| Ref | Part Number | Description |
|---|
| 1 |
703-1951 |
PEDESTAL Not Available Price: |
| 2 |
532149723 |
MUFFLER.TWIN.CYL.LOW.TONE Price: $39.99 |
| 2 |
712-3044 |
NUT, 1/4 WING Not Available Price: |
| 2 |
93-7977 |
SEAL Price: $74.14 |
| 3 |
736-0463 |
Washer, Flat, .251 X .62 X .052 Thk Price: $3.91 |
| 3 |
93-7978 |
ROD-PULL Price: $171.95 |
| 4 |
703-2153 |
PANEL, LH SIDE W/SLOTS Not Available Price: |
| 4 |
93-7983 |
PIN-CLEVIS Price: $3.19 |
| 5 |
703-2152 |
SIDE PANEL (RH) Not Available Price: |
| 5 |
93-7980 |
LINK Price: $13.85 |
| 6 |
759-3635 |
KIT-DECAL Not Available Price: |
| 6 |
93-7979 |
PIN-HITCH Price: $1.70 |
| 7 |
710-0376 |
Screw, 5/16-18 X 1 Znd Hex Hd Cap This part replaces 710-3002. Price: $3.66 |
| 7 |
93-7986 |
DISC-STATIONARY Price: $26.25 |
| 8 |
93-7981 |
DISC-ROTATING Price: $177.64 |
| 8 |
936-0119 |
Washer, Lock, 5/16 This part replaces 736-0119. Price: $4.29 |
| 9 |
532194319 |
KEEPER.BELT.ENGINE.3.25 (3 2) Price: $11.99 |
| 9 |
703-0008 |
GRILLE HOUSING RETAINER Not Available Price: |
| 9 |
93-7976 |
RING-RETAINING Price: $12.48 |
| 10 |
731-3099 |
GRILLE INSERT Not Available Price: |
| 10 |
93-7984 |
GASKET Price: $20.21 |
| 11 |
583389701 |
KIT.SVC.CLUTCH.ELE.180505 This part replaces 532180505. Price: $299.99 |
| 11 |
93-7982 |
ACTUATOR Price: $187.96 |
| 11 |
931-3102 |
GRILLE LENS This part replaces 731-3102. Price: $36.19 |
| 12 |
532194338 |
PULLEY.ASM.ENG.OGURA.3 Price: $54.99 |
| 12 |
93-7987 |
SPRING-EXTENSION Price: $9.47 |
| 13 |
703-1829-0499 |
HOOD HINGE ASSEMBLY (CUB BEIGE) Not Available This part replaces 703-1829. Price: |
| 14 |
710-3214 |
STUD-DOUBLE ENDED Not Available Price: |
| 15 |
532400021 |
TANK.FUEL.SIDE-FILL.3.NON-EPA Price: $99.99 |
| 15 |
912-0107 |
Hex L-Nut 1/4-20 Thd This part replaces 712-0107. Price: $4.06 |
| 16 |
703-1856 |
PLATE, HINGE Not Available Price: |
| 17 |
710-0748 |
SCREW #12-14 x .500 Not Available Price: |
| 18 |
584248701 |
CAP.ASSY.FUEL.3".N-EPA.BLK.428 This part replaces 532195951. Price: $14.99 |
| 18 |
931-3089B |
HOOD Not Available This part replaces 731-3089A. Price: |
| 19 |
979-3536 |
LABEL-CCC SCRIPT Not Available This part replaces 779-3536. Price: |
| 20 |
532175437 |
CONTROL.THROTTLE.BLACK This part replaces 532178385. Price: $24.99 |
| 20 |
710-3217 |
Screw, Truss Hd Mach, #8-32 X .38 Lg Price: $5.94 |
| 21 |
596321701 |
Screws This part replaces 532191611. Price: $2.99 |
| 21 |
732-3063A |
Clip, Hood Latch Price: Call Us |
| 22 |
532191596 |
CONTROL.CHOKE.ERGO.PUSH-IN.BLA Price: $32.99 |
| 22 |
736-0310 |
Washer, Flat, .16 X .38 X .045 Thk Price: $3.50 |
| 23 |
912-3072 |
HEX NUT KEPS #8-32 Not Available This part replaces 712-3072. Price: |
| 24 |
911-3296 |
LATCH PIN Not Available This part replaces 711-3296. Price: |
| 25 |
710-0286 |
Screw, Phillips Hd Truss Mach, 1/4-20 X .50 Lg Price: $3.86 |
| 26 |
736-0211 |
Washer, Flat, .285 X 1.25 X .060 Thk Price: $5.99 |
| 27 |
703-1955 |
BRACKET ASSY, LH PANEL MTG Not Available Price: |
| 28 |
587044864 |
HOSE 1/4" LOW PERMEATION FUEL This part replaces 532401135. Price: $17.99 |
| 28 |
703-2162-0499 |
PANEL SCREEN (RH) (CUB BEIGE) Not Available This part replaces 703-2162. Price: |
| 29 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 31 |
532145006 |
PUSH CLIP Price: $2.99 |
| 37 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 41 |
532126197 |
WASHER Price: $6.99 |
| 42 |
596238901 |
Washers This part replaces 810040700. Price: $2.99 |
| 45 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 62 |
531154901 |
SERVICE KIT HEAT SHIELD This part replaces 532146629. Price: $11.99 |
| 69 |
532165391 |
GASKET.MUFFLER Price: $9.99 |
| 70 |
581881101 |
EXHAUST.TUBE.LH.BS/TWIN This part replaces 532159955. Price: $27.99 |
| 71 |
581881001 |
EXHAUST.TUBE.RH.B&S.TWIN.INTEK This part replaces 532160589. Price: $22.99 |
| 79 |
596134202 |
Screws This part replaces 532183906. Price: $2.99 |
| 81 |
532148456 |
TUBE, DRAIN OIL ASM. Price: $5.99 |
| 82 |
532428287 |
VALUE.OIL.DRAIN This part replaces 532181654. Price: $14.99 |
| 83 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK Price: $4.99 |
| 84 |
817060620 |
SCREW.3/8-16 Price: $5.99 |
| 85 |
501606501 |
BOLT.HEX.7/16-20X4.GR5.1.5BLUE This part replaces 532173937. Price: $2.99 |
