
WASHER-FLAT Price: $0.48 |
| 25 |
539107609 |
TORSION SPRING This part replaces 532178102. Price: $4.99 |
| 26 |
3296-50 |
NUT-LOCK, NI Price: $2.68 |
| 26 |
532110452 |
NUT PUSH M Price: $2.99 |
| 27 |
532180655 |
DEFLECTOR.ASM.BLACK.48" This part replaces 532181707. Price: $39.99 |
| 27 |
93-2699 |
PIN Price: $48.15 |
| 28 |
147-6067 |
PIVOT PIN ASM This part replaces 98-8826. Price: $44.62 |
| 28 |
819111016 |
Washer 11/32 x 5/8 x 16 Ga SD Price: $5.99 |
| 29 |
32121-110 |
PIN-ROLL, SLOTTED Price: $1.93 |
| 29 |
595297001 |
Rods This part replaces 532131491. Price: $4.99 |
| 30 |
104-5657-03 |
NO. 6 SUPPORT ARM ASM Price: $1,374.05 |
| 30 |
584953901 |
BOLT.HEX.WASHR.HED.313-18X1.19 This part replaces 532173984. Price: $3.99 |
| 31 |
32128-33 |
NUT-HF Price: $0.25 |
| 31 |
532187690 |
WASHER.SPACER.MANDREL This part replaces 532129963. Price: $3.99 |
| 32 |
532173436 |
PULLEY MANDREL This part replaces 532177865. Price: $14.99 |
| 32 |
67-1750 |
BUSHING Price: $0.92 |
| 33 |
115-1577-03 |
LINK ASM Price: $299.26 |
| 33 |
596134801 |
Nuts This part replaces 532178342. Price: $1.00 |
| 35 |
32104-32 |
SCREW-HWH Price: $1.99 |
| 36 |
2412-93 |
CLAMP-R Price: $1.02 |
| 36 |
596565301 |
WASHER PLAIN WASHER 3/8 X 0.08 This part replaces 819131316. Price: $2.99 |
| 37 |
532177968 |
PULLEY.IDLER.FLAT Price: $27.99 |
| 38 |
105-9828 |
ACTUATOR-SWITCH Price: $35.48 |
| 39 |
108-4045-03 |
LATCH-ARM, LH Price: $120.83 |
| 39 |
532174375 |
PULLEY.DRIVEN.DECK.48' Price: $34.99 |
| 40 |
104-3556-03 |
LATCH-RH Price: $58.58 |
| 41 |
327-6 |
SCREW-HH Price: $12.99 |
| 42 |
3234-46 |
SCREW-HHF Price: $2.08 |
| 42 |
532165723 |
SPACER.RETAINER.MOWER This part replaces 532122052. Price: $5.99 |
| 43 |
104-3577 |
WASHER Price: $0.76 |
| 43 |
532174373 |
ARM, IDLER SECONDARY Price: $9.99 |
| 44 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 45 |
3296-45 |
NUT-HEX Price: $3.79 |
| 45 |
532180806 |
COVER.MANDREL.DECK.48" This part replaces 532174343. Price: $12.99 |
| 46 |
48-7081 |
GRIP-PLASTIC Price: $7.54 |
| 46 |
532137729 |
SCREW.1/4-20X5/8 Price: $3.99 |
| 47 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 47 |
532180808 |
V-BELT, 48"SECONDARY This part replaces 532174369. Price: $49.99 |
| 48 |
532174368 |
V-BELT PRIMARY 48" Price: $49.99 |
| 49 |
136-3510 |
CARRIER FRAME ASM This part replaces 115-3453. Price: $664.28 |
| 49 |
596322601 |
Nuts This part replaces 873680600. Price: $2.99 |
| 50 |
112-9900-03 |
GUARD-FOOT Price: $82.81 |
| 50 |
596136101 |
GSPW Bolts This part replaces 872110612. Price: $2.99 |
| 51 |
323-52 |
SCREW-HH Price: $3.63 |
| 52 |
596481401 |
Pulleys This part replaces 532175820. Price: $22.99 |
| 52 |
93-8806 |
WASHER-HARDENED Price: $1.62 |
| 53 |
105-9823 |
BUSHING-CARRIER Price: $5.52 |
| 54 |
105-9822 |
SPACER Price: $3.16 |
| 54 |
596564401 |
Bolts This part replaces 874780616. Price: $3.99 |
| 55 |
323-11 |
SCREW-HH Price: $1.08 |
| 55 |
596728201 |
Bolts This part replaces 872140608. Price: $3.99 |
| 56 |
115-4841 |
SCREW-HH Price: $10.68 |
| 56 |
532155986 |
BAR.ADJUST.WHEEL.ANTI.SCALP.BL Price: $17.99 |
| 57 |
136-3383 |
NO.7 LIFT ARM ASM This part replaces 108-4036. Price: $1,212.21 |
| 57 |
532156941 |
RIVET.PIN.HEAD.YELLOW. Price: $4.99 |
| 58 |
104-5658-03 |
NO. 7 SUPPORT ARM ASM Price: $1,362.74 |
| 59 |
108-4046-03 |
LATCH-ARM, RH Price: $120.83 |
| 60 |
104-3557-03 |
LATCH-LH Price: $58.58 |
| 72 |
596134901 |
GSPH This part replaces 819131312. Price: $2.99 |
| 91 |
529846101 |
SERVICE KIT BRKT.NOSEROLLER.LH This part replaces 532180534. Price: $5.99 |
| 92 |
596322601 |
Nuts This part replaces 873800600. Price: $2.99 |
| 94 |
532176066 |
NOSE ROLLER 48" Price: $11.99 |
| 97 |
532178515 |
WASHER This part replaces 532133943. Price: $5.99 |
| 98 |
532179479 |
SPRING PRIMARY DRIVE Price: $3.99 |
| 99 |
532193195 |
PULLEY.V.IDLER This part replaces 532175080. Price: $49.99 |
| 100 |
596136301 |
Bolts This part replaces 872110616. Price: $2.99 |
| 107 |
532175294 |
BAFFLE.VAC.EDGE.MOWER.48" Price: $2.99 |
| 108 |
596133401 |
Bolts This part replaces 872140404. Price: $1.99 |
| 109 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873680400. Price: $3.99 |
| 110 |
532175016 |
ARM, SPRING SECONDARY Price: $4.99 |
| 112 |
532174387 |
LEVER, TENSION RELIEF LINK Price: $14.99 |
| 113 |
596435701 |
Bolts This part replaces 872110508. Price: $2.99 |
| 114 |
532174384 |
LEVER ASM, TENSION RELIEF Price: $8.99 |
| 115 |
532174609 |
ARM, SPRING TENSION RELIEF Price: $4.99 |
| 116 |
596434404 |
Bolts This part replaces 532137644. Price: $4.99 |
| 117 |
532133957 |
WHEEL GAGE DONUT Price: $11.99 |
| 118 |
596322601 |
Nuts This part replaces 873930600. Price: $2.99 |
| 119 |
596134901 |
GSPH This part replaces 819121414. Price: $2.99 |
| 121 |
532174371 |
SPRING.DRIVE.SECONDARY.48".DEC Price: $5.99 |
| 122 |
532174606 |
BUSHING, PIVOT TENSION RELIEF Price: $3.99 |
| 126 |
532174372 |
ARM, IDLER PRIMARY DECK Price: $9.99 |
| 130 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 132 |
817000612 |
SCREW, 3/8-16X3/4 This part replaces 817060612. Price: $3.99 |
| 182 |
594092501 |
Rods This part replaces 532179127. Price: $5.99 |
| 183 |
532003146 |
SPRING RETAINER This part replaces 532163552. Price: $2.99 |
| 184 |
532173979 |
KEEPER BELT IDLER PLATED Price: $4.99 |
