| Ref | Part Number | Description |
|---|
| 1 |
93323 |
SCREW Price: Call Us |
| 2 |
280118 |
SUPPORT, AIR CLEANER ELEMENT Price: Call Us |
| 3 |
391786 |
CLEANER ASSY, AIR Price: Call Us |
| 4 |
270843 |
ELEMENT, AIR CLEANER Price: Call Us |
| 5 |
270853 |
GASKET, AIR CLEANER Price: Call Us |
| 5 |
98-9468 |
NOZZLE HOLDER ASM This part replaces 105-3740. Price: $341.86 |
| 6 |
93622 |
SCREW Price: Call Us |
| 7 |
93043 |
PIN, THROTTLE STOP Price: Call Us |
| 8 |
211712 |
STOP, THROTTLE Price: Call Us |
| 9 |
299740 |
NOZZLE CARBURETOR Price: Call Us |
| 10 |
292681 |
VALVE ASSEMBLY, CARBURETOR IDLE SCREW, SEMS Price: Call Us |
| 10 |
98-9468 |
NOZZLE HOLDER ASM Price: $341.86 |
| 11 |
270511 |
GASKET, FLOAT BOWL Price: Call Us |
| 12 |
299707 |
FLOAT, CARBURETOR Price: Call Us |
| 13 |
491006 |
SHAFT & LEVER, THROTTLE Price: Call Us |
| 14 |
222433 |
VALVE, THROTTLE Price: Call Us |
| 15 |
93499 |
SCREW Price: Call Us |
| 16 |
491562 |
CARBURETOR ASSY Price: Call Us |
| 17 |
221995 |
BOWL, FLOAT Price: Call Us |
| 18 |
231323 |
SCREW Price: Call Us |
| 19 |
222014 |
WASHER Price: Call Us |
| 20 |
396568 |
VALVE, NEEDLE Price: Call Us |
| 20 |
99-8301 |
NUT Price: $8.64 |
| 21 |
222311 |
BRACKET, CARBURETOR Price: Call Us |
| 22 |
394681 |
VALVE, FUEL INLET Price: Call Us |
| 23 |
230896 |
PIN, FLOAT HINGE Price: Call Us |
| 24 |
93572 |
SCREW Price: Call Us |
| 25 |
391787 |
BODY ASSY, CARBURETOR Price: Call Us |
| 26 |
221997 |
PLUG WELSH Price: Call Us |
| 27 |
213115 |
VENTURI - CARBURETOR Price: Call Us |
| 28 |
390684 |
SHAFT & LEVER, CHOKE Price: Call Us |
| 29 |
261116 |
SPRING, CHOKE RETURN Price: Call Us |
| 30 |
26157 |
SPRING, THROTTLE ADJUSTMENT Price: Call Us |
| 30 |
99-8302 |
WASHER-ADJUSTING Price: $7.16 |
| 31 |
91920 |
SCREW, MACHINE, FILLISTER HEAD Price: Call Us |
| 32 |
222010 |
VALVE, CHOKE Price: Call Us |
| 33 |
270382 |
WASHER, FOAM Price: Call Us |
| 34 |
93357 |
SCREW, SEMS, CARBURETOR MOUNTING Price: Call Us |
| 35 |
270872 |
GASKET, CARBURETOR Price: Call Us |
| 36 |
261610 |
LINK, CHOKE Price: Call Us |
| 37 |
393815 |
HOSE (CUT TO SUIT) Price: Call Us |
| 38 |
93053 |
CLAMP, HOSE, GREEN Price: Call Us |
| 39 |
67218 |
CONNECTOR, FUEL PIPE Price: Call Us |
| 40 |
19203 |
PULLER, FLYWHEEL Price: Call Us |
| 40 |
99-8303 |
SPRING-NOZZLE Price: $11.49 |
| 41 |
298090 |
FILTER, FUEL Price: Call Us |
| 42 |
222380 |
CUP, AIR CLEANER SUPPORT Price: Call Us |
| 43 |
222495 |
SPACER, AIR CLEANER Price: Call Us |
| 44 |
222382 |
SCREEN, AIR CLEANER Price: Call Us |
| 45 |
398970 |
SEAL, THROTTLE SHAFT Price: Call Us |
| 46 |
93543 |
SCREW, SEMS, HEX HEAD Price: Call Us |
| 47 |
271853 |
WASHER, THROTTLE SHAFT, FOAM Price: Call Us |
| 50 |
99-8304 |
SPACER-DISTANCE Price: $29.26 |
| 60 |
99-8305 |
ROD-PUSH Price: $60.67 |
| 70 |
99-8306 |
NUT-NOZZLE Price: $34.65 |
| 80 |
99-8307 |
WASHER-PLAIN Price: $8.84 |
| 90 |
99-8308 |
PIECE-NOZZLE Price: $90.57 |
| 100 |
99-8309 |
ADJUSTING WASHER ASM Price: $56.19 |
| 110 |
99-8310 |
WASHER-ADJUST (0.10MM) Price: $2.74 |
| 110 |
99-8311 |
WASHER-ADJUST (0.20MM) Price: $3.56 |
| 110 |
99-8312 |
WASHER-ADJUST (0.30MM) Price: $2.74 |
| 110 |
99-8313 |
WASHER-ADJUST (0.40MM) Price: $2.74 |
| 110 |
99-8314 |
WASHER-ADJUST (0.50MM) Price: $1.91 |
| 110 |
99-8315 |
WASHER-ADJUST (0.52MM) Price: $1.91 |
| 110 |
99-8316 |
WASHER-ADJUST (0.54MM) Price: $1.91 |
| 110 |
99-8317 |
WASHER-ADJUST (0.56MM) Price: $1.91 |
| 110 |
99-8318 |
WASHER-ADJUST (0.58MM) Price: $1.91 |
| 110 |
99-8319 |
WASHER-ADJUST (0.80MM) Price: $1.91 |
| 120 |
98-7676 |
GASKET Price: $2.73 |
| 394698 |
CARBURETOR |
OVERHAUL KIT Price: Call Us 394698 |
