| Ref | Part Number | Description |
|---|
| 1 |
322-2 |
SCREW-HH Price: $0.69 |
| 1 |
KB-12691-44010 |
CARBURETOR-ASSEMBLY Not Available Price: |
| 2 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 2 |
KB-12035-46110 |
CARBURETOR GASKET Not Available This part replaces KB-13961-46110. Price: |
| 3 |
2412-133 |
CLAMP-R Price: $3.19 |
| 3 |
KB-12596-46150 |
FLANGE-CAR Not Available Price: |
| 4 |
74-0720 |
TUBE-MANUAL Price: $22.99 |
| 4 |
KB-02114-50080 |
NUT Not Available Price: |
| 5 |
KB-04512-70080 |
WASHER Not Available This part replaces KB-04512-50080. Price: |
| 6 |
KB-12581-11610 |
FLANGE-AIR Not Available Price: |
| 7 |
51-0790 |
ADJUSTER-SEAT, LH Price: $127.92 |
| 7 |
KB-12035-11510 |
AIR CLEANER GASKET Not Available This part replaces KB-13961-11510. Price: |
| 8 |
83-1270 |
SEAT SUPPORT ASM Price: $350.78 |
| 8 |
KB-01513-50885 |
STUD Not Available Price: |
| 9 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 9 |
KB-12581-36550 |
CAP Not Available Price: |
| 10 |
3272-11 |
PIN-COTTER Price: $0.99 |
| 10 |
KB-15852-52850 |
COVER Not Available Price: |
| 11 |
68-5100 |
ROD-SEAT, PROP Price: $32.13 |
| 11 |
KB-15841-52140 |
GASKET-F/P Not Available Price: |
| 12 |
3296-16 |
NUT-LOCK, NI Price: $1.39 |
| 12 |
KB-01023-50616 |
BOLT W/WASHER Not Available Price: |
| 13 |
68-5310 |
CLIP-ROD, PROP Price: $6.35 |
| 13 |
KB-12581-43012 |
FUEL FILTER Not Available This part replaces KB-12691-43010. Price: |
| 14 |
321-3 |
SCREW-HH Price: $0.28 |
| 14 |
KB-EG601-52034 |
FUEL PUMP Not Available This part replaces KB-12691-52030. Price: |
| 15 |
32121-45 |
PIN-SPRING Price: $0.27 |
| 15 |
726-0205 |
Clamp, Hose Price: $3.71 |
| 16 |
3284-3 |
PIN-GROOVED Price: $2.24 |
| 17 |
51-0350 |
PIN-SPRING, SEAT Price: $11.90 |
| 18 |
3-6685 |
SPRING Price: $10.99 |
| 19 |
43-9071 |
LIMIT SWITCH ASM Price: $182.60 |
| 20 |
218-461 |
NUT-HH Price: $2.50 |
| 21 |
49-5880 |
SHAFT-SUPPORT, SEAT Price: $17.88 |
| 22 |
83-1840-01 |
COVER-VALVE, RH Price: $27.61 |
| 23 |
3274-12 |
SCREW-HSH Price: $0.81 |
| 24 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 25 |
51-0780 |
SLIDER-SEAT Price: $116.02 |
| 26 |
104-4620 |
SEAT This part replaces 100-3187. Price: $273.15 |
| 27 |
93-6686 |
DECAL-OIL, HYD This part replaces 93-8067. Price: $7.01 |
| 28 |
83-2490 |
DECAL-JAPANESE Price: $14.18 |
| 28 |
84-9240 |
DECAL-SPANISH Price: $10.42 |
| 28 |
84-9250 |
DECAL-FRENCH Price: $10.42 |
| 28 |
84-9260 |
DECAL-GERMAN Price: $10.42 |
| 28 |
84-9270 |
DECAL-SWEDISH Price: $10.42 |
| 28 |
84-9280 |
DECAL-ITALIAN Price: $5.58 |
| 28 |
93-7257 |
DISCONTINUED Price: Call Us |
| 28 |
93-7258 |
DISCONTINUED Price: Call Us |
| 28 |
93-7259 |
DISCONTINUED Price: Call Us |
| 28 |
93-7260 |
DISCONTINUED Price: Call Us |
| 28 |
93-7261 |
DISCONTINUED Price: Call Us |
| 503145101 |
503145101 |
CLUTCH SPRING Price: $7.99 |
| 503254601 |
503254601 |
NEEDLE BEARING Price: $11.99 |
| 503521204 |
503521204 |
WASHER Price: $4.99 |
| 503714003 |
503714003 |
CLUTCH Price: $49.99 |
