| Ref | Part Number | Description |
|---|
| 1 |
117-4760-01 |
SUPPORT-ROLLER Price: $306.77 |
| 2 |
3234-38 |
SCREW-HHF Price: $3.33 |
| 2 |
596437001 |
Screws This part replaces 817720408. Price: $2.99 |
| 3 |
87-3470 |
BUMPER Price: $18.89 |
| 4 |
33025-00 |
NUT-LOCK, NI Price: $0.54 |
| 4 |
532149723 |
MUFFLER.TWIN.CYL.LOW.TONE Price: $39.99 |
| 5 |
105-3996-01 |
SUPPORT-ROLLER Price: $141.71 |
| 5 |
583954501 |
PIPE.EXHAUST.LH.CV18/20 This part replaces 532146699. Price: $19.99 |
| 6 |
325-22 |
SCREW-HH Price: $4.26 |
| 6 |
583954801 |
PIPE.EXHAUST.RH.CV18/20 This part replaces 532146700. Price: $17.99 |
| 7 |
3296-23 |
NUT-LOCK, NI Price: $0.52 |
| 8 |
325-20 |
SCREW-HH Price: $6.29 |
| 8 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK Price: $4.99 |
| 9 |
105-3970 |
SPRING-COMPRESSION Price: $46.60 |
| 10 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 10 |
531154901 |
SERVICE KIT HEAT SHIELD This part replaces 532146629. Price: $11.99 |
| 11 |
105-9816 |
ROLLER-PLASTIC Price: $47.03 |
| 12 |
104-5545 |
SHAFT-ROLLER Price: $35.54 |
| 13 |
3272-11 |
PIN-COTTER Price: $0.99 |
| 14 |
115-9137 |
SHROUD-PLATFORM Price: $443.77 |
| 14 |
532148456 |
TUBE, DRAIN OIL ASM. Price: $5.99 |
| 15 |
32104-17 |
SCREW-HWH Price: $0.99 |
| 16 |
94-9024 |
LAMP ASM Price: $157.81 |
| 17 |
3230-7 |
BOLT-CARR Price: $0.88 |
| 17 |
817060624 |
SCREW 3/8-16 X 1-1/2 Price: $4.99 |
| 18 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 19 |
93-6028 |
PLATE-LOGO Price: $13.70 |
| 20 |
3254-9 |
WASHER-LOCK, INTERNAL Price: $0.25 |
| 21 |
136-2923 |
SPACER-CENTERING Price: $28.02 |
| 23 |
531150701 |
SERVICE KIT SHIELD SHIELD.BROW This part replaces 532169837. Price: $19.99 |
| 26 |
873920600 |
Nut Keps 3/8 - 24 UNF Price: $3.99 |
| 29 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 32 |
532179124 |
FUEL CAP This part replaces 532181803. Price: $29.99 |
| 33 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 37 |
587044854 |
HOSE.1/4".LOW.PERM.FUEL.LN.54" This part replaces 532142158. Price: $14.99 |
| 38 |
532428287 |
VALUE.OIL.DRAIN This part replaces 532181654. Price: $14.99 |
| 41 |
532139277 |
STEM FUEL TANK Price: $6.99 |
| 45 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 101 |
596433401 |
Nuts This part replaces 532163305. Price: $2.99 |
| 116 |
532184362 |
NUT.HEX.FLANGE.TOPLOCK Price: $3.99 |
