| Ref | Part Number | Description |
|---|
| 1 |
04001-109 |
Bolt, Hex Head, 1/4-20 x 1-3/8" Price: Call Us |
| 2 |
481434 |
Pulley, 5.55 OD Price: Call Us |
| 3 |
481497 |
Belt, Main Drive Price: Call Us |
| 4 |
48926 |
Hub, Tapered Price: Call Us |
| 5 |
04063-06 |
Key, 1/4 x 1/4 x 1-1/2" Price: Call Us |
| 6 |
04001-62 |
Bolt, Hex Head, 3/8-16 x 3-1/4" Price: Call Us |
| 7 |
04040-07 |
Flatwasher, 1/2 (.531 x .062 x 095) Price: Call Us |
| 8 |
04001-90 |
Bolt, Hex Head, 1/2-13 x 3-1/4" Price: Call Us |
| 9 |
48062 |
Pulley, Idler - 5.75 Dia Price: Call Us |
| 10 |
43391 |
Spacer Price: Call Us |
| 11 |
04050-02 |
Retaining Ring, .75 "E" Price: Call Us |
| 12 |
04041-08 |
Flatwasher, 3/8 (7.66 x 1.25 x .06) Price: Call Us |
| 13 |
04041-08S |
Flatwasher, 3/8 (7.66 x 1.25 x .035) Price: Call Us |
| 14 |
48100-05 |
Bushing, Oilite, .753 ID Price: Call Us |
| 15 |
46081 |
Arm, Idler Price: Call Us |
| 16 |
43277 |
Spacer, J-Pull Rod Price: Call Us |
| 17 |
04001-22 |
Bolt, Hex Head, 3/8-16 x 2-3/4" Price: Call Us |
| 18 |
44114 |
Rod, J-Pull Price: Call Us |
| 19 |
04030-04 |
Lockwasher, 3/8” Spring, Kawasaki FX / FT & FT-EFI / B&S 32BV Price: Call Us |
| 20 |
04004-31 |
Stud, 3/8-16 x 4.00" Price: Call Us |
| 21 |
04021-09 |
Hex Locknut, Elastic Stop, 3/8-16 Price: Call Us |
| 22 |
04021-07 |
Hex Locknut, Elastic Stop, 1/2-13 Price: Call Us |
| 23 |
45741 |
Pivot, Engine Idler Price: Call Us |
| 24 |
48114-04 |
Grease Fitting Price: Call Us |
| 25 |
04019-04 |
Serr. Fl. Hex Nut, 3/8-16 Price: Call Us |
| 26 |
483211 |
Idler Pulley, Wheel Drive This part replaces 48198. Price: Call Us |
| 27 |
48141 |
Hub, Tapered, 1.00 Bore Price: Call Us |
| 28 |
04063-01 |
Key, 1/4 x 1/4 x 1-1/4" Price: Call Us |
| 29 |
481227 |
Gearbox, T-Drive Price: Call Us |
| 30 |
481229 |
Pulley, 4.25 OD Double Groove Price: Call Us |
| 31 |
44075 |
Rod, J-Pull Price: Call Us |
| 32 |
43077 |
Spacer, J-Pull Price: Call Us |
| 33 |
483208 |
Pulley, Idler 3" Dia. - 52" This part replaces 481048. Price: Call Us |
| 34 |
04041-12 |
Flatwasher, 3/8 (.375 x 1.50 x .06) Price: Call Us |
| 35 |
04003-21 |
Carriage Bolt, 3/8-16 x 2-1/2" Price: Call Us |
| 36 |
481499 |
Belt, R.H. Transmission Drive Price: Call Us |
| 37 |
481498 |
Belt, L.H. Transmission Drive Price: Call Us |
| 38 |
48791 |
Hub, Tapered, 15 mm Price: Call Us |
| 39 |
04001-12 |
Bolt, Hex Head, 5/16-18 x 1-3/4" Price: Call Us |
| 40 |
04001-53 |
Bolt, Hex Head, 5/16-18 x 2-1/2" Price: Call Us |
| 41 |
04030-03 |
Lockwasher, 5/16" Price: Call Us |
| 42 |
04017-04 |
Serr. Fl. Hex Head CPSCR, 1/4-20 x 1/2" Price: Call Us |
| 43 |
481225 |
Pump, L.H. Price: Call Us |
| 44 |
481223 |
Axle, L.H. Price: Call Us |
| 45 |
04001-132 |
Bolt, Hex Head, 3/8-24 x 4.0 GR 8 Price: Call Us |
| 46A |
481503 |
Drive Wheel Assembly This part replaces 48827. Price: Call Us |
| 46B |
481619 |
Tire Only This part replaces 48827-02. Price: Call Us |
| 46C |
481725 |
RIM WELDMENT This part replaces 48321-04. Price: Call Us |
| 47 |
04028-01 |
Nut, Wheel Price: Call Us |
| 48 |
421209 |
Back-up Washer, Fan Price: Call Us |
| 49 |
04001-126 |
Bolt, Hex Head, 5/16-18 x 5-1/2" Price: Call Us |
| 50 |
481231 |
Pulley, 4.25 OD Price: Call Us |
| 51 |
482133 |
Fan, Cooling This part replaces 48789. Price: Call Us |
| 52 |
04001-96 |
Bolt, Hex Head, 5/16-18 x 4-1/2" Price: Call Us |
| 53 |
04040-04 |
Flatwasher, 5/16 (.344 x .688 x .065) Price: Call Us |
| 54 |
04063-14 |
Key, 5 mm x 5 mm x 25 mm Price: Call Us |
| 55 |
481226 |
Pump, R.H. Price: Call Us |
| 56 |
481224 |
Axle, R.H. Price: Call Us |
| 57 |
04020-03 |
Hex Nut, 5/16-18 Price: Call Us |
| 58 |
43063 |
Spacer Price: Call Us |
| 59 |
04001-94 |
Bolt, Hex Head, 5/16-18 x 7-1/2" Price: Call Us |
| 60 |
04001-32 |
Bolt, Hex Head 3/8-16 x 1-1/4", Kawasaki FX / FT & FT-EFI Price: Call Us |
| 61 |
481232 |
Fan, Cooling RH Price: Call Us |
| 62 |
04043-02 |
Flatwasher, 5/16 USS GR 8 Price: Call Us |
| 63 |
421863 |
Washer, Heat Deflector Price: Call Us |
| 64 |
04015-14 |
Socket Head Capscrew, 1/4-20 x 1-3/8" Price: Call Us |
| 65 |
04030-09 |
Lockwasher, 3/8 Spring, Hardened Price: Call Us |
| 66 |
04021-18 |
Lock Nut 3/8-24 Elastic Stop GR 8 Price: Call Us |
| 67 |
48102 |
Bearing Idler Pulley Price: Call Us |
| 69 |
43045 |
Sleeve, Idler Pulley Price: Call Us |
| 70 |
04041-07 |
Flatwasher, 3/8 (.391 x .938 x .105) Price: Call Us |
| 71 |
48030-13 |
Clamp, .75 ID Price: Call Us |
