| Ref | Part Number | Description |
|---|
| 1 |
108-0638 |
BOTTLE-OVERFLOW Price: $33.20 |
| 2 |
589818702 |
MUFFLER.ASM.TWIN.MNTG.BRACKET This part replaces 589818701. Price: $44.99 |
| 2 |
92-2379 |
CLAMP-HOSE Price: $0.34 |
| 3 |
110-3257 |
HOSE-FUEL Price: $17.26 |
| 4 |
340-142 |
FITTING-ELBOW-90 Price: $65.90 |
| 5 |
110-5275 |
SEAL-FOAM Price: $17.84 |
| 6 |
110-5310-01 |
BRACKET-MOUNTING Price: $55.86 |
| 7 |
110-5276 |
SEAL-FOAM Price: $16.24 |
| 8 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 9 |
2412-129 |
CLAMP-HOSE Price: $2.10 |
| 9 |
596501502 |
Keepers This part replaces 501832602. Price: $9.99 |
| 10 |
117-8093 |
RADIATOR ASM Price: $2,185.13 |
| 11 |
110-5251-03 |
FRAME-RADIATOR Price: $733.84 |
| 11 |
592821701 |
CLUTCH MAGNETIC CLUTCH & BRAKE Price: $279.99 |
| 12 |
3234-30 |
SCREW-HHF Price: $0.41 |
| 12 |
532405097 |
PULLEY.ENGINE.TUFFTORQ Price: $49.99 |
| 13 |
108-1666-0P |
BRACKET - RESERVOIR This part replaces 108-1666-03. Price: $20.32 |
| 14 |
110-8942 |
HOSE-FORMED Price: $85.85 |
| 15 |
110-8943 |
HOSE-FORMED Price: $75.79 |
| 15 |
583507201 |
TANK.ASSY.XTERNAL.FILL.GT2.TEX This part replaces 532435816. Price: $129.99 |
| 16 |
110-5311 |
SHROUD-FAN Price: $369.24 |
| 17 |
3269-15 |
RIVET-POP Price: $0.54 |
| 18 |
3234-5 |
SCREW-HHF Price: $0.42 |
| 18 |
532441462 |
CAP.ASM.FUEL.2.25"TOP.TURN Price: $11.99 |
| 19 |
115-1554 |
LATCH-DRAW Price: $38.46 |
| 20 |
32104-32 |
SCREW-HWH Price: $1.99 |
| 21 |
110-0485 |
COOLER-OIL Price: $706.30 |
| 21 |
596321701 |
Screws Price: $2.99 |
| 22 |
104-7851 |
FITTING-HYD, 45 DEG Price: $62.28 |
| 22 |
532191596 |
CONTROL.CHOKE.ERGO.PUSH-IN.BLA Price: $32.99 |
| 23 |
110-5269-03 |
SCREEN Price: $1,472.37 |
| 24 |
93-6028 |
PLATE-LOGO Price: $13.70 |
| 25 |
94-2638 |
NUT-FLAT Price: $0.54 |
| 26 |
115-1556 |
PIN-BALL, DETENT Price: $8.01 |
| 27 |
110-4104 |
HOSE-FUEL Price: $8.95 |
| 28 |
2412-34 |
CLAMP-HOSE Price: $2.14 |
| 28 |
587044820 |
HOSE 1/4" LOW PERMEATION FUEL This part replaces 532137040. Price: $9.99 |
| 29 |
32128-49 |
NUT-HHF Price: $1.04 |
| 29 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 30 |
104-5460-03 |
PLATE-MOUNT, OIL COOLER Price: $19.12 |
| 31 |
3234-14 |
SCREW-HHF Price: $0.61 |
| 32 |
104-5429 |
CLAMP-FORM, WIRE Price: $11.80 |
| 33 |
325-17 |
SCREW-HH Price: $2.90 |
| 34 |
41-8440 |
WASHER Price: $1.49 |
| 35 |
108-1665-0P |
BRACKET - RESERVIOR This part replaces 108-1665-03. Price: $13.72 |
| 36 |
110-8955 |
HOSE Price: $36.39 |
| 37 |
3234-13 |
SCREW-HHF Price: $0.77 |
| 37 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 38 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 39 |
108-1843-0P |
SCREEN - AIR INTAKE This part replaces 108-1843-03. Price: $35.29 |
| 40 |
104-5428 |
BRACKET-OIL COOLER, TOP Price: $50.73 |
| 41 |
110-5324 |
SEAL-FOAM Price: $16.15 |
| 41 |
532126197 |
WASHER Price: $6.99 |
| 42 |
1-603903 |
SPACER Price: $4.99 |
| 42 |
596238901 |
Washers Price: $2.99 |
| 43 |
3234-36 |
SCREW-HHF Price: $0.75 |
| 45 |
596133601 |
Hardware Price: $2.99 |
| 62 |
531154901 |
SERVICE KIT HEAT SHIELD This part replaces 532434017. Price: $11.99 |
| 69 |
532178151 |
GASKET Price: $4.99 |
| 70 |
583955601 |
TUBE.EXHAUST.LH.FR961/FR730 Price: $24.99 |
| 71 |
583955701 |
TUBE.EXHAUST.RH.FR961/FR730 Price: $24.99 |
| 81 |
532148456 |
TUBE, DRAIN OIL ASM. Price: $5.99 |
| 84 |
817120616 |
SCREW 3/8-16X1 Price: $4.99 |
| 85 |
501606601 |
BOLT.HEX.7/16-20X3.75.GR5.RED Price: $3.99 |
| 86 |
532184362 |
NUT.HEX.FLANGE.TOPLOCK Price: $3.99 |
| 90 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 96 |
596135301 |
Washers Price: $2.99 |
| 97 |
817670412 |
SCREW HEXWSHR 1/4-20X3/4 Price: $3.99 |
| 102 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 116 |
539132624 |
KNOB - SHIFT Price: $6.99 |
| 137 |
532441461 |
SPILL.CUP Price: $7.99 |
