| Ref | Part Number | Description |
|---|
| 1 |
32120-8 |
RING-SNAP Price: $1.76 |
| 2 |
72-3750 |
BEARING-ROLLER Price: $180.02 |
| 3 |
323-56 |
SCREW-HH Price: $2.18 |
| 4 |
67-9080 |
HOUSING-MOTOR Price: $1,756.34 |
| 5 |
48-1800 |
CYLINDER BLOCK KIT Price: $1,923.22 |
| 6 |
25-2650 |
PLUG-VALVE, CHECK Price: $89.01 |
| 7 |
237-86 |
O-RING Price: $5.47 |
| 8 |
25-2640 |
SPRING-VALVE Price: $4.22 |
| 9 |
25-2490 |
BALL Price: $14.47 |
| 10 |
67-9100 |
GASKET Price: $15.83 |
| 11 |
99-5689 |
CHECK VALVE KIT This part replaces 25-3180. Price: $83.29 |
| 12 |
285-17 |
PLUG-PIPE Price: $2.59 |
| 13 |
237-22 |
O-RING Price: $2.43 |
| 14 |
25-2630 |
RING-BACK UP Price: $3.55 |
| 15 |
88-8220 |
VALVE-BY PASS Price: $189.03 |
| 16 |
25-2610 |
SPRING-VALVE Price: $29.42 |
| 17 |
25-2410 |
VALVE ASM Price: $514.54 |
| 18 |
76-1900 |
O-RING Price: $3.64 |
| 19 |
353-550 |
PLUG-HYD, HH Price: $10.71 |
| 20 |
119-2895 |
SPLINED SHAFT KIT This part replaces 67-8020. Price: $1,116.09 |
| 21 |
3257-32 |
KEY-WOODRUFF Price: $2.52 |
| 22 |
117-2700 |
HOUSING KIT This part replaces 54-7890. Price: $2,321.28 |
| 23 |
252-82 |
BEARING-NEEDLE Price: $51.31 |
| 24 |
25-3210 |
SEAL-LIP Price: $23.14 |
| 25 |
25-2510 |
WASHER-FLAT Price: $2.41 |
| 26 |
25-2580 |
SHAFT-TRUNNION Price: $215.33 |
| 27 |
32151-46 |
RING-RETAINING Price: $8.38 |
| 28 |
25-2460 |
PLUG-HH Price: $37.38 |
| 29 |
25-2470 |
PACK-SHIM Price: $47.36 |
| 30 |
25-2570 |
SPRING-VALVE Price: $12.67 |
| 31 |
83-7260 |
CONE-RELIEF, CHARGE Price: $50.57 |
| 32 |
353-551 |
PLUG-HH Price: $18.48 |
| 33 |
237-80 |
O-RING Price: $6.10 |
| 34 |
25-2550 |
DISCONTINUED-SEE PB#945 Price: Call Us |
| 35 |
67-8050 |
BEARING-NEEDLE Price: $54.10 |
| 36 |
93-4133 |
SEAL-LIP Price: $37.43 |
| 37 |
322-4 |
SCREW-HH Price: $0.35 |
| 38 |
25-2680 |
GEROTOR ASM Price: $651.02 |
| 39 |
25-2530 |
PIN-STRAIGHT, HEADLESS Price: $21.24 |
| 40 |
25-3190 |
DISCONTINUED-SEE PB#945 Price: Call Us |
| 41 |
237-95 |
O-RING Price: $11.97 |
| 42 |
67-9090 |
PLUG Price: $41.68 |
| 43 |
25-2500 |
SHAFT-TRUNNION Price: $191.66 |
| 44 |
25-2480 |
SPRING-VALVE Price: $4.93 |
| 45 |
32120-15 |
RING-SNAP, EXT Price: $1.20 |
| 46 |
251-8 |
BEARING-BALL Price: $30.06 |
| 47 |
32151-75 |
RING-RETAINING This part replaces 32120-11. Price: $2.51 |
| 48 |
25-2450 |
PLATE-SWASH, VARIABLE Price: $896.81 |
| 49 |
32121-91 |
PIN-SPRING Price: $0.81 |
| 50 |
25-2380 |
PLATE-THRUST Price: $32.89 |
| 51 |
25-2440 |
PLATE-VALVE, PUMP Price: $491.90 |
| 52 |
25-2430 |
PIN-DOWEL Price: $0.95 |
| 53 |
110-6341 |
BEARING-ROLLER This part replaces 46-8400. Price: $41.33 |
| 54 |
93-4132 |
O-RING Price: $6.84 |
| 55 |
92-8918 |
SECTION-CENTER Price: $1,338.76 |
| 57 |
25-2390 |
PLATE-VALVE, MOTOR Price: $832.97 |
| 58 |
46-8410 |
SHAFT-MOTOR Price: $968.23 |
| 59 |
25-2400 |
GASKET Price: $19.26 |
| 60 |
93-0312 |
WASHER-HARDENED Price: $0.78 |
| 61 |
75-0170 |
PLUG-THREAD, STRAIGHT This part replaces 92-8776. Price: $18.20 |
| 502199203 |
502199203 |
THROTTLE TRIGGER Price: $6.99 |
| 502199301 |
503794101 |
SPRING This part replaces 502199301. Price: $3.99 |
| 502199403 |
502199403 |
THROTTLE LOCKOUT Price: $2.99 |
| 502208502 |
502208507 |
HANDLE This part replaces 502208502. Price: $19.99 |
| 502208602 |
502208602 |
THROTTLE HOUSING-RH Price: $6.99 |
| 502209602 |
502209602 |
THROTTLE LOCK Price: $2.99 |
| 502209701 |
530403152 |
THROTTLE SPRING This part replaces 502209701. Price: $2.99 |
| 503210719 |
503210719 |
SCREW Price: $1.99 |
| 503210738 |
503210738 |
SCREW Price: $2.99 |
| 503718201 |
503718201 |
START/STOP SWITCH Price: $11.99 |
| 503736303 |
596296801 |
HUS STANDARD HARNESS This part replaces 503736303. Price: $29.99 |
| 530001642 |
530001642 |
LOCKWASHER Price: $2.99 |
| 530001711 |
530001711 |
SCREW-1/4-20X1 HEX SOC Price: $1.99 |
| 530012207 |
530012207 |
Handlebar Clamp Price: $8.48 |
| 530014210 |
530014210 |
SHIELD Price: $25.99 |
| 530015197 |
530015197 |
NUT Price: $3.99 |
| 530015328 |
530015328 |
LOCKWASHER-LOCATOR-TYPE 2 Price: $2.99 |
| 530015492 |
530016240 |
WASHER BELLVILLE This part replaces 530015492. Price: $3.99 |
| 530015791 |
530015940 |
SCREW This part replaces 530015791. Price: $2.99 |
| 530015792 |
530015792 |
WASHER-FLAT. Price: $4.99 |
| 530015793 |
530015793 |
NUT-FLANGE (LH) Price: $4.99 |
| 530027615 |
530027615 |
PLATE-SHIELD RETENTION Price: $6.99 |
| 530037179 |
530037179 |
DECAL Price: $1.14 |
| 530038694 |
530038694 |
GRIP - DRIVE SHAFT Price: $6.99 |
| 530047139 |
530047139 |
Handlebar Price: $33.13 |
| 530069252 |
530069347 |
HANDLE KIT This part replaces 530069252. Price: $4.99 |
| 530094566 |
530094566 |
SHAFT-FLEX (57"). Price: $84.99 |
| 530094568 |
530071781 |
GEAR BOX REPLACEMENT KIT This part replaces 530094568. Price: $69.99 |
| 530094572 |
530094572 |
BRACKET-HANDLEBAR Price: $2.99 |
| 530094612 |
530094612 |
SCREW-10-24 X 7/16 (HEX Price: $0.99 |
| 530094616 |
530094616 |
Screw Price: $2.35 |
| 530094686 |
530094686 |
ASSY-CLAMP HARNESS Price: $5.99 |
| 530095165 |
530071284 |
DRIVE SHAFT TUBE This part replaces 530095165. Price: $49.99 |
