| Ref | Part Number | Description |
|---|
| 1 |
1915068 |
Self-Sealing Screw, 1/4"-20 x 5/8 " Price: $3.86 |
| 2 |
GW-20873 |
Tiller Housing Cover Price: $95.24 |
| 3 |
911-04082 |
Tine Shaft This part replaces 711-04082. Price: $101.65 |
| 4 |
941-3037 |
PTO SHAFT BALL BEARING This part replaces 741-3037. Price: $38.73 |
| 5 |
1901976 |
Worm Gear Price: $146.85 |
| 6 |
GW-1104 |
Woodruff Key Price: $8.32 |
| 7 |
921-04035 |
Oil Seal, .984 x 1.75 This part replaces 721-04035. Price: $10.91 |
| 8 |
716-0101 |
External Retaining Ring Price: $3.37 |
| 9 |
718-04614 |
Dog Clutch This part replaces 1909138. Price: $27.61 |
| 10 |
GW-9301 |
Key, 3/16" x 1" Price: $3.46 |
| 11 |
732-04022 |
COMPRESSION SPRING .766 ID x 1.50 TILR This part replaces GW-2127. Price: $4.99 |
| 12 |
1915069 |
Self-Sealing Screw, 1/4"-20 x 7/8" Price: $3.93 |
| 13 |
718-04406 |
Rear Bearing Cover This part replaces GW-1115. Price: $44.01 |
| 14 |
736-04305 |
Flat Washer, 1.75 x 1.5 x .062 Price: $3.52 |
| 15 |
941-04299 |
Cup Bearing This part replaces 741-04299. Price: $6.01 |
| 16 |
GW-11602 |
Shaft This part replaces GW-2653. Price: $265.94 |
| 17 |
921-04030 |
Oil Seal, .75 x 1.783 This part replaces 721-04030. Price: $11.33 |
| 18 |
716-04102 |
Retaining Ring Price: $3.85 |
| 19 |
619-04127 |
USE 619-04127 HOUSING-TRANS M This part replaces 1901971. Price: $301.55 |
| 20 |
1909157 |
Oil Dipstick Price: $16.46 |
