| Ref | Part Number | Description |
|---|
| 1 |
3231-10 |
SCREW-CARR Price: $1.22 |
| 1 |
532423469 |
WHEEL STEERING Price: $32.99 |
| 2 |
32151-72 |
RING-RETAINING Price: $1.59 |
| 2 |
532413591 |
AXLE.SVC.ASM CAST IRON.TEX This part replaces 532195968. Price: $119.99 |
| 3 |
63-8410 |
WASHER Price: $1.76 |
| 4 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 4 |
596873601 |
SPINDLE.WELDED.LH.15"TEX.X431 This part replaces 532403087. Price: $14.99 |
| 5 |
130-6043 |
DECAL-SERVICE Price: $37.66 |
| 5 |
538691201 |
SPINDLE.WLDMT.RH.15INTIRE.X431 This part replaces 532403088. Price: $19.99 |
| 6 |
120-4195 |
TANK-FUEL Price: $630.36 |
| 6 |
532006266 |
WASHER THRUST This part replaces 532124931. Price: $4.99 |
| 7 |
2412-98 |
CLAMP-HOSE Price: $1.39 |
| 7 |
532121748 |
WASHER Price: $3.99 |
| 8 |
104-5228 |
FITTING-ELBOW, 90 DEG Price: $17.50 |
| 8 |
812000029 |
RING CLIP Price: $3.99 |
| 9 |
120-8908 |
PIPE-STAND Price: $26.42 |
| 9 |
532121232 |
CAP.SPINDLE.BLACK Price: $3.99 |
| 10 |
46-6560 |
BUSHING Price: $2.94 |
| 11 |
92-2379 |
CLAMP-HOSE Price: $0.34 |
| 12 |
3253-15 |
WASHER-LOCK Price: $1.49 |
| 13 |
32122-24 |
SCREW-PTH Price: $0.27 |
| 13 |
532121749 |
WASHER Price: $2.99 |
| 14 |
121-1688 |
GAUGE-FUEL Price: $197.80 |
| 14 |
596238701 |
Washers This part replaces 810040600. Price: $3.99 |
| 15 |
121-1707 |
GASKET-FUEL, VITON Price: $22.66 |
| 15 |
873540600 |
NUT CROWNLOCK 3/8-24 Price: $3.99 |
| 16 |
119-8266 |
CAP-FUEL (BIODIESEL) Price: $57.02 |
| 16 |
587738904 |
KIT.SRVC.STEERINGSHAFT.2HISHFT This part replaces 532408219. Price: $34.99 |
| 17 |
121-1514-03 |
BRACKET-LATCH, RH Price: $31.14 |
| 18 |
120-4190-0P |
TANK SUPPORT ASM [PRIMED] This part replaces 120-4190-03. Price: $263.49 |
| 19 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 19 |
531169101 |
SERVICE KIT PLATE PLATE.STEER. This part replaces 532194729. Price: $19.99 |
| 20 |
120-4193-0P |
BRACKET-FUEL TANK This part replaces 120-4193-03. Price: $16.84 |
| 21 |
3230-1 |
BOLT-CARR Price: $1.49 |
| 21 |
587738905 |
KIT.SRVC.STEERINGSHAFT.ADAPTER This part replaces 532186737. Price: $7.99 |
| 22 |
3256-3 |
WASHER-FLAT Price: $0.49 |
| 22 |
587738901 |
KIT.SRVC.STEERINGSHAFT.LWRBSHG This part replaces 532420537. Price: $14.99 |
| 23 |
103-4080 |
LATCH-RUBBER Price: $29.99 |
| 24 |
99-5414 |
STRAP-CLEANER, AIR Price: $48.46 |
| 25 |
104-3563 |
INDICATOR Price: $58.60 |
| 26 |
532439743 |
INSERT.CAP.WHL.STRG.HUSQ.PREM This part replaces 532415987. Price: $8.99 |
| 26 |
99-5410 |
AIR CLEANER ASM Price: $381.32 |
| 27 |
322-6 |
SCREW-HH Price: $0.45 |
| 28 |
32144-1 |
SCREW-TAPTITE Price: $3.19 |
| 28 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 29 |
121-1513-03 |
BRACKET-LATCH, LH Price: $31.14 |
| 35 |
532194732 |
GEAR.SECTOR.PLATE.DDL. Price: $27.99 |
| 45 |
819183812 |
WASHER 9/16"ID, 2 3/8"OD Price: $7.99 |
| 51 |
873940800 |
NUT.HEX.1/2-20 Price: $3.99 |
| 53 |
532188967 |
WASHER.HARDENED Price: $3.99 |
| 57 |
532407465 |
BRACKET.UPSTOP.TEX Price: $5.99 |
| 59 |
532194748 |
WASHER.THURST.SECTOR.S Price: $4.99 |
| 60 |
583612801 |
NUT.FLANGE.LOCK.5/8-11 This part replaces 873971000. Price: $3.99 |
| 61 |
597047802 |
Links This part replaces 532194740. Price: $11.99 |
| 62 |
597047902 |
Links This part replaces 532194741. Price: $11.99 |
| 63 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 64 |
532199849 |
RETAINER.CLIP.SPRING.S Price: $4.99 |
| 66 |
871020748 |
BOLT HEX FGHD 7/16-14 X 3 SERR Price: $4.99 |
| 67 |
529496302 |
BUSHING, AXLE This part replaces 532194737. Price: $2.99 |
| 68 |
873900700 |
NUT.LOCK.FLANGE.7/16 Price: $3.99 |
| 69 |
532199162 |
WASHER.1.5X.505X.118 Price: $4.99 |
| 70 |
585338802 |
BRACKET FRONT DECK SUSPENSION This part replaces 532196197. Price: $14.99 |
