| Ref | Part Number | Description |
|---|
| 2 |
48926 |
Hub, Tapered 1.125" bore This part replaces 46020. Price: Call Us |
| 3 |
04050-04 |
RETAINING RING, 1" EXT.-INVERTED Price: Call Us |
| 4 |
04050-07 |
RETAINING RING, 2-7/16 INT.-BASIC Price: Call Us |
| 5 |
48101-02 |
BEARING, CUTTER SPINDLE LOWER This part replaces 48101-01. Price: Call Us |
| 5A |
48101-02 |
BEARING, CUTTER SPINDLE LOWER Price: Call Us |
| 6 |
48926 |
Hub, Tapered 1.125" bore This part replaces 41001. Price: Call Us |
| 7 |
48114-02 |
GREASE FITTING, STR. 5/16 SERR. Price: Call Us |
| 8 |
43001-02 |
SPINDLE, CUTTER BLADE Price: Call Us |
| 9 |
04041-02 |
WASHER, 1-15/16 X 2-13/32 X 16 GA. Price: Call Us |
| 10 |
04063-08 |
KEY, 1/4 X 1/4 X 2 Price: Call Us |
| 11 |
43592 |
Spacer, Cutter Blade This part replaces 43038. Price: Call Us |
| 16 |
04040-10 |
FLAT WASHER, 5/8W Price: Call Us |
| 17 |
04001-41 |
HEX HEAD BOLT, 5/8-11 X 9-1/2 Price: Call Us |
| 18 |
46079 |
CASTER ASSY, COMP.(INCL. 19-28) Price: Call Us |
| 19 |
04066-01 |
QUICK PIN Price: Call Us |
| 20 |
43037-01 |
SPACER, CASTER YOKE, 1/2 LONG Price: Call Us |
| 21 |
48100-01 |
BRONZE BEARING Price: Call Us |
| 22 |
48114-04 |
GREASE FITTING, STR, 1/4-28 Price: Call Us |
| 23 |
46082 |
SUPPORT ASSY.(INC. 21-22) Price: Call Us |
| 24 |
45006 |
CASTER YOKE WLD. Price: Call Us |
| 25 |
43022 |
SLEEVE, CASTER WHEEL BEARING Price: Call Us |
| 26 |
04001-37 |
HEX HD. BOLT, 1/2-13 X 5-1/2 Price: Call Us |
| 28 |
48307 |
Wheel Assy., Caster This part replaces 48307-01. Price: Call Us |
| 29 |
481774 |
Tire Only, Caster Wheel This part replaces 48307-02. Price: Call Us |
| 29A |
481773 |
Inner Tube Only, Caster Wheel This part replaces 48006-03. Price: Call Us |
| 30 |
481772 |
Rim Pair, Caster Wheel This part replaces 48307-04. Price: Call Us |
| 31 |
481770 |
Retainer This part replaces 48006-07. Price: Call Us |
| 32 |
481769 |
Roller Bearing .625 x 3.25" This part replaces 48006-06. Price: Call Us |
| 33 |
48114-03 |
GREASE FITTING, 45' 1/4-28 Price: Call Us |
| 34 |
481768 |
Hub Assy. W/Bolts, Caster Wheel This part replaces 48006-05. Price: Call Us |
| 39 |
461292 |
Discharge Chute, Advantage This part replaces 45029. Price: Call Us |
| 44 |
04029-03 |
Knob This part replaces 04022-04. Price: Call Us |
| 45 |
43123 |
SPACER Price: Call Us |
| 46 |
42045 |
BELT COVER SKIRT Price: Call Us |
| 50 |
48141 |
Hub, Tapered 1.00" bore This part replaces 48127. Price: Call Us |
| 51 |
48141 |
TAPER HUB Price: Call Us |
| 58 |
48062 |
PULLEY IDLER Price: Call Us |
| 59 |
48102 |
BEARING Price: Call Us |
| 60 |
04050-06 |
RETAINING RING, 1-9/16 INT. BASIC Price: Call Us |
| 61 |
43045 |
SLEEVE, IDLER BEARING Price: Call Us |
| 62 |
43040 |
SPACER, IDLER BEARING Price: Call Us |
| 65 |
43105 |
SLEEVE, IDLER PULLEY Price: Call Us |
| 70 |
42536 |
IDLER PULLEY SUPPORT Price: Call Us |
| 71 |
48413 |
PULLEY, BELT GUIDE Price: Call Us |
| 73 |
42483 |
SPACER Price: Call Us |
| 76 |
46081 |
IDLER ARM ASSY.(INCL. 22 & 77) Price: Call Us |
| 77 |
48100-05 |
BRONZE BEARING Price: Call Us |
| 78 |
04050-02 |
RETAINING RING, 3/4 EXT.-"E" Price: Call Us |
| 79 |
43028 |
ROD, IDLER PULL, J Price: Call Us |
| 80 |
45037 |
IDLER PIVOT WLD. Price: Call Us |
| 82 |
46260 |
IDLER ARM ASSY.(INCL. 22 & 77) This part replaces 45213. Price: Call Us |
| 83 |
43054 |
SHOULDER BOLT Price: Call Us |
| 84 |
43041 |
SPACER, IDLER Price: Call Us |
| 85 |
04070-02 |
EYEBOLT, LH Price: Call Us |
| 86 |
04070-01 |
EYEBOLT, RH Price: Call Us |
| 87 |
43025 |
TURNBUCKLE Price: Call Us |
| 88 |
04022-02 |
WING NUT, 5/16-18 Price: Call Us |
| 89 |
43042 |
SLEEVE, CAM CLUTCH Price: Call Us |
| 90 |
04041-08 |
WASHER 3/4(49/64 X 1 1/4 X 16 GA.) Price: Call Us |
| 91 |
43043 |
SLEEVE, CLUTCH ROD Price: Call Us |
| 94 |
04062-01 |
HAIR PIN, LARGE Price: Call Us |
| 96 |
42057 |
CAM LINK Price: Call Us |
| 98 |
44017 |
ROD, BLADE ENGAGE(APPROX. 27" LONG) Price: Call Us |
