| Ref | Part Number | Description |
|---|
| 1 |
596583101 |
Screws This part replaces 539990582. Price: $3.99 |
| 1 |
731-3100A |
VALVE HANDLE Not Available Price: |
| 1 |
95-7522 |
AXLE Price: $377.20 |
| 2 |
596433701 |
GSPW Washers This part replaces 539990517. Price: $2.99 |
| 2 |
910-0749 |
CHAIN ADJUSTMENT BOLT Not Available This part replaces 710-0749. Price: |
| 2 |
99-7564 |
SEAL-OIL Price: $25.36 |
| 3 |
539103257 |
IDLER PULLEY Price: $49.99 |
| 3 |
712-0998 |
Nut, Hex Center Lock, #10-24 Not Available Price: |
| 3 |
95-7544 |
CLIP Price: $4.04 |
| 4 |
539103230 |
IDLER ARM Price: $159.99 |
| 4 |
913-3000 |
CHAIN LINK Not Available This part replaces 713-3000. Price: |
| 4 |
95-7523 |
SPACER Price: $26.89 |
| 5 |
539103427 |
PIVOT BUSHING Price: $7.99 |
| 5 |
99-7555 |
SHIM 0.3 Price: $3.29 |
| 5 |
99-7556 |
SHIM 0.2 Price: $3.29 |
| 5 |
99-7557 |
SHIM 0.5 Price: $3.37 |
| 6 |
596437501 |
Washers This part replaces 539102243. Price: $8.99 |
| 6 |
936-0329 |
L-Wash. 1/4" I.D. This part replaces 736-0329. Price: $3.90 |
| 6 |
95-7524 |
GEAR-BEVEL, 29 TOOTH Price: $222.95 |
| 7 |
539103433 |
HCS 1/2C X 3 1/4 Price: $5.99 |
| 7 |
710-3218 |
Screw, Socket Hd Cap, 1/4-20 X .62 Lg GR8 Price: $3.86 |
| 7 |
99-7534 |
BEARING-BALL Price: $65.44 |
| 8 |
596899901 |
GSPW Zerks This part replaces 539976998. Price: $2.99 |
| 8 |
921-3021 |
O-RING .301 IDX.070 This part replaces 721-3021. Price: $3.39 |
| 8 |
95-7521 |
COVER-AXLE Price: $107.87 |
| 9 |
106-1071 |
O-RING This part replaces 99-7538. Price: $18.43 |
| 9 |
596135601 |
GSPW NUTS This part replaces 539101331. Price: $3.99 |
| 9 |
903-1803 |
VALVE DOUBLE CLAMP Not Available This part replaces 703-1803. Price: |
| 10 |
539104605 |
BELTSHIELD Price: $27.01 |
| 10 |
727-3046 |
CYLINDER HOSE Not Available Price: |
| 10 |
93-7775 |
BEARING-BALL This part replaces 99-7561. Price: $127.75 |
| 11 |
539102892 |
DECAL, NO STEP Price: $0.64 |
| 11 |
727-3045 |
CYLINDER HOSE Not Available Price: |
| 11 |
99-7539 |
CLIP Price: $11.07 |
| 12 |
104-2374 |
BOLT This part replaces 99-7596. Price: $6.33 |
| 12 |
539990839 |
NUT 7/16C CENTERLOCK Price: $2.99 |
| 12 |
710-0751 |
SCREW 1/4-20 x .620 GR5 Price: $3.63 |
| 13 |
596577901 |
Nuts This part replaces 539102582. Price: $2.99 |
| 13 |
736-0270 |
SPRING WASHER BELL Price: $3.63 |
| 14 |
594944601 |
Bolts This part replaces 539101175. Price: $2.99 |
| 14 |
710-0641 |
Screw, Hex Cap, 1/4-20 X 2.25 Lg Price: $3.66 |
| 15 |
594722002 |
LIFT This part replaces 539102641. Price: $4.99 |
| 15 |
703-1801 |
VALVE MOUNTING BRACKET Not Available Price: |
| 16 |
539103256 |
SPRING Price: $9.99 |
| 16 |
712-3006 |
HEX NUT Price: $4.05 |
| 17 |
539103295 |
IDLER BUSHING Price: $12.99 |
| 18 |
539103258 |
IDLER PULLEY (TALL) Price: $44.99 |
| 19 |
596434201 |
Bolts This part replaces 539990637. Price: $3.99 |
| 19 |
721-3002 |
O-RING-1/4 Not Available Price: |
| 20 |
539100141 |
HCS 7/16F X 1 1/2 Price: $7.99 |
| 21 |
596238901 |
Washers This part replaces 539990247. Price: $2.99 |
| 22 |
596770301 |
Washers This part replaces 539106504. Price: $4.99 |
| 23 |
539101995 |
KEY 1/4 SQ X 1 1/8 Price: $2.99 |
| 24 |
539103283 |
PULLEY Price: $59.99 |
| 25 |
539102675 |
MACHINERY BUSHING 10 GA. Price: $8.99 |
| 26 |
539102244 |
BUSHING.MACHINE.18.GAUGE Price: $4.99 |
| 27 |
539115279 |
BEARING-ECC LOCK W/COLLAR This part replaces 539102677. Price: $30.99 |
| 28 |
539102673 |
HOUSING Price: $229.99 |
| 29 |
539102676 |
SPACER Price: $8.99 |
| 30 |
539103290 |
SPINDLE SHAFT Price: $64.99 |
| 31 |
539100340 |
BLADE OEM 16 1/4" Price: $22.99 |
| 32 |
539990333 |
LOCKWASHER 5/8 Price: $2.99 |
| 33 |
539103299 |
HCS 5/8F X 1 1/4 Price: $5.99 |
| 34 |
596580801 |
Bolts This part replaces 539990209. Price: $2.99 |
| 35 |
596580701 |
Nuts This part replaces 539990184. Price: $2.99 |
| 36 |
539104546 |
DEFLECTOR CHUTE Price: $139.99 |
| 37 |
539104197 |
STRUT MOUNT WELDMENT Price: $51.99 |
| 38 |
539104199 |
HCS 5/8C X 2 GR.5 Price: $2.99 |
| 39 |
539102698 |
BUSHING Price: $29.99 |
| 40 |
539102643 |
ANTI-SCALP ROLLER Price: $8.99 |
| 41 |
539102754 |
HCS 3/8C X 3 1/2 Price: $3.99 |
| 42 |
539105779 |
DECK W/DECALS 48" This part replaces 539104610. Price: $2,799.99 |
| 45 |
539108350 |
STRUT, RIGHT This part replaces 539104609. Price: $549.99 |
| 47 |
539913010 |
DECAL, CPSC Price: $3.99 |
| 48 |
539100344 |
DECAL, DANGER Price: $2.42 |
| 51 |
595316401 |
Washers This part replaces 539990550. Price: $2.99 |
| 52 |
539102619 |
PIVOT PIN Price: $32.99 |
| 53 |
596030501 |
SCREW HEXAGON HEAD SCREW 5/16- This part replaces 539976934. Price: $3.99 |
| 55 |
595305901 |
Nuts This part replaces 539990546. Price: $2.99 |
| 56 |
539105444 |
CENTER BAFFLE 48" Price: $59.99 |
| 57 |
539105448 |
MAIN BAFFLE - 48" DECK BLK Price: $299.99 |
| 58 |
596039401 |
BOLT ROUND HEAD SQUARE NECK BO This part replaces 539990799. Price: $2.99 |
