| Ref | Part Number | Description |
|---|
| 1 |
36177 |
Cylinder (Incl. 2, 10, 12, 20 125) Price: Call Us |
| 2 |
27652 |
Pin-Dowel Price: Call Us |
| 6 |
36059 |
Breather Element Price: Call Us |
| 9 |
590568 |
Screw Price: Call Us |
| 10 |
36002 |
Breather Valve Body Price: Call Us |
| 11 |
36003A |
Check Valve Price: Call Us |
| 12 |
32447 |
Breather Tube Price: Call Us |
| 12C |
36005A |
Breather Cover Gasket Price: Call Us |
| 14 |
28277 |
Washer-Flat Price: Call Us |
| 15 |
36006 |
Governor Rod (Machined) Price: Call Us |
| 16 |
36008 |
Governor Level Price: Call Us |
| 17 |
31335 |
Clamp-Lever, Governor Price: Call Us |
| 18 |
651018 |
Screw (T-15, 8-32 x 19/64) Price: Call Us |
| 19 |
36103 |
Governor Spring Price: Call Us |
| 20 |
36010 |
Oil Seal Price: Call Us |
| 25 |
37300 |
Blower Housing Baffle (Incl.l95) Price: Call Us |
| 26 |
650802 |
Screw (1/2-20x5/8) Price: Call Us |
| 30 |
37321 |
Crankshaft Price: Call Us |
| 40 |
40004 |
DISCONTINUED Price: Call Us |
| 41 |
36070 |
Piston Pin Ass-y.(Std.)(Incl. 43) Price: Call Us |
| 41 |
36071 |
Piston Pin Ass-y.(.010 OS)(Incl.43) Price: Call Us |
| 42 |
40006 |
FITTING - TANK 3/4" Price: $66.59 |
| 42 |
40007 |
FITTING - TANK 1" Price: $60.39 |
| 43 |
20381 |
Ring-Retaining, Piston Pin Price: Call Us |
| 45 |
36023A |
Connecting Rod Ass-y. (Incl. 46) Price: Call Us |
| 46 |
32610A |
Bolt-Rod, Connecting Price: Call Us |
| 48 |
36030 |
Valve Lifter Price: Call Us |
| 50 |
36031A |
Camshaft (MCR) Price: Call Us |
| 52 |
29914 |
Oil Pump ASM Price: Call Us |
| 69 |
36032A |
Mounting Flange Gasket Price: Call Us |
| 70 |
37271 |
Mounting Flange (Incl. 72 thru 85) Price: Call Us |
| 72 |
36083 |
Plug-Oil Price: Call Us |
| 75 |
36010 |
Oil Seal Price: Call Us |
| 80 |
30574A |
Shaft-Governor Price: Call Us |
| 81 |
30590A |
Washer-Flat Price: Call Us |
| 82 |
30591 |
Gear Assy., Governor (Incl. No.132) Price: Call Us |
| 83 |
36057 |
Spool-Governor Price: Call Us |
| 85 |
36034 |
Idler Gear Price: Call Us |
| 86 |
650924 |
Screw, 1/4-20x1-9/16" Price: Call Us |
| 89 |
611154 |
Flywheel Key Price: Call Us |
| 90 |
611155 |
NEEDS DESCRIPTION Price: Call Us |
| 91 |
611156 |
NEEDS DESCRIPTION Price: Call Us |
| 92 |
650815 |
Washer-Belleville Price: Call Us |
| 93 |
650816 |
Nut-Flywheel Price: Call Us |
| 100 |
34443B |
Solid State Ignition (Incl. 101) Price: Call Us |
| 101 |
610118 |
Cover-Spark Plug Price: Call Us |
| 103 |
651007 |
Screw (T-15, 10-24 x 15/16) Price: Call Us |
| 110 |
36054 |
Tine Bolt Price: Call Us |
| 119 |
36061 |
Cylinder Head Gasket Price: Call Us |
| 120 |
36187 |
Cylinder Head Price: Call Us |
| 125 |
36471 |
Exhaust Valve (Std.)(Incl. 151) Price: Call Us |
| 125 |
36472 |
Valve-Exhaust (1/32 O S) Price: Call Us |
| 126 |
29314C |
Intake Valve (Std.)(Incl. 151) Price: Call Us |
| 126 |
29315C |
Valve, Intake (1/32" Oversize) (Incl. Ref. #86) Price: Call Us |
| 130 |
6021A |
Screw (5/16-18x1-1/2) Price: Call Us |
| 135 |
35395 |
Spark Plug-Resistor (R J19 L M) Price: Call Us |
| 150 |
31672 |
Spring-Valve Price: Call Us |
| 151 |
31673 |
Cap-Valve, Spring Price: Call Us |
| 151A |
40016A |
Seal-Valve, Intake Price: Call Us |
| 169 |
27234A |
Gasket-Cover, Valve Price: Call Us |
| 172 |
32755 |
Cover-Valve Price: Call Us |
| 174 |
30200 |
Screw (10-24 x 9/16) Price: Call Us |
| 177 |
650925A |
Carburetor Mounting Stud Price: Call Us |
| 184 |
36183 |
Carburetor To Intake Pipe Gasket Price: Call Us |
| 186 |
36009 |
Governor Link Price: Call Us |
| 187A |
37148 |
Air Baffle Price: Call Us |
| 190 |
36013 |
Brake Lever ASM Price: Call Us |
| 191A |
36012 |
Brake Control Lever Price: Call Us |
| 192 |
36016 |
Brake Control Lever Link Price: Call Us |
| 193 |
36015 |
Brake Spring Price: Call Us |
| 194 |
36014 |
Retaining Ring Price: Call Us |
| 195 |
610973 |
Terminal Price: Call Us |
| 198 |
36017 |
Brake Control Lever Spring Price: Call Us |
| 199 |
36018 |
Brake Lever Bushing Price: Call Us |
| 239 |
36048 |
Carburetor To Air Cleaner Gasket Price: Call Us |
| 240 |
36190 |
Air Cleaner Body Price: Call Us |
| 240A |
37195 |
Air Cleaner Body Extension Price: Call Us |
| 243B |
651041 |
Air Cleaner Stud Price: Call Us |
| 245 |
36046 |
Air Cleaner Filter Price: Call Us |
| 245A |
37144 |
Air Cleaner Filter Price: Call Us |
| 250 |
36191 |
Air Cleaner Cover Price: Call Us |
| 251 |
650928 |
Lock Nut, 1/4-20 Price: Call Us |
| 251A |
650933 |
Wing Nut, 1/4-20 Price: Call Us |
| 255 |
36193 |
Control Plate Price: Call Us |
| 256 |
650983 |
Screw, 8-32 x 21/64" Price: Call Us |
| 260 |
37194 |
Blower Housing Price: Call Us |
| 262 |
650737 |
Screw (1/4-20 x 1/2) Price: Call Us |
| 275 |
36107 |
Muffler Price: Call Us |
| 276 |
36043 |
Locking Plate Price: Call Us |
| 277 |
650927 |
Screw, 5/16-18 x 2-11/32" Price: Call Us |
| 279 |
650956 |
Screw, Torx T-25, 12-24 x 49/64" Price: Call Us |
| 285 |
34449A |
Starter Cup Price: Call Us |
| 287 |
650926 |
Screw (8-32 x 21/64) Price: Call Us |
| 290 |
34357 |
Fuel Line Price: Call Us |
| 292 |
26460 |
Clamp-Line, Fuel Price: Call Us |
| 300 |
36130 |
Fuel Tank (Incl. 301) Price: Call Us |
| 301 |
36246 |
Cap-Fuel Price: Call Us |
| 305 |
36063 |
Oil Fill Tube Price: Call Us |
| 307 |
35499 |
O-Ring Price: Call Us |
| 308 |
36040 |
Fill Tube Clip Price: Call Us |
| 310 |
36064 |
Dipstick Price: Call Us |
| 346A |
28763 |
Screw (10-32 x 35/64) Price: Call Us |
| 350 |
36045A |
Primer Price: Call Us |
| 370A |
36261 |
Decal-Lubrication Price: Call Us |
| 370C |
37199 |
Primer Decal Price: Call Us |
| 380 |
640020A |
Carburetor (Incl. 187B 239 of Engine Parts List) Price: Call Us |
| 390 |
590739 |
Rewind Starter ASM Price: Call Us |
| 400 |
36062D |
Gasket Set (Incl. Items Marked PK in Notes) 0 Incl. part #-s 27234A (1),28833 (1), 36005A (1), 36032A (1), 36061 (1), 37136 (1), 696088 (1) Price: Call Us |
| 416 |
36085 |
Spark Arrestor Kit (Incl. 417)(Optional) Price: Call Us |
| 417 |
650821 |
Screw (10-32 x 1/2) Price: Call Us |
