| Ref | Part Number | Description |
|---|
| 1 |
137-6105 |
SHORT REAR ROLLER ASM (2.5IN DIA)(22IN) This part replaces 114-5406. Price: $478.13 |
| 1 |
532136973 |
Wire Asm Inner W/plunger 17 32 (AYP part number) Price: $11.99 |
| 2 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 2 |
532140278 |
Shaft Asm Lift (AYP part number) Price: $34.17 |
| 3 |
119-0626 |
SHIM-ROLLER Price: $3.23 |
| 3 |
532138284 |
Pin Groove (AYP part number) Price: $3.99 |
| 4 |
812000002 |
E Ring #5133-62 (AYP part number) Price: $3.99 |
| 5 |
106-3924 |
BRACKET-ROLLER, REAR Price: $23.58 |
| 5 |
819211621 |
Washer PLTD 21/32 X 1 X 21 ga (AYP part number) Price: $3.99 |
| 6 |
3230-7 |
BOLT-CARR Price: $0.88 |
| 6 |
532120183 |
Bearing Nylon Blk 629 Id (AYP part number) Price: $2.99 |
| 7 |
114-5400 |
PLASTIC WIEHLE ROLLER ASM Price: $477.85 |
| 7 |
532109413 |
Grip Handle Bicycle Matte Blk (AYP part number) Price: $2.99 |
| 8 |
532125925 |
PLUNGER BUTTON KIT This part replaces 532124526. Price: $5.99 |
| 9 |
32128-20 |
NUT-HF Price: $0.99 |
| 10 |
322-16 |
SCREW-HH Price: $3.39 |
| 10 |
532122512 |
Spring Cprsn 3 750 Oiled Price: $4.99 |
| 11 |
3231-4 |
SCREW-CARR Price: $3.59 |
| 11 |
532145537 |
LIFT LINK LH This part replaces 532139865. Price: $14.99 |
| 12 |
140-5690 |
BRACKET-RM FRONT HOC This part replaces 125-2796. Price: $20.85 |
| 12 |
532145536 |
LIFT LINK RH This part replaces 532139866. Price: $7.99 |
| 13 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 13 |
532124670 |
Retainer Spring (AYP part number) Price: $5.99 |
| 14 |
48-9220 |
WASHER-PLAIN Price: $0.87 |
| 15 |
107-4026 |
SCREW-HH Price: $5.28 |
| 15 |
532127218 |
Link Front (AYP part number) Price: $9.99 |
| 16 |
873350800 |
Nut Jam Hex 1/2-13 Unc (AYP part number) Price: $1.99 |
| 16 |
94-6936 |
WASHER-HARDENED Price: $0.58 |
| 17 |
532175689 |
TRUNNION This part replaces 532130171. Price: $2.99 |
| 18 |
539101331 |
NUT 1/2-13 HEX NYLOC ZD This part replaces 873800800. Price: $1.99 |
| 19 |
532139868 |
Arm Suspension Rear (AYP part number) Price: $11.99 |
| 20 |
532003146 |
SPRING RETAINER This part replaces 532124660. Price: $1.99 |
| 21 |
819151216 |
Washer 15/32 x 3/4 x 16 Ga. (AYP part number) Price: Call Us |
| 22 |
812000037 |
Ring Klip #T534037 (AYP part number) Price: $3.99 |
| 23 |
532110807 |
Nut Special (AYP part number) Price: $3.99 |
| 24 |
819131016 |
Washer 13/32 x 5/8 x 16 Ga. (AYP part number) Price: $3.99 |
| 25 |
532002876 |
SPRING This part replaces 532124874. Price: $3.99 |
| 26 |
876020308 |
Pin cotter 3/32 x 1/2 (AYP part number) Price: $1.99 |
| 27 |
532126971 |
Rod adj Lifte zino 7.49 work lg. Price: $4.99 |
| 28 |
873220600 |
NUT.HEX.3/8-16UNC This part replaces 873350600. Price: $3.99 |
| 29 |
532138057 |
Knob info 3/8 - 16 Unc. Blk w/sym (AYP part number) Price: $5.99 |
| 30 |
532110810 |
Turnnion dp. stop dbl thds plt. Price: $14.99 |
| 31 |
532169865 |
BEARING.PIVOT.LIFT This part replaces 532140302. Price: $3.99 |
| 32 |
873540600 |
Nut Crownlock 3/8-24 (AYP part number) Price: $1.99 |
| 33 |
532140168 |
Bracket Stop inf. Hgt. (AYP part number) Price: $2.90 |
| 34 |
817490608 |
Screw thdrol 3/8 - 16 x 1/2 Ty. TT (AYP part number) Price: $3.99 |
| 35 |
532120529 |
Washer Nylon .44 x .75 x .032 (AYP part number) Price: $2.99 |
| 36 |
532123933 |
HEIGHT INDICATOR PNTR This part replaces 532138346. Price: $3.99 |
| 37 |
532123935 |
Plug Hole Blk 1.485/1.515 Dia. (AYP part number) Price: $3.99 |
| 38 |
539976934 |
HCS 5/16C X 3/4 This part replaces 817490512. Price: $1.99 |
| 40 |
819112410 |
Washer 11/32 x 1-1/2 x 10 Ga. (AYP part number) Price: $3.99 |
