| Ref | Part Number | Description |
|---|
| 1 |
120-6049 |
FRAME AND AXLE ASM Price: $6,666.99 |
| 2 |
119-6224 |
SEE NOTES Price: $361.87 |
| 2 |
532194263 |
DRAWBAR.1PC.NSTL Price: $54.99 |
| 3 |
T0000-3423 |
JACK-SIDEWIND This part replaces 106-9699. Price: $134.35 |
| 4 |
110-7518-03 |
PLATE-HITCH, LH Price: $55.90 |
| 5 |
110-7519-03 |
PLATE-HITCH, RH Price: $68.60 |
| 5 |
532401823 |
DASH.HUSQ.UPR.ELE.SVMD Price: $49.99 |
| 6 |
131-4381-01 |
HITCH-CLEVIS This part replaces 47-3550-03. Price: $161.64 |
| 7 |
327-17 |
SCREW-HH Price: $8.50 |
| 8 |
327-12 |
SCREW-HH Price: $7.26 |
| 9 |
3296-53 |
NUT-LOCK, NI Price: $1.47 |
| 10 |
20-9580 |
ROPE-LATCH Price: $47.65 |
| 11 |
13-6200 |
PIN-HITCH, POINTED Price: $40.83 |
| 14 |
532442396 |
HOOD.ASM.HUSQVARNA.GT.TEX.ORAN This part replaces 532401824. Price: $149.99 |
| 15 |
532198907 |
LENS.LH.TEX.GT.HUSQ.CL Price: $22.99 |
| 17 |
13-6890-01 |
GUIDE-ROPE Price: $119.16 |
| 18 |
13-6910-01 |
SPACER-GUIDE, ROPE Price: $18.39 |
| 18 |
532408607 |
GRILL.ASM.HUSQ.TG/CRD.W/TRIM This part replaces 532404821. Price: $129.99 |
| 19 |
2412-40 |
CLAMP-CONDUIT Price: $6.72 |
| 20 |
32104-95 |
SCREW-HWH Price: $0.41 |
| 21 |
32104-96 |
SCREW-HH Price: $5.59 |
| 22 |
106-0262-01 |
MOUNT-HARNESS Price: $23.39 |
| 23 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 24 |
323-6 |
SCREW-HH Price: $0.66 |
| 25 |
121-2778-03 |
GUARD-BELT Price: $374.83 |
| 25 |
532198906 |
LENS.RH.TEX.GT.HUSQ.CL Price: $32.99 |
| 26 |
121-2784-03 |
GUARD-FOOT Price: $299.44 |
| 27 |
121-2682-03 |
GUARD-BRUSH, LH Price: $56.94 |
| 28 |
121-2683-03 |
COVER-BRUSH, RH Price: $71.29 |
| 30 |
121-2686-03 |
COVER-BRUSH, CENTER Price: $87.34 |
| 31 |
105-4886 |
NUT-TINNERMAN Price: $2.37 |
| 32 |
110-5052 |
SCREW-HHF Price: $1.22 |
| 34 |
121-2706-03 |
SUPPORT-COVER Price: $25.32 |
| 36 |
321-4 |
SCREW-HH Price: $0.99 |
| 36 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK This part replaces 817060512. Price: $4.99 |
| 37 |
532405789 |
FENDER Price: $139.99 |
| 68 |
596030701 |
Screws This part replaces 817490508. Price: $2.99 |
| 99 |
532401003 |
ROD ASM BYPASS Price: $10.99 |
| 102 |
532004497 |
RETAINER M This part replaces 532124788. Price: $4.99 |
| 130 |
596321701 |
Screws This part replaces 532191611. Price: $2.99 |
| 138 |
532439747 |
HOLDER.CUP.LT.GREY This part replaces 532402954. Price: $4.99 |
| 150 |
532198513 |
AIR.DUCT.TEXGT.HUSQ.SV Price: $37.99 |
| 152 |
532194329 |
SHIELD.BROWNING/DEBRIS Price: $17.99 |
| 159 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 161 |
532440029 |
WINDOW.FUEL.LT.TEX.GREY This part replaces 532404941. Price: $11.99 |
| 162 |
596134101 |
Screws This part replaces 532142432. Price: $2.99 |
| 165 |
532400315 |
SUPPORT.TANK.REAR.WIRE Price: $19.99 |
| 176 |
532400776 |
SCREW.#10-24X5/8.RN.QU Price: $4.99 |
| 177 |
532195227 |
BUSHING, STEERING Price: $5.99 |
| 178 |
532199782 |
CARGO.ASM.NET.TXGT.W/C Price: $29.99 |
| 180 |
582033101 |
KITS.TEX.BOLTED.CHASSIS.445559 This part replaces 532194260. Price: $229.99 |
| 181 |
532403025 |
BUSHING.MNT.FEND.CRGO. This part replaces 532404796. Price: $4.99 |
| 182 |
532406859 |
DASH.LOWER.COMMON.12V.ADAPTOR This part replaces 532194787. Price: $84.99 |
| 183 |
595305701 |
Screws This part replaces 874780520. Price: $3.99 |
| 184 |
532195780 |
SPACER.FENDER Price: $5.99 |
| 194 |
596135701 |
GSPW Nuts This part replaces 873900500. Price: $2.99 |
| 195 |
532404137 |
PLUG.HOLE.DASH.LOWER.12V.BLK Price: $4.99 |
| 196 |
532414579 |
CONSOLE.ASM.DECKLFT.BL/RBT.TLT This part replaces 532402843. Price: $22.99 |
| 197 |
532409167 |
ROD.PIVOT.HOOD This part replaces 532156524. Price: $9.99 |
| 202 |
532403048 |
VENT.SIDE.HOOD.HUSQ.RH.GREY Price: $7.99 |
| 203 |
532403076 |
VENT.SIDE.HOOD.HUSQ.LH.GRAY Price: $7.99 |
| 204 |
532416615 |
VENT.ASM.TORPHD.HUSQGT.LOGO.CL This part replaces 532198904. Price: $16.99 |
| 205 |
532401709 |
SKIRT.HOOD.SIDE.HUSQ.RH.GREY Price: $6.99 |
| 206 |
532401711 |
SKIRT.HOOD.SIDE.HUSQ.LH.GREY Price: $5.99 |
| 207 |
532197198 |
BEZEL.RH.TEX.GT.HUSQ Price: $19.99 |
| 208 |
532197199 |
BEZEL.LH.TEX.GT.HUSQ Price: $17.99 |
| 209 |
532199130 |
INSERT.HEX.GRILL.HUSQ.GREY Price: $4.99 |
| 210 |
532199131 |
INSERT.HEX.GRILL.HUSQ. Price: $2.99 |
| 211 |
532199132 |
INSERT.HEX.GRILL.HUSQ. Price: $2.99 |
| 212 |
532199133 |
INSERT.HEX.GRILL.HUSQ. Price: $2.99 |
| 214 |
532199145 |
CLIP.RETAINER.TINNER. Price: $2.99 |
| 219 |
593824001 |
STUD.W/"D"ANTI-ROTATION This part replaces 532195161. Price: $3.99 |
| 222 |
532137729 |
SCREW.1/4-20X5/8 Price: $3.99 |
| 229 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 230 |
532170165 |
SHOULDER BOLT 5/16-18TT Price: $3.99 |
| 234 |
532404742 |
BUMPER.HOOD.TEX.HUSQVARNA Price: $5.99 |
