| Ref | Part Number | Description |
|---|
| 1 |
603003957 |
DIODE, GENERAL PURPOSE, 6.0A Price: $9.99 |
| 1 |
683-04256-0637 |
Muffler Shield Price: $51.71 |
| 1 |
93-3102 |
CAP-FUEL Price: $24.02 |
| 2 |
114-4680 |
TANK ASM This part replaces 93-2225. Price: $402.21 |
| 2 |
531308376 |
HARNESS, RESTYLE GAS, FRONT Price: $279.99 |
| 2 |
710-0227 |
Hex Washer Screw, #8-18 x .5 Price: $3.90 |
| 3 |
240-11 |
BUSHING-FLANGE Price: $5.32 |
| 3 |
710-04683C |
Hex Washer Screw, 3/8-16 x 1.00 This part replaces 710-04683. Price: $5.67 |
| 4 |
710-0599 |
Hex Washer Screw, 1/4-20 x .5 Price: $3.86 |
| 4 |
93-4637 |
WASHER-FLAT Price: $1.83 |
| 5 |
710-1652 |
Hex Washer Screw, 1/2-20 x .625 Price: $3.86 |
| 6 |
32144-14 |
SCREW-HWHTF Price: $4.29 |
| 6 |
710-3008 |
SCREW 5/16-18 x .75 GR5 Price: $3.76 |
| 7 |
712-3005 |
Nut, Hex Flange Lock, 3/8-16 GR5 This part replaces 912-3005. Price: $5.99 |
| 8 |
725-0157 |
Cable Tie Price: $3.46 |
| 9 |
56-2520 |
FITTING-SHUT OFF, FUEL Price: $31.19 |
| 9 |
726-0205 |
Hose Clamp Price: $3.71 |
| 10 |
2412-36 |
CLAMP-HOSE Price: $1.28 |
| 10 |
728-04000 |
Pop Rivet, .188 x .3 Price: $5.99 |
| 11 |
112-0212 |
FITTING-FUEL This part replaces 93-2299. Price: $46.70 |
| 11 |
736-0300 |
Fl-Wash .385 I.D. x .87 O.D. This part replaces 936-0300. Price: $3.93 |
| 12 |
751-0564B |
Muffler Deflector Price: $12.14 |
| 13 |
751-10017 |
Pipe Exhaust Price: $74.49 |
| 13 |
94-1364-03 |
PLATE ASM Price: $155.56 |
| 14 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 14 |
951-10162 |
MUFFLER (SINGLE INLET) This part replaces 751-10162. Price: $74.35 |
| 15 |
751-22813-36 |
FUEL HOSE 1/4-36" This part replaces 751-10349-28. Price: $41.21 |
| 16 |
33115-020 |
SCREW-HH Price: $0.88 |
| 16 |
751-11053B |
EXHAUST DELECTOR (LONG) This part replaces 751-10353. Price: $4.64 |
| 17 |
951-10517A |
Drain, Oil This part replaces 951-10517. Price: $22.67 |
| 18 |
110-7504 |
HOSE-FUEL This part replaces 94-4353. Price: $4.42 |
| 18 |
751-3141-14 |
Oil Drain Extension Hose Price: $10.40 |
| 19 |
2412-41 |
CLAMP-R Price: $4.82 |
| 19 |
783-04870-0637 |
MUFFLER BRACKET (LH) Not Available Price: |
| 20 |
783-04872-0637 |
MUFFLER BRACKET (RH) Not Available Price: |
| 20 |
92-5753 |
CLAMP-HOSE Price: $2.10 |
| 22 |
92-2379 |
CLAMP-HOSE Price: $0.34 |
| 23 |
93-2298 |
HOSE-FUEL Price: $10.13 |
| 24 |
56-2230 |
HOSE-FUEL Price: $3.66 |
| 25 |
237-124 |
GROMMET Price: $2.30 |
| 26 |
2412-108 |
CLAMP-WORM Price: $1.29 |
