| Ref | Part Number | Description |
|---|
| 1 |
611-04033 |
Shaft Assembly, Detent Price: Call Us |
| 2 |
619-04069 |
Housing, Transmission Price: Call Us |
| 3 |
619-04070 |
Cover, Housing, Transmission Price: Call Us |
| 4 |
686-04046 |
Link Assembly, Shift Price: Call Us |
| 6 |
710-0425 |
Screw, Machine, #10-24, 0.625 Price: $4.21 |
| 8 |
710-04049 |
Flange Screw, 5/16-18,.625, Gr5 Price: $4.11 |
| 10 |
711-04261 |
Shaft, Wheel,.750 Dia x 15.46 Lg Price: Call Us |
| 11 |
711-04263 |
Shaft, Tiller, Tine Price: Call Us |
| 12 |
711-04178 |
Shaft, Worm, Drive Price: Call Us |
| 13 |
711-04177 |
Shaft, Idler,.500 Dia x 1.823 Lg Price: Call Us |
| 14 |
711-04168 |
Shaft, Drive Price: Call Us |
| 15 |
712-0161 |
Nut, Hex Lock, #10-24, Gr2, Nylon Price: $4.02 |
| 16 |
915-0221 |
Dowel Pin This part replaces 715-0221. Price: $3.93 |
| 17 |
716-04026 |
Ring, Retaining, External, 1.188 Dia Shaft Price: Call Us |
| 18 |
716-04027 |
Ring, Retaining, Int, 1.25 Dia Bore Price: Call Us |
| 19 |
716-0865 |
Ring, Snap,.500 Price: $3.86 |
| 20 |
717-04088 |
Gear, Spur, 30t Price: Call Us |
| 21 |
717-04084 |
Gear, Spur, 34t Price: Call Us |
| 22 |
717-04083 |
Gear, Spur, 10t Price: Call Us |
| 23 |
717-04087 |
Gear, Spur, 13t Price: Call Us |
| 24 |
717-04093 |
Gear, Worm, 30t Price: Call Us |
| 25 |
717-04090 |
Gear, Worm, 40t Price: Call Us |
| 26 |
718-04074 |
Collar, Clutch Price: Call Us |
| 27 |
718-04065 |
Cover, Bearing, Rear Price: Call Us |
| 28 |
918-04435 |
Bearing Cover This part replaces 718-04008. Price: $20.18 |
| 30 |
721-0212 |
OIL SEAL -.375 ID Not Available Price: |
| 31 |
721-04073 |
Seal, Oil,.750 Shaft x 1.125 Bore Price: Call Us |
| 33 |
721-04069 |
O-Ring, 1/4 x 3/8 x.07 Price: Call Us |
| 34 |
721-04065 |
Seal,.750 Shaft x1.783 Bore x.375 Price: Call Us |
| 35 |
721-04064 |
Seal,.563 Shaft x 1.25 Bore x.25 Price: Call Us |
| 36 |
921-04036 |
Seal,Oil 1.00 Shft X 1.500 Bore This part replaces 721-04036. Price: $17.34 |
| 37 |
736-04153 |
Washer, Flat,.751 x.975 x.01 Price: Call Us |
| 38 |
936-0119 |
LOCK WASHER 5/16 This part replaces 736-0119. Price: $4.29 |
| 40 |
936-0419 |
THRUST WASHER-.630 x 1.125 Not Available This part replaces 736-0419. Price: |
| 42 |
736-04102 |
Washer, Flat,.5685 x.875 x.04 Price: Call Us |
| 43 |
736-0495 |
THRUST WASHER Price: $3.90 |
| 44 |
736-0617 |
Washer, Thrust,.750 x 1.250 x.0615 Price: $10.05 |
| 45 |
737-0356 |
Grease, Seal Price: Call Us |
| 46 |
737-0353 |
Oil, 85w 140 Price: Call Us |
| 47 |
741-04077 |
Bearing, Hub Price: Call Us |
| 48 |
741-04075 |
Bearing, 9/16 x 1.25 x.650 Lg Price: Call Us |
| 49 |
741-0973 |
Bearing, Sleeve,.627 x.81 x.80 Price: Call Us |
| 50 |
941-0336 |
Flange Bearing, 5/8 x 3/4 x 3/4 This part replaces 741-0336. Price: $10.28 |
| 51 |
741-0678 |
Bearing, Sleeve,.503 x.626 x.600 Price: Call Us |
| 52 |
741-0469 |
THRUST BEARING Not Available Price: |
| 53 |
741-05060 |
SLEEVE BEARING .75X1.00X1.00 This part replaces 741-0340. Price: $7.69 |
| 54 |
716-04104 |
Retaining Ring This part replaces 1909950. Price: $3.85 |
| 55 |
1916109001 |
COVER-TRANS REAR Not Available This part replaces 1918377. Price: |
| 56 |
941-04300 |
Bushing, 1.25 x 1 x .005 x 1.5 This part replaces GW-1086. Price: $15.25 |
| 57 |
736-04310 |
Flat Washer, 1/234 x 1.015 x .062 This part replaces GW-1132-2. Price: $3.95 |
| 68 |
921-04229 |
Gear Housing Gasket This part replaces GW-50032. Price: $6.04 |
| 69 |
941-04299 |
Cup Bearing This part replaces GW-9400. Price: $6.01 |
| 70 |
941-04298 |
Cone Bearing This part replaces GW-9401. Price: $14.84 |
| 71 |
716-04102 |
Retaining Ring, Int This part replaces GW-9517. Price: $3.85 |
