Carburetor
Parts (31)
| Ref | Part Number | Description |
|---|---|---|
| 1 | 121-4697 | BRUSH SHAFT ASM Price: $320.58 |
| 1 | 921722091 | Screw m3x12 Price: $1.99 |
| 2 | 110-2321 | BRUSH-GROOMER Price: $122.80 |
| 2 | 320852105 | Stopper Price: $2.99 |
| 3 | 120-9657 | BOLT-J Price: $6.72 |
| 3 | 120222059 | Valve-Reed Price: $7.99 |
| 4 | 160732235 | Insulator Price: $8.99 |
| 5 | 920092235 | Screw m5x25 Price: $1.99 |
| 6 | 110612160 | Gasket-carb. "B" Price: $6.99 |
| 7 | 110612150 | Gasket-Insulator "A" Price: $2.99 |
| 8 | 110612196 | Gasket "C" Price: $9.99 |
| 9 | 150042034 | Assy-Carburetor Price: $129.99 |
| 10 | 920092277 | Screw "A" Price: $1.99 |
| 11 | 110532066 | Bracket Price: $8.99 |
| 12 | 210832073 | Arm Price: $3.99 |
| 13 | 922002074 | Washer Price: $1.99 |
| 14 | 920332078 | Ring-Snap Price: $1.99 |
| 15 | 920552147 | O-Ring Price: $3.99 |
| 16 | 920632480 | Jet-Main #56 Price: $7.99 |
| 17 | 921442308 | Spring Price: $2.99 |
| 18 | 920432094 | Pin Price: $1.99 |
| 19 | 110612054 | Gasket Price: $4.99 |
| 20 | 430282067 | Diaphragm Price: $4.99 |
| 21 | 161602138 | Body Price: $32.99 |
| 22 | 140432051 | Filter Price: $2.99 |
| 23 | 920092336 | Screw Price: $1.99 |
| 24 | 160302078 | Valve-Float Price: $11.99 |
| 25 | 160552051 | Lever Price: $2.99 |
| 26 | 110602456 | Gasket Price: $3.99 |
| 27 | 430282090 | Diaphragm Price: $17.99 |
| 28 | 140252157 | Cover Price: $3.99 |
