| Ref | Part Number | Description |
|---|
| 1 |
119-0816 |
ENGINE-YAMAHA, MZ360 GAS Price: $1,200.14 |
| 2 |
104-6478 |
SPRING-EXTENSION Price: $13.02 |
| 3 |
104-6511 |
MANIFOLD Price: $196.42 |
| 4 |
119-0746 |
MUFFLER Price: $453.97 |
| 5 |
119-0716 |
PIPE-EXHAUST, KOHLER Price: $118.64 |
| 6 |
323-8 |
SCREW-HH Price: $1.20 |
| 7 |
138-0090 |
CLUTCH-PRIMARY, MD This part replaces 119-0802. Price: $529.76 |
| 8 |
119-0710 |
BELT-VARIABLE Price: $95.35 |
| 9 |
112-3131 |
BELT-STARTER Price: $25.86 |
| 10 |
323-30 |
SCREW-HH Price: $22.99 |
| 11 |
94-2690 |
FILTER-FUEL Price: $4.69 |
| 13 |
131-8444 |
STARTER/GENERATOR ASM This part replaces 119-9545. Price: $426.18 |
| 14 |
121-6277 |
PULLEY-DRIVE This part replaces 119-9482. Price: $28.48 |
| 16 |
2412-98 |
CLAMP-HOSE Price: $1.39 |
| 17 |
107-0588 |
HOSE-FUEL Price: $5.67 |
| 18 |
99-7377 |
CONDUIT-LINE, FUEL Price: $8.09 |
| 19 |
95-5806 |
BRACKET-MOUNTING Price: $28.01 |
| 20 |
115-8125 |
HARNESS-WIRE, ENGINE Price: $93.34 |
| 21 |
119-0707-03 |
TRAY-ENGINE Price: $414.77 |
| 22 |
122-1176 |
CABLE-BATTERY, NEGATIVE This part replaces 99-7403. Price: $19.85 |
| 23 |
119-0863-0P |
BRKT-AIR CLEANER, KOHLER This part replaces 119-0863-03. Price: $26.62 |
| 24 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 25 |
112-6950 |
SCREW-CARR Price: $0.59 |
| 26 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 27 |
2412-130 |
CLAMP-HOSE Price: $2.57 |
| 28 |
2412-111 |
CLAMP Price: $4.39 |
| 31 |
119-0724 |
WASHER-FLANGE Price: $13.38 |
| 32 |
119-0721 |
SCREW-HH Price: $1.97 |
| 33 |
63-9750 |
MOUNT Price: $18.92 |
| 34 |
2844 |
WASHER Price: $2.69 |
| 35 |
119-9502 |
GRILL-ENGINE Price: $51.76 |
| 36 |
3256-78 |
WASHER-FLAT Price: $1.21 |
| 37 |
33103-012 |
SCREW-HHF Price: $3.21 |
| 38 |
112-3247 |
HOSE-INTAKE This part replaces 115-7983. Price: $47.77 |
| 39 |
3234-36 |
SCREW-HHF Price: $0.75 |
| 40 |
2412-36 |
CLAMP-HOSE Price: $1.28 |
| 41 |
99-7120 |
AIR CLEANER ASM Price: $118.01 |
| 42 |
74-9120 |
HOSE-OVERFLOW, RADIATOR Price: $9.97 |
| 43 |
115-7625 |
HOSE-INTAKE Price: $50.21 |
| 44 |
323-9 |
SCREW-HH Price: $1.29 |
| 45 |
99-7230 |
FITTING-90 DEG Price: $35.12 |
| 46 |
3296-69 |
NUT-LOCK, NI Price: $0.84 |
| 47 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 48 |
2412-89 |
CLAMP-R Price: $2.09 |
| 51 |
32180-030 |
CLIP-TIE Price: $4.19 |
| 52 |
3290-378 |
TIE-CABLE Price: $0.79 |
| 53 |
120-9738 |
SCREW-HH This part replaces 322-11. Price: $0.84 |
| 54 |
100335 |
WIRE-GROUND Price: $15.97 |
| 55 |
3254-6 |
WASHER-LOCK, INTERNAL Price: $0.31 |
