| Ref | Part Number | Description |
|---|
| 1 |
408799 |
Transaxle, Hydro Gear 351-0510 (See Transaxle Breakdown) Price: Call Us |
| 1 |
99-6905-03 |
NO. 5 LIFT ARM ASM Price: $807.57 |
| 2 |
123583X |
Key Square Price: Call Us |
| 2 |
3296-49 |
NUT-LOCK, NI Price: $4.93 |
| 3 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 4 |
302-60 |
FITTING-GREASE Price: $2.26 |
| 5 |
104-1438-03 |
STEP-PERFORATED Price: $33.53 |
| 6 |
3296-51 |
NUT-LOCK, NI Price: $3.23 |
| 7 |
328-7 |
SCREW-HH Price: $4.00 |
| 8 |
99-6941-03 |
PIVOT ROD ASM Price: $92.29 |
| 9 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 10 |
98-3929 |
SPRING-TORSION Price: $23.85 |
| 11 |
140-6431 |
PIVOT PIN ASM This part replaces 95-7158. Price: $37.92 |
| 12 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 13 |
3230-1 |
BOLT-CARR Price: $1.49 |
| 14 |
94-8946 |
WASHER-THRUST Price: $1.96 |
| 15 |
19131316 |
Washer 13/32 x 13/16 x 16 Ga. Price: Call Us |
| 15 |
5-1096 |
CHAIN-LIFT Price: $18.82 |
| 16 |
282-4 |
SHACKLE Price: $32.98 |
| 17 |
197296 |
Spring, Brake Price: Call Us |
| 17 |
283-6 |
PIN-CLEVIS Price: $1.70 |
| 18 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 19 |
256-287 |
BUSHING Price: $1.76 |
| 20 |
104-1413 |
CHAIN-LINK, STRAIGHT Price: $10.05 |
| 21 |
104-0028 |
GUIDE-HOSE Price: $46.21 |
| 22 |
197660 |
Rod Shift Price: Call Us |
| 22 |
32121-110 |
PIN-ROLL, SLOTTED Price: $1.93 |
| 23 |
3-6781 |
WASHER-THRUST Price: $1.40 |
| 23 |
409154X421 |
Knob Price: Call Us |
| 24 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 25 |
98-1880-03 |
KNUCKLE-PIVOT Price: $350.23 |
| 26 |
99-5610 |
PIN Price: $40.16 |
| 27 |
98-7993 |
SCREW-HHF Price: $3.05 |
| 28 |
76-2980 |
WASHER-THRUST Price: $5.08 |
| 29 |
197659 |
Rod, Brake Price: Call Us |
| 29 |
3256-6 |
WASHER-FLAT Price: $0.34 |
| 30 |
99-6913-03 |
DISCONTINUED Price: Call Us |
| 31 |
99-6904-03 |
ARM ASM #4 Price: $728.47 |
| 32 |
98-7974 |
WASHER-THRUST Price: $37.96 |
| 33 |
106-9004 |
BUMPER This part replaces 99-5605. Price: $6.35 |
| 33 |
12000001 |
Ring E Price: Call Us |
| 34 |
99-6901-03 |
DISCONTINUED Price: Call Us |
| 35 |
197722 |
Rod, Brake, Park Price: Call Us |
| 35 |
283-71 |
PIN-LYNCH Price: $2.73 |
| 37 |
121749X |
Washer 25/32 x 1-1/4 x 16 Ga. Price: Call Us |
| 38 |
323-6 |
SCREW-HH Price: $0.66 |
| 39 |
32128-21 |
NUT-HF Price: $0.39 |
| 40 |
3256-57 |
WASHER-FLAT Price: $0.41 |
| 41 |
32144-26 |
SCREW-FLOW, TAPTITE Price: $5.75 |
| 42 |
8883R |
Cover, Foot Pedal Price: Call Us |
| 42 |
98-3936 |
LANYARD Price: $23.28 |
| 49 |
72110614 |
Bolt Price: Call Us |
| 50 |
194327 |
Pulley Idler Flat Price: Call Us |
| 51 |
73900600 |
Lock Nut 3/8-16 Price: Call Us |
| 52 |
194326 |
Idler V-Groove 910" Offset Price: Call Us |
| 56 |
140218 |
V-Belt, Drive Price: Call Us |
| 64 |
196200 |
Shaft Asm. Pedal Brake Control Price: Call Us |
| 70 |
193220X428 |
Console Price: Call Us |
| 74 |
142432 |
Screw 1/4 x 1/2 Price: Call Us |
| 114 |
73800500 |
Nut Lock 5/16-18 UNC Price: Call Us |
| 116 |
73900500 |
Nut Lock Hex Flange 5/16-18 Price: Call Us |
| 125 |
17000512 |
Screw 5/16-18 x 3/4 Price: Call Us |
| 159 |
76020412 |
Pin Cotter 1/8 x 3/4 Price: Call Us |
| 160 |
169484 |
Retainer Clip Price: Call Us |
| 161 |
195403 |
Spring, Return, Clutch Price: Call Us |
| 162 |
195785 |
Spacer Transaxle Price: Call Us |
| 166 |
197290 |
Nut Push .625 Price: Call Us |
| 167 |
405257 |
Latch Brake Parking Price: Call Us |
| 169 |
74490560 |
Bolt 5/16-18 x 3.75 Price: Call Us |
| 170 |
194322 |
Keeper Belt Centerspan Price: Call Us |
| 171 |
72110622 |
Bolt Price: Call Us |
| 172 |
197655 |
Strap Torque RH Price: Call Us |
| 173 |
197656 |
Strap Torque LH Price: Call Us |
| 174 |
197289 |
Nut Push Price: Call Us |
| 175 |
197653 |
Shaft Asm Shift Price: Call Us |
| 176 |
196214 |
Arm Clevis Rod Shift Price: Call Us |
| 178 |
197456 |
Spring Shift Price: Call Us |
| 183 |
137057 |
Spacer Axle Price: Call Us |
| 184 |
198403X505 |
Handle Parking Brake Price: Call Us |
| 185 |
72110620 |
Bolt Price: Call Us |
| 186 |
194321 |
Spacer Retainer Price: Call Us |
| 187 |
19133210 |
Washer Price: Call Us |
| 188 |
194323 |
Link Clutch Ground Drive Price: Call Us |
| 189 |
194317 |
Bellcrank Ground Drive Price: Call Us |
| 190 |
194318 |
Keeper Bellcrank Ground Drive Price: Call Us |
| 195 |
198012 |
Bracket Brake Rod Price: Call Us |
| 199 |
72140508 |
Bolt 5/16-18 UNC x 1 Price: Call Us |
| 200 |
73930500 |
Nut Centerlock 5/16-18 UNC Price: Call Us |
| 201 |
169612 |
Bolt Shoulder 5/16-18 UNC Price: Call Us |
| 202 |
197715 |
Link Transaxle Price: Call Us |
| 203 |
19111116 |
Washer 11/32 x 11/16 x 16 Ga. Price: Call Us |
| 205 |
121748X |
Washer 25/32 x 1-5/8 x 16 Ga. Price: Call Us |
| 211 |
196212 |
Bushing Price: Call Us |
| 226 |
74780716 |
Bolt 7/16-14 x 1 Gr 5 Price: Call Us |
| 227 |
405296 |
Washer Serrated Price: Call Us |
