| Ref | Part Number | Description |
|---|
| 1 |
27-4720 |
SHAFT-PIVOT, SEAT Price: $32.27 |
| 1 |
530015880 |
Screw Price: $1.99 |
| 2 |
27-9780 |
DISCONTINUED Price: Call Us |
| 2 |
530058982 |
Bolt-Muffler Price: $1.99 |
| 3 |
107-3039 |
PIN-LYNCH This part replaces 3290-243. Price: $6.96 |
| 4 |
27-9880 |
DISCONTINUED Price: Call Us |
| 4 |
530015953 |
Screw-Cylinder Price: $1.99 |
| 5 |
27-9870 |
PIN-SWITCH, SEAT Price: $31.55 |
| 5 |
952030249 |
Spark Plug (RCJ 6Y) Price: $3.99 |
| 6 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 6 |
530012541 |
Cylinder Price: $11.99 |
| 7 |
3272-6 |
PIN-COTTER Price: $0.25 |
| 7 |
530071750 |
Seal-Cylinder (kit) Price: $8.99 |
| 8 |
545154001 |
RING PISTON This part replaces 530055120. Price: $1.99 |
| 8 |
71-4490 |
SEAT SUPT BRKT WA *R This part replaces 27-9830. Price: $142.74 |
| 9 |
3217-11 |
NUT-HEX Price: $0.95 |
| 9 |
530015162 |
Retainer-Piston Pin Price: $1.99 |
| 10 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 11 |
323-12 |
SCREW-HH Price: $1.14 |
| 11 |
530012555 |
Assy-Crankshaft Price: $17.99 |
| 12 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 13 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 13 |
530071750 |
Seal-Cyl/Carb.(kit) Price: $8.99 |
| 14 |
27-9810-01 |
SEAT PIVOT ASM This part replaces 27-9810. Price: $80.36 |
| 14 |
530057547 |
Adapter-Carb. Price: $7.99 |
| 15 |
32121-4 |
PIN-ROLL, SLOTTED Price: $3.49 |
| 15 |
530016309 |
Screw Price: $1.99 |
| 16 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 16 |
530071750 |
Gasket-Carb. (kit) Price: $8.99 |
| 17 |
530071822 |
KIT CARB ASSY # C1U-W24 This part replaces 530071752. Price: $29.99 |
| 17 |
HY3225 |
DISCONTINUED This part replaces 322-5. Price: Call Us |
| 18 |
28-0570 |
SPRING-COMPRESSION Price: $33.04 |
| 18 |
530057544 |
Air Box Price: $6.99 |
| 19 |
29-6930 |
DISCONTINUED-SEE PB#936 This part replaces 27-7250. Price: Call Us |
| 19 |
530016429 |
Screw Price: $1.99 |
| 20 |
321-2 |
SCREW-HH Price: $2.79 |
| 20 |
530036575 |
Foam-Air Filter Price: $1.99 |
| 21 |
32121-6 |
PIN-ROLL, SLOTTED Price: $0.28 |
| 21 |
530058740 |
Cover-Air Box Price: $5.99 |
| 22 |
545081826 |
Kit - Ignition Module Price: $32.99 |
| 23 |
530027953 |
Coupling-Drive Price: $1.99 |
| 24 |
530016357 |
Screw Price: $1.99 |
| 25 |
530014663 |
Assy-Leadwire Price: $5.99 |
| 26 |
581425901 |
SWITCH, GROUND WIRE This part replaces 530014662. Price: $1.99 |
| 27 |
530016391 |
Screw Price: $1.99 |
| 28 |
530071735 |
Assy.-Fan Hsg Price: $17.99 |
| 29 |
530071356 |
Kit-Switch Price: $4.99 |
| 30 |
530058742 |
Handle-Starter Price: $2.99 |
| 31 |
530071798 |
Kit - Rope Price: $3.99 |
| 32 |
530016386 |
SCREW This part replaces 530015810. Price: $5.99 |
| 33 |
545008011 |
KIT STARTER SPRING This part replaces 545213601. Price: $5.99 |
| 34 |
545081852 |
Kit - Starter Pulley This part replaces 530071797. Price: $9.99 |
| 35 |
530057548 |
Baffle Price: $6.99 |
| 36 |
530015880 |
Screw Price: $1.99 |
| 37 |
530015828 |
Washer-Flat Price: $1.99 |
| 38 |
545221701 |
FLYWHEEL ASSY This part replaces 530054115. Price: $8.99 |
| 40 |
530015941 |
Retain. Ring-C'shaft Price: $1.99 |
| 41 |
530055728 |
Outer Bearing Price: $6.99 |
| 42 |
530019264 |
Seal Price: $2.99 |
| 43 |
530032125 |
Inner Bearing Price: $11.99 |
| 45 |
530049817 |
CONNECTING ROD ASSY This part replaces 530069945. Price: $6.99 |
| 46 |
530071750 |
O-Ring-C'case (kit) Price: $8.99 |
| 48 |
530016386 |
Screw Price: $5.99 |
| 49 |
530058737 |
Shroud-Rear Price: $7.99 |
| 50 |
530016431 |
Retainer-Tank Price: $3.99 |
| 52 |
530058743 |
Assy-Fuel Cap Price: $7.99 |
| 53 |
530069247 |
Kit-Fuel Line (Small) Price: $3.99 |
| 54 |
530069216 |
Kit-Fuel Line (Large) Price: $3.99 |
| 55 |
530095646 |
Assy-Fuel Pickup Price: $2.99 |
