| Ref | Part Number | Description |
|---|
| 1 |
104-0402 |
TUBE-HYD Price: $147.93 |
| 1 |
598602801 |
Decks This part replaces 532196495. Price: $349.99 |
| 2 |
340-70 |
NUT-LOCK Price: $2.10 |
| 3 |
340-68 |
FITTING-TEE, BULKHEAD Price: $36.00 |
| 4 |
104-0407 |
HOSE-HYD Price: $126.67 |
| 5 |
340-77 |
FITTING-ELBOW, 90 DEG Price: $24.95 |
| 6 |
100-4891 |
HOSE-HYD Price: $161.55 |
| 6 |
529846401 |
SERVICE.KIT ARM.SUSPENSION.MOW This part replaces 532195186. Price: $14.99 |
| 7 |
104-0403 |
TUBE ASM Price: $145.25 |
| 7 |
596321701 |
Screws This part replaces 532191611. Price: $2.99 |
| 8 |
340-71 |
FITTING-STRAIGHT, BULKHEAD Price: $20.74 |
| 8 |
532193003 |
BOLT.WASHER.ASM.7/16-2 Price: $6.99 |
| 10 |
112-9916 |
HYD CYLINDER ASM Price: $752.66 |
| 11 |
3-6498 |
WASHER-THRUST Price: $4.58 |
| 13 |
340-74 |
NUT-LOCK, BULKHEAD Price: $4.83 |
| 13 |
587819701 |
KIT.MANDREL.NONGREASE.TALL This part replaces 532192872. Price: $49.99 |
| 14 |
340-72 |
FITTING-BULKHEAD, 90 DEG Price: $41.27 |
| 14 |
587819701 |
KIT.MANDREL.NONGREASE.TALL This part replaces 532187281. Price: $49.99 |
| 15 |
100-4879 |
HOSE-HYD Price: $272.03 |
| 15 |
532110485 |
BEARING Price: $11.99 |
| 16 |
115-3411 |
HOSE-HYD Price: $114.49 |
| 16 |
531167701 |
SERVICE KIT MANDREL STRIPPER This part replaces 532174493. Price: $6.99 |
| 17 |
104-0401 |
TUBE ASM Price: $210.81 |
| 18 |
104-0400 |
TUBE ASM Price: $175.47 |
| 19 |
104-0404 |
TUBE ASM Price: $142.78 |
| 19 |
532196539 |
BOLT.SHOULDER Price: $5.99 |
| 20 |
531167001 |
SERVICE KIT BAFFLE.VORTEX BAFF This part replaces 532159770. Price: $11.99 |
| 20 |
99-3641 |
CLAMP-TUBE Price: $5.90 |
| 21 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 21 |
596040501 |
Hardware This part replaces 873680500. Price: $2.99 |
| 22 |
321-11 |
SCREW-HH Price: $0.36 |
| 23 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 23 |
532192557 |
BRKT.DEFLECTOR.38"2005+ Price: $7.99 |
| 24 |
532105304 |
CAP-SLEEVE LT Price: $3.99 |
| 24 |
95-8990 |
SHAFT-PIVOT, REAR Price: $75.06 |
| 25 |
3220-9 |
NUT-JAM Price: $11.71 |
| 25 |
532197026 |
SPRING.TORSION.DEFLECT Price: $8.99 |
| 26 |
532110452 |
NUT PUSH M Price: $2.99 |
| 26 |
86-1480 |
WASHER Price: $4.82 |
| 27 |
136-3415 |
REAR LIFTARM ASM This part replaces 115-3473. Price: $685.84 |
| 27 |
532403004 |
SHIELD.DEFLECTOR.MOWER.42"BLAC Price: $29.99 |
| 28 |
3234-27 |
SCREW-HHF Price: $5.97 |
| 29 |
595297001 |
Rods This part replaces 532131491. Price: $4.99 |
| 29 |
75-7730 |
WASHER-THRUST Price: $2.88 |
| 30 |
584953901 |
BOLT.HEX.WASHR.HED.313-18X1.19 This part replaces 532173984. Price: $3.99 |
| 31 |
100-4944 |
SHAFT-PIVOT, CUTTING UNIT Price: $87.73 |
| 31 |
532187690 |
WASHER.SPACER.MANDREL Price: $3.99 |
| 32 |
323-6 |
SCREW-HH Price: $0.66 |
| 32 |
532195945 |
PULLEY.MANDREL.5.438.P Price: $12.99 |
| 33 |
323-4 |
SCREW-HH Price: $1.02 |
| 33 |
596134801 |
Nuts This part replaces 532400234. Price: $1.00 |
| 34 |
596136101 |
GSPW Bolts This part replaces 872110612. Price: $2.99 |
| 34 |
63-7400 |
WASHER-REBOUND Price: $1.70 |
| 35 |
3-6781 |
WASHER-THRUST Price: $1.40 |
| 36 |
283-71 |
PIN-LYNCH Price: $2.73 |
| 36 |
532196106 |
PULLEY.IDLER.2006 Price: $34.99 |
| 37 |
596565301 |
WASHER PLAIN WASHER 3/8 X 0.08 This part replaces 819131316. Price: $2.99 |
| 40 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $3.99 |
| 42 |
121-3616-03 |
GUARD Price: $35.32 |
| 42 |
532198410 |
SPRING.TORSION.BRAKE Price: $4.99 |
| 43 |
32136-4 |
NUT-HEX,SLOTTED This part replaces 322-12. Price: $1.56 |
| 43 |
532197256 |
SRPING.TORSION.RETAINE Price: $4.99 |
| 44 |
322-3 |
SCREW-HH Price: $0.79 |
| 45 |
32128-20 |
NUT-HF Price: $0.99 |
| 46 |
32120-93 |
RING-RETAINING Price: $2.49 |
| 46 |
532137729 |
SCREW.1/4-20X5/8 Price: $3.99 |
| 47 |
532197250 |
BRKT.CLUTCH.CABLE Price: $4.99 |
| 47 |
95-8575 |
PIN-CLEVIS Price: $15.31 |
| 49 |
3334-945 |
TIE-CABLE Price: $0.43 |
| 50 |
104-4229 |
REAR CARRIER FRAME ASM Price: $470.75 |
| 51 |
95-8936 |
STRIP-WEAR Price: $93.56 |
| 52 |
3269-18 |
RIVET-BLIND Price: $1.15 |
| 53 |
302-60 |
FITTING-GREASE Price: $2.26 |
| 55 |
531169401 |
SERVICE KIT IDLER.ARM This part replaces 532197249. Price: $5.99 |
| 56 |
532199092 |
SPACER.RETAINER Price: $5.99 |
| 57 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 59 |
531165901 |
SERVICE KIT GUARD This part replaces 532141043. Price: $4.99 |
| 60 |
597074201 |
ARMS This part replaces 532197402. Price: $12.99 |
| 62 |
596136301 |
Bolts This part replaces 872110616. Price: $2.99 |
| 63 |
532199478 |
ARM.BRAKE.ZINC Price: $14.99 |
| 64 |
532199918 |
LINKAGE.BRAKE.ASM.ZINC Price: $11.99 |
| 68 |
592855001 |
Belts This part replaces 532197253. Price: $34.99 |
| 69 |
596136401 |
Bolts This part replaces 872140505. Price: $2.99 |
| 70 |
532401246 |
CLUTCH.ASM.MANUAL.LT.PRED Price: $32.99 |
| 113 |
817000510 |
BOLT.5/16HEX.WHS.HD Price: $4.99 |
| 116 |
596434402 |
Bolts This part replaces 532124842. Price: $3.99 |
| 117 |
589527401 |
WHEEL.GAUGE.RALLY.NARROW This part replaces 532188606. Price: $9.99 |
| 118 |
596322601 |
Nuts This part replaces 873930600. Price: $2.99 |
| 144 |
531169801 |
SERVICE KIT BELT KEEPER This part replaces 532199204. Price: $4.99 |
| 145 |
532177968 |
PULLEY.IDLER.FLAT Price: $27.99 |
| 147 |
532401971 |
RETURN SPRING Price: $4.99 |
| 152 |
532435111 |
CABLE.CLUTCH.MANUAL. This part replaces 532408714. Price: $29.99 |
| 188 |
593824001 |
STUD.W/"D"ANTI-ROTATION This part replaces 532195161. Price: $3.99 |
| 189 |
596135701 |
GSPW Nuts This part replaces 873900500. Price: $2.99 |
| 195 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
