| Ref | Part Number | Description |
|---|
| 1 |
139-2564 |
NUT-LUG This part replaces 242-50. Price: $0.99 |
| 2 |
28-3680 |
TIRE This part replaces 231-64. Price: $118.18 |
| 2 |
482510 |
Extension, Oil Drain 2.3" - Kawasaki Price: Call Us |
| 3 |
217-60 |
RIM Price: $110.16 |
| 3 |
483280 |
Tubing, Oil Drain (order by inch) Price: Call Us |
| 4 |
04011-22 |
Screw, 3/8-19 x 1" Self Tapping Price: Call Us |
| 4 |
3272-13 |
PIN-COTTER Price: $0.25 |
| 5 |
463679 |
Clutch Price: Call Us |
| 5 |
99-3139 |
NUT This part replaces 11-5800. Price: $16.11 |
| 6 |
10-6821 |
BRAKE DRUM ASM This part replaces 10-6820. Price: $170.90 |
| 6 |
487917 |
Belt, Transmission Price: Call Us |
| 7 |
111512 |
DISCONTINUED This part replaces 10-6830. Price: Call Us |
| 7 |
486697 |
Transmission, MV702 Price: Call Us |
| 8 |
11-1579 |
DISCONTINUED-SEE MPV NOTES This part replaces 215-73. Price: Call Us |
| 8 |
487848 |
Pulley, Transmission Price: Call Us |
| 9 |
04063-39 |
KEY, WDRF # 505 FLAT BOTTOM Price: Call Us |
| 9 |
329-3 |
SCREW-HH Price: $0.22 |
| 10 |
04041-11 |
Flatwasher, 3/8-.406 x 1-1-1/2 x 7 Gauge Price: Call Us |
| 10 |
3255-7 |
WASHER-LOCK/EXT Price: $1.39 |
| 11 |
04030-04 |
Lockwasher, 3/8” Spring, Kawasaki FX / FT & FT-EFI / B&S 32BV Price: Call Us |
| 11 |
325-11 |
SCREW-HH Price: $1.93 |
| 12 |
04102-15 |
Bolt, Hex Head 3/8-24 x 2" w/ Patch Lock Price: Call Us |
| 12 |
10-8000 |
BRAKE BRACKET *B Price: $37.62 |
| 13 |
04001-04 |
Bolt, Hex Head, 1/4-20 x 1-1/2" Price: Call Us |
| 13 |
237-80 |
O-RING Price: $6.10 |
| 14 |
353-389 |
FITTING-ELBOW, 45 DEG Price: $36.57 |
| 14 |
463616 |
Anti Rotation Assy Price: Call Us |
| 15 |
32108-10 |
DISCONTINUED Price: Call Us |
| 15 |
431194 |
PIN, ANTI ROTATION Price: Call Us |
| 16 |
04063-17 |
KEY, 3/16 X 3/16 X 1" Price: Call Us |
| 16 |
27-2580 |
DISCONTINUED This part replaces 10-6450. Price: Call Us |
| 17 |
04019-02 |
NUT, 1/4-20 SERRATED FLANGE HEX HEAD Price: Call Us |
| 17 |
10-8180 |
TUBING CLAMP Price: $30.53 |
| 18 |
04003-07 |
Bolt, Carriage 1/4-20 x 1/2" Price: Call Us |
| 18 |
3220-2 |
NUT-JAM Price: $0.50 |
| 19 |
3290-318 |
DISCONTINUED Price: Call Us |
| 19 |
486912 |
Hourmeter Price: Call Us |
| 20 |
10-6350 |
CONTROL ROD WA Price: $102.40 |
| 21 |
04020-41 |
NUT, 7/16-14 UNC JAM ZINC Price: Call Us |
| 21 |
321-2 |
SCREW-HH Price: $2.79 |
| 22 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 22 |
484535 |
Spring, Brake Price: Call Us |
| 23 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 23 |
429511 |
Mtg Bracket, Clutch Cable Price: Call Us |
| 24 |
10-8220 |
TOOL BOX PAD Price: $24.12 |
| 24 |
431243 |
Spacer, Clutch Price: Call Us |
| 25 |
10-6430 |
DISCONTINUED Price: Call Us |
| 26 |
3253-7 |
WASHER-LOCK Price: $0.27 |
| 27 |
3217-9 |
NUT-HH Price: $0.37 |
| 28 |
3296-3 |
NUT-LOCK Price: $0.54 |
| 29 |
3272-2 |
PIN-COTTER Price: $2.29 |
| 30 |
10-5890 |
DISCONTINUED Price: Call Us |
| 31 |
329-7 |
SCREW-HH Price: $0.22 |
| 32 |
11-8840 |
DISCONTINUED Price: Call Us |
| 33 |
125-5196 |
BUSHING This part replaces 3-0348. Price: $6.00 |
| 34 |
20-7650 |
DISCONTINUED Price: Call Us |
| 35 |
3217-5 |
NUT-HEX Price: $0.25 |
| 36 |
136-8446 |
KIT, CENTER PULL FRAME This part replaces 12-8200. Price: $340.89 |
| 37 |
283-1 |
PIN-CLEVIS Price: $1.63 |
| 38 |
282-2 |
YOKE Price: $30.04 |
| 39 |
3272-6 |
PIN-COTTER Price: $0.25 |
| 40 |
10-8010 |
DISCONTINUED X-REF Price: Call Us |
| 41 |
11-5790 |
KEY-SQUARE Price: $17.50 |
| 42 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 43 |
215-75 |
HOLD DOWN SPRING Price: $7.60 |
| 44 |
99-5652 |
BRAKE ASM & LEVER This part replaces 3-6944. Price: $179.21 |
| 45 |
215-74 |
DISCONTINUED Price: Call Us |
| 46 |
215-76 |
DISCONTINUED Price: Call Us |
| 47 |
232-24 |
STEM-VALVE Price: $4.03 |
