| Ref | Part Number | Description |
|---|
| 1 |
125-3483 |
BRUSH SHAFT ASM Price: $502.04 |
| 1 |
532850735 |
Control Bar (AYP part number) This part replaces 532800655. Price: $4.69 |
| 2 |
105-9635 |
BRUSH-GROOMER Price: $200.88 |
| 2 |
532850724 |
Handle Grip (AYP part number) Price: $11.99 |
| 3 |
120-9657 |
BOLT-J Price: $6.72 |
| 3 |
532194788 |
GUIDE.ROPE.STD.BLK.ZIN This part replaces 532132001. Price: $3.99 |
| 4 |
532125161 |
Upper Handle (AYP part number) Price: $42.91 |
| 5 |
532157081 |
HANDLE.LOWER.BLACK This part replaces 532125160. Price: $54.99 |
| 6 |
532183724 |
KNOB.HANDLE.KIT.SERVICE This part replaces 532131959. Price: $6.99 |
| 7 |
539976978 |
NUT 1/4-20 NYLOC This part replaces 532063601. Price: $1.99 |
| 8 |
532850733 |
BRACKET.UPSTOP This part replaces 532125162. Price: $3.99 |
| 9 |
817021008 |
Screw, Hex Hd. Tap #10-24 x 1/2 (AYP part number) This part replaces 532750097. Price: $1.99 |
| 10 |
532130861 |
Engine Zone Control Cable Price: $8.99 |
| 11 |
874250434 |
Machine Screw 1/4-20 x 2-1/8 (AYP part number) This part replaces 532085692. Price: $2.99 |
| 12 |
532051793 |
Hairpin Cotter (AYP part number) Price: $3.99 |
| 13 |
532183724 |
KNOB.HANDLE.KIT.SERVICE This part replaces 532063688. Price: $6.99 |
| 14 |
532077400 |
Hubcap (AYP part number) Price: $3.99 |
| 15 |
532409148 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 532083923. Price: $2.99 |
| 16 |
532428450 |
KIT.O-RING/WASHER This part replaces 532057143. Price: $5.99 |
| 17 |
532801847 |
Wheel & Tire Assembly 8.0 x 1.75 Price: $38.12 |
| 18 |
532174719 |
BOLT SHOULDER 3/8 -16X1 This part replaces 532084921. Price: $3.99 |
| 19 |
532062335 |
Belleville Washer (AYP part number) Price: $6.99 |
| 20 |
532125066 |
Selector Spring Price: $3.99 |
| 21 |
532701037 |
SELECTOR KNOB This part replaces 532132800. Price: $2.99 |
| 22 |
532125061 |
Axle Arm Assembly (AYP part number) Price: $7.99 |
| 23 |
532134528 |
Lawn Mower Housing (Inc. 29,30, and 44) Price: $3.33 |
| 24 |
532128151 |
Wheel Adjusting Bracket L.F. R.R. Price: $11.99 |
| 25 |
532084920 |
Spacer (AYP part number) Price: $1.99 |
| 26 |
532128150 |
Wheel Adjusting Bracket L.R. R.F. Price: $3.33 |
| 27 |
532085723 |
Washer (AYP part number) Price: $2.99 |
| 28 |
532700417 |
Throttle Control This part replaces 532132536. Price: $12.99 |
| 29 |
532125164 |
Handle Bracket Assembly (Right) (AYP part number) Price: $3.33 |
| 30 |
532125163 |
Handle Bracket Assembly (Left) (AYP part number) Price: $3.33 |
| 31 |
873680600 |
LOCKNUT This part replaces 532751592. Price: $1.99 |
| 32 |
532007192 |
WIRE TIE This part replaces 532066426. Price: $3.99 |
| 33 |
532055187 |
Thread Cutting Screw 5/16-18 x 3/4 (AYP part number) Price: $3.99 |
| 34 |
532851084 |
Hex Head Screw 3/8-24 x 1-3/8 Price: $2.99 |
| 35 |
539990118 |
SLW 3/8 STD This part replaces 532850263. Price: $1.99 |
| 36 |
532851074 |
Hardened Washer (AYP part number) Price: $2.99 |
| 38 |
581547901 |
ADAPTOR.BLADE.7/8 This part replaces 532850977. Price: $11.99 |
| 39 |
532130665 |
Hex Head Thread Rolling Screw 3/8-16 x 1-1/8 (AYP part number) Price: $3.33 |
| 40 |
532053998 |
Washer (AYP part number) Price: $3.71 |
| 41 |
532751649 |
Skirt Rod (AYP part number) Price: $3.99 |
| 42 |
532140544 |
Rear Skirt (AYP part number) This part replaces 532751648. Price: $10.99 |
| 43 |
532700279 |
Retainer Clip (AYP part number) Price: $3.99 |
| 44 |
581579101 |
DECAL.CUTFINGER.CE.02 This part replaces 532107339. Price: $4.99 |
| 45 |
532083816 |
Thread Rolling Screw #10-32 x 5/8 (AYP part number) Price: $3.99 |
