| Ref | Part Number | Description |
|---|
| 1 |
104-4620 |
SEAT Price: $273.15 |
| 1 |
532059192 |
VALVE CAP Price: $4.99 |
| 1 |
581578901 |
DECAL.FENDER.WARNING.ENGLISH Price: $3.99 |
| 2 |
100-4928 |
BELT-SEAT Price: $280.73 |
| 2 |
532065139 |
VALVE STEM LT Price: $5.99 |
| 2 |
581627301 |
DECAL.BADGE.170MM.TEXTLOGO. Price: $11.99 |
| 3 |
3234-14 |
SCREW-HHF Price: $0.61 |
| 3 |
532441481 |
DECAL.SDPNL.YTH20K46.SET Price: $3.99 |
| 4 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 5 |
532423829 |
DECAL.WARNING.CUST.RESP.E85. Price: $14.99 |
| 5 |
92-8990 |
ADJUSTER-SLAVE Price: $54.82 |
| 6 |
92-8991 |
ADJUSTER (W/LATCH) Price: $73.04 |
| 7 |
3212-4 |
SCREW-HH Price: $2.73 |
| 8 |
3253-6 |
WASHER-LOCK Price: $0.39 |
| 8 |
532104757 |
CAP.HUB.FRONT.LT.BLACK This part replaces 532175039. Price: $3.99 |
| 9 |
532145005 |
DECAL BTRY SYMBOLS Price: $3.99 |
| 9 |
92-6282 |
SWITCH-SEAT Price: $31.99 |
| 10 |
32144-10 |
SCREW-HWH Price: $4.29 |
| 10 |
581579501 |
DECAL.MOWER.WARN.KEEP.HAND.AWY Price: $3.99 |
| 11 |
104-0467-03 |
STRAP-SUPPORT, SEAT Price: $165.70 |
| 12 |
531229001 |
DECAL.DECK.BELT.ROUTE.42"2021 This part replaces 581580001. Price: $1.99 |
| 12 |
95-8896 |
FOAM Price: $32.41 |
| 13 |
3234-11 |
SCREW-HHF Price: $1.23 |
| 14 |
104-0466 |
SPACER-TUBE Price: $27.25 |
| 15 |
323-14 |
SCREW-HH Price: $1.34 |
| 16 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 17 |
121-3644-03 |
SHIELD-HEAT Price: $73.25 |
| 18 |
92-7307 |
LH ARMREST ASM Price: $200.08 |
| 19 |
92-7306 |
RH ARMREST ASM Price: $198.41 |
| 20 |
121-3646-03 |
BRACKET-LINE, FUEL Price: $60.02 |
| 21 |
121-3645-03 |
BRACKET-LINE, FUEL Price: $31.94 |
| 22 |
321-2 |
SCREW-HH Price: $2.79 |
| 23 |
3234-13 |
SCREW-HHF Price: $0.77 |
| 24 |
104-7201 |
NUT-HF Price: $0.69 |
