| Ref | Part Number | Description |
|---|
| 1 |
108-0638 |
BOTTLE-OVERFLOW This part replaces 104-9318. Price: $33.20 |
| 2 |
589818702 |
MUFFLER.ASM.TWIN.MNTG.BRACKET This part replaces 589818701. Price: $44.99 |
| 2 |
92-2379 |
CLAMP-HOSE Price: $0.34 |
| 3 |
110-3257 |
HOSE-FUEL Price: $17.26 |
| 4 |
110-0967 |
SEAL-FOAM Price: $14.99 |
| 7 |
100-4869 |
COOLER-OIL Price: $791.17 |
| 9 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 9 |
596501502 |
Keepers This part replaces 501832602. Price: $9.99 |
| 10 |
2412-34 |
CLAMP-HOSE Price: $2.14 |
| 11 |
110-0968 |
SEAL-FOAM Price: $12.29 |
| 11 |
587255001 |
CLUTCH. 5.0 PD. 2.5 OFFSET Price: $229.99 |
| 12 |
32128-49 |
NUT-HHF Price: $1.04 |
| 12 |
586899601 |
PULLEY.EXTENDED.SHAFT.GROUND Price: $29.99 |
| 13 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 14 |
104-5460-03 |
PLATE-MOUNT, OIL COOLER Price: $19.12 |
| 15 |
105-3943 |
CLAMP-COOLER, OIL Price: $8.70 |
| 16 |
2412-129 |
CLAMP-HOSE Price: $2.10 |
| 17 |
322-10 |
SCREW-HH Price: $0.70 |
| 18 |
104-5429 |
CLAMP-FORM, WIRE Price: $11.80 |
| 19 |
325-17 |
SCREW-HH Price: $2.90 |
| 20 |
41-8440 |
WASHER Price: $1.49 |
| 20 |
587631703 |
THROTTLE.KOHL.PRO.#88PAD_46" Price: $27.99 |
| 21 |
119-6956 |
RADIATOR ASM Price: $1,856.53 |
| 21 |
596321701 |
Screws This part replaces 532416358. Price: $2.99 |
| 22 |
127-2665-03 |
FRAME-SUPPORT, RADIATOR This part replaces 108-1617-03. Price: $573.73 |
| 22 |
532191596 |
CONTROL.CHOKE.ERGO.PUSH-IN.BLA Price: $32.99 |
| 23 |
108-1665-0P |
BRACKET - RESERVIOR This part replaces 108-1665-03. Price: $13.72 |
| 24 |
108-1666-0P |
BRACKET - RESERVOIR This part replaces 108-1666-03. Price: $20.32 |
| 25 |
108-1696 |
HOSE-FORMED Price: $35.18 |
| 26 |
108-1697 |
HOSE-FORMED Price: $38.62 |
| 27 |
108-1791 |
SHROUD-FAN Price: $328.36 |
| 28 |
108-1693 |
HOSE Price: $60.11 |
| 28 |
587044864 |
HOSE 1/4" LOW PERMEATION FUEL Price: $17.99 |
| 29 |
3269-15 |
RIVET-POP Price: $0.54 |
| 29 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 30 |
3234-5 |
SCREW-HHF Price: $0.42 |
| 31 |
115-1554 |
LATCH-DRAW Price: $38.46 |
| 32 |
32104-32 |
SCREW-HWH Price: $1.99 |
| 33 |
3234-13 |
SCREW-HHF Price: $0.77 |
| 34 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 35 |
322-21 |
SCREW-HH Price: $4.29 |
| 36 |
110-0952-03 |
SCREEN ASM Price: $1,010.39 |
| 37 |
108-1843-0P |
SCREEN - AIR INTAKE This part replaces 108-1843-03. Price: $35.29 |
| 37 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 38 |
110-4104 |
HOSE-FUEL Price: $8.95 |
| 39 |
107-2043-03 |
BRACKET-OIL COOLER, TOP Price: $51.21 |
| 40 |
93-6028 |
PLATE-LOGO Price: $13.70 |
| 41 |
532126197 |
WASHER Price: $6.99 |
| 41 |
94-2638 |
NUT-FLAT Price: $0.54 |
| 42 |
110-5324 |
SEAL-FOAM Price: $16.15 |
| 42 |
596238901 |
Washers This part replaces 539990247. Price: $2.99 |
| 43 |
1-603903 |
SPACER Price: $4.99 |
| 44 |
3234-36 |
SCREW-HHF Price: $0.75 |
| 45 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 46 |
93-7272 |
DECAL-WARNING Price: $6.37 |
| 47 |
106-6755 |
DECAL-CAP, RADIATOR Price: $18.49 |
| 48 |
3290-378 |
TIE-CABLE Price: $0.79 |
| 62 |
531154901 |
SERVICE KIT HEAT SHIELD This part replaces 532434017. Price: $11.99 |
| 69 |
532186054 |
GASKET.EXHAUST.KOHL.CV18-CV26 Price: $5.99 |
| 70 |
583954501 |
PIPE.EXHAUST.LH.CV18/20 Price: $19.99 |
| 71 |
583954801 |
PIPE.EXHAUST.RH.CV18/20 Price: $17.99 |
| 81 |
532148456 |
TUBE, DRAIN OIL ASM. Price: $5.99 |
| 82 |
532428287 |
VALUE.OIL.DRAIN Price: $14.99 |
| 84 |
817120616 |
SCREW 3/8-16X1 Price: $4.99 |
| 85 |
501606701 |
BOLT.HEX.7/16-20X5.GR5.GREEN Price: $7.99 |
| 86 |
532184362 |
NUT.HEX.FLANGE.TOPLOCK Price: $3.99 |
| 90 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 91 |
532187495 |
BUSHING.1.375OD Price: $4.99 |
| 102 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 109 |
585977401 |
CANISTER CARB, FLEX TECH, 6.3 Price: $39.99 |
| 110 |
532414118 |
VALVE.ASM.ANTI-SLOSH Price: $19.99 |
| 113 |
597791601 |
VALVES This part replaces 532414127. Price: $9.99 |
| 117 |
532420828 |
VALVE FUEL RESERVE Price: $27.99 |
| 138 |
587044580 |
Hoses This part replaces 532414119. Price: $9.99 |
| 140 |
585977301 |
BRACKET BRACKET, CARBON CAN, F Price: $5.99 |
