| Ref | Part Number | Description |
|---|
| 1 |
951-12739 |
FUEL TANK ASSEMBLY Not Available This part replaces 951-10368. Price: |
| 2 |
710-04976 |
STARTER SHROUD STUD Not Available Price: |
| 2 |
710-04977 |
Shroud Stud Front/Unmarked Not Available Price: |
| 2 |
710-04978 |
STARTER SHROUD STUD M6 x 79 Not Available Price: |
| 2 |
712-05015 |
Nut M6 This part replaces 712-04212. Price: $5.78 |
| 2 |
951-10369 |
FLYWHEEL SHROUD Not Available Price: |
| 3 |
951-10335 |
Rubber Fuel Tank Mounting Washer Price: $4.90 |
| 4 |
951-10334 |
Oil Filler Tube Assembly Price: $20.69 |
| 5 |
951-10333 |
Dipstick Assembly Price: $15.70 |
| 6 |
951-10413B |
Cylinder Head Assembly This part replaces 951-10413. Price: $164.33 |
| 7 |
951-12724 |
SHORTBLOCK ASSEMBLY Not Available This part replaces 951-10414. Price: |
| 8 |
951-10321A |
Stop Switch and Brake Ass'y Not Available This part replaces 951-10321. Price: |
| 9 |
710-04976 |
STARTER SHROUD STUD Not Available Price: |
| 9 |
710-04977 |
Starter Shroud Stud M6 x 87-51.5 Not Available Price: |
| 9 |
710-04978 |
STARTER SHROUD STUD M6 x 79 Not Available Price: |
| 9 |
712-05015 |
Nut M6 This part replaces 712-04212. Price: $5.78 |
| 9 |
951-10319 |
Recoil Spring and Pulley Assembly Price: $44.50 |
| 10 |
951-10344 |
Push Rod Kit Price: $16.42 |
| 10 |
951-11629 |
PUSH ROD GUIDE Price: $7.04 |
| 11 |
951-10345 |
Valve Kit Not Available Price: |
| 12 |
951-10370 |
Oil Drain Plug and Washer Assembly Price: $7.96 |
| 13 |
951-10366 |
Ignition Coil Price: $96.78 |
| 14 |
951-10310 |
Carburetor Assembly Price: $98.96 |
| 15 |
751P10307A |
WOODRUFF KEY This part replaces 951-10307. Price: $2.01 |
| 16 |
951-10412B |
Air Cleaner Housing Assy Comp This part replaces 951-10412. Price: $34.32 |
| 17 |
951-10342 |
Muffler Stud Assembly Price: $8.66 |
| 18 |
951-10364 |
Fuel Line Kit - Inc. hoses, clamps & filter Price: $25.25 |
| 19 |
951-12296A |
FUEL FILTER This part replaces 951-10358. Price: $8.68 |
| 20 |
951-10300 |
Fuel Cap Assembly Price: $10.24 |
| 21 |
951-10299A |
Recoil Starter This part replaces 951-10299. Price: $60.89 |
| 22 |
951-10298 |
Air Cleaner Kit Price: $15.94 |
| 23 |
951-10297 |
Air Cleaner Thumb Screw Price: $5.34 |
| 24 |
951-10411 |
Muffler Guard Not Available Price: |
| 25 |
951-10403 |
Muffler Price: $72.42 |
| 26 |
951-10402 |
Muffler Gasket /Heat Shield Price: $16.75 |
| 27 |
951-10387 |
Governor Return Spring Price: $6.54 |
| 28 |
951-10292A |
SPARK PLUG (F6RTC/RN11YC/BPR6ES) This part replaces 951-10292. Price: $6.35 |
| 29 |
951-11258A |
THROTTLE SPRING Price: $3.81 |
| 29 |
951-11259 |
THROTTLE LINKAGE ROD Price: $6.88 |
| 503443201 |
591375401 |
KIT FUEL FILTER This part replaces 503443201. Price: $8.99 |
| 503735801 |
503735801 |
FUEL TANK BUSHING Price: $5.99 |
| 503911001 |
503911001 |
SUPPORT Price: $6.99 |
| 503936601 |
503936601 |
AIR PURGE BUBBLE Price: $9.99 |
| 537042401 |
537042401 |
HOSE.FUEL L=102 Price: $3.99 |
| 537051101 |
537184901 |
O-RING This part replaces 537051101. Price: $3.99 |
| 537052301 |
537052301 |
HOSE Price: $6.99 |
| 537068601 |
537068602 |
FUEL TANK This part replaces 537068601. Price: $39.99 |
