| Ref | Part Number | Description |
|---|
| 0010 |
1755412YP |
SPRING, Torsion, Deflector Price: $6.12 |
| 0020 |
1737228BZYP |
BLADE, Mower, 16.125 Long Price: $19.52 |
| 0030 |
1656916SM |
WASHER, SPRING 0.475I Price: $6.65 |
| 0040 |
1735686YP |
PULLEY, Split, 4.6 OD Price: $18.02 |
| 0050 |
1754868BMYP |
BRACKET, Deflector Hinge This part replaces 1754868AYP. Price: $18.75 |
| 0060 |
1737457YP |
SPACER, Pulley Price: $9.62 |
| 0090 |
704146 |
SCREW, HEX, 5/16-18X1 Price: $3.40 |
| 0095 |
1930600SM |
CAPSCREW, Hex Washer Head, Taptite, 5/16-18 x 1-1/2 Price: $4.49 |
| 0100 |
704028 |
PUSHNUT, CAP, 5/16 Price: $4.59 |
| 0110 |
1920676SM |
CAPSCREW, Hex Head, 7/16-14 X 1 Price: $4.70 |
| 0120 |
1759064YP |
ROD, Deflector Price: $7.47 |
| 0160 |
1921212SM |
CAPSCREW, Hex Head, 7/16-14 X 1 1/2 Price: $3.85 |
| 0200 |
1688017 |
KIT, Mower Deck, w/Decals, 46", Red Price: $918.69 |
| 0210 |
1759289YP |
COVER, Spindle, 46"/ 52" Mower, LH Price: $52.16 |
| 0215 |
84002339 |
BRACKET, Mounting, LH Price: $28.18 |
| 0230 |
1756247YP |
ADAPTER, Washout Port Price: $5.78 |
| 0240 |
1756246YP |
CONNECTOR, Washout Port Price: $14.39 |
| 0250 |
703228 |
SCREW, 5/16-18 X .75 This part replaces 1664847CAYP. Price: $3.94 |
| 0270 |
1759290YP |
COVER, Spindle, 46"/52" Mower, RH Price: $52.16 |
| 0275 |
84002347 |
BRACKET, Mounting, RH Price: $24.08 |
| 0320 |
1737279BMYP |
BAFFLE, Pinchoff Price: $16.09 |
| 0420 |
703447 |
BOLT, 5/16-18X.625 G5 Price: $3.72 |
| 0425 |
703297 |
RETAINER, GR5, 5/16 Price: $3.29 |
