| Ref | Part Number | Description |
|---|
| 1 |
7073100SM |
SPACER, Park Brake This part replaces 73100. Price: $8.09 |
| 2 |
83502 |
Governor Adjust Bolt - M5 Price: $283.70 |
| 3 |
83503 |
Metal Lock Nut - M5-0.8 Price: $255.45 |
| 4 |
92437 |
Blower Housing Assembly Price: Call Us |
| 5 |
81642 |
Recoil Assembly Price: Call Us |
| 6 |
81641 |
Recoil Cup Price: Call Us |
| 7 |
67890 |
Flywheel Hex Nut Price: Call Us |
| 8 |
67198N |
Bevel Washer Price: Call Us |
| 9 |
77147A |
Flywheel Assembly Price: Call Us |
| 10 |
84542 |
Ignition Coil Assembly Price: Call Us |
| 11 |
73104 |
Air Cleaner Cover Price: Call Us |
| 12 |
73108 |
Air Cleaner Base Price: Call Us |
| 13 |
73111GS |
ELEMENT,Air Cleaner This part replaces 73111. Price: $13.15 |
| 14 |
91204 |
Spit Back Plate Price: $172.45 |
| 15 |
92896GS |
DECAL, AIR BOX This part replaces 92896. Price: $21.10 |
| 16 |
90827 |
Air Box Bracket Price: Call Us |
| 17 |
690279 |
NUT This part replaces 90970. Price: $3.14 |
| 18 |
7091187SM |
NUT, Hex Nyloc, 10mm-1.50 This part replaces 91187. Price: $2.79 |
| 19 |
89228 |
Carburetor/manifold Gasket Price: Call Us |
| 20 |
78609 |
Air Cleaner Cover Bolt Price: Call Us |
| 21 |
7091028YP |
HHCS 7/16F X2-1/4 This part replaces 91028. Price: $3.19 |
| 22 |
81647 |
Carburetor Mounting Bolt Price: Call Us |
| 23 |
7072745YP |
BRKT ATTACHMENT This part replaces 72745. Price: $279.99 |
| 24 |
83504 |
Choke Knob Price: $272.19 |
| 25 |
73116A |
Blower Housing Backplate Price: Call Us |
| 26 |
7091039YP |
WLN, #10C This part replaces 91039. Price: $3.09 |
| 27 |
82774 |
Woodruff Key 4 x 19 Price: Call Us |
| 28 |
72735 |
Governor Control Rod Price: $181.78 |
| 29 |
72789 |
Governor Anti-lash Spring Price: Call Us |
| 30 |
78653GS |
SWITCH, Run - Stop This part replaces 78653. Price: $3.65 |
| 31 |
88434 |
Bottom Wrapper Price: Call Us |
| 32 |
88433 |
Top Wrapper Price: Call Us |
| 34 |
84007216 |
PLUG, SPARK This part replaces 72347. Price: $4.59 |
| 35 |
73101 |
Bracket, Governor Adjust with Idle Control Price: Call Us |
| 36 |
72734 |
Governor Lever Assembly Price: $154.48 |
| 37 |
86931 |
Oil Filter Adaptor Price: Call Us |
| 38 |
85272 |
Low Oil Indicator Lamp Price: Call Us |
| 39 |
77667 |
Low Oil Pressure Switch Price: Call Us |
| 40 |
40945GS |
SCREW This part replaces 40945. Price: $2.77 |
| 41 |
45756 |
Screw, M6-1.0 x 10mm Price: Call Us |
| 42 |
49813GS |
NUT, M6 This part replaces 49813. Price: $2.75 |
| 43 |
49821 |
M8-1.25 x 30mm Capscrew Price: Call Us |
| 44 |
59635 |
Plastite Screw - #8 x 3/8" Price: Call Us |
| 45 |
66476GS |
SCREW, M6-1 x 12 w/Lock Washer This part replaces 66476. Price: $2.94 |
| 46 |
67899 |
M6-1.0 x 8mm Capscrew Price: Call Us |
| 47 |
81646 |
Air Filter Pre-cleaner Price: Call Us |
| 48 |
81668 |
M6-1.0 x 10mm Capscrew Price: Call Us |
| 49 |
83512GS |
Screw, M8 1.25 x 15, Taptite This part replaces 83512. Price: $4.60 |
| 50 |
86999 |
Oil Filter Adaptor Gasket Price: Call Us |
| 51 |
7092079YP |
INSERT HX THRD 5/16 This part replaces 92079. Price: $3.99 |
| 52 |
5022097SM |
CAP This part replaces 22097. Price: $2.75 |
| 55 |
92981 |
Ignition Wire Assembly Price: Call Us |
| 57 |
49811GS |
WASHER This part replaces 49811. Price: Call Us |
| 58 |
93104 |
LOS Engine Decal Price: Call Us |
| 59 |
90782 |
Long Block with taper shaft Price: Call Us |
| 60 |
87221B |
LOS Module Price: Call Us |
| 61 |
7072709YP |
HANDLE UPPER This part replaces 72709. Price: $58.99 |
